Quick Details
-
Rolling thinckness:
-
0.5-1.2mm
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
FORWARD
-
Voltage:
-
380V 50Hz 3phases
-
Dimension(L*W*H):
-
11000*1950*950mm
-
Weight:
-
5000 kg
-
Marketing Type:
-
New Product 2024
-
After-sales Service Provided:
-
Service Machinery Overseas
-
Roller material:
-
High-grade 45# Steel Outer
-
Thickness:
-
0.5~1.2mm
-
Usage:
-
Building
-
Control system:
-
PLC System
-
Color:
-
Blue
-
Cutting blade material:
-
Cr 12Mov
-
Keywords:
-
Colored Steel Roof Making Machine
Quick Details
-
Type:
-
Tile Forming Machine
-
Tile Type:
-
Colored Steel
-
Production Capacity:
-
15m/min
-
Rolling thinckness:
-
0.5-1.2mm
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
FORWARD
-
Voltage:
-
380V 50Hz 3phases
-
Dimension(L*W*H):
-
11000*1950*950mm
-
Weight:
-
5000 kg
-
Marketing Type:
-
New Product 2024
-
After-sales Service Provided:
-
Service Machinery Overseas
-
Roller material:
-
High-grade 45# Steel Outer
-
Thickness:
-
0.5~1.2mm
-
Usage:
-
Building
-
Control system:
-
PLC System
-
Color:
-
Blue
-
Cutting blade material:
-
Cr 12Mov
-
Keywords:
-
Colored Steel Roof Making Machine
|
No.
|
Iron Sheet Making/Press/Rolling Machine
|
|
|
|
1
|
Suitable material
|
PPGI/Aluminium sheet/galvanized sheet/various sheet plates
|
|
|
2
|
Thickness of coil sheet
|
0.5mm-1.2mm
|
|
|
3
|
Coil width
|
1200mm
|
|
|
4
|
Material of main frame
|
350H steel
|
|
|
5
|
Diameter of Soild shaft
|
80mm, high grade 45# steel
|
|
|
6
|
Roller
|
Quenched and tempered treatment,
hard chrome coated 0.05-0.07mm |
|
|
7
|
Thickness of middle plate
|
16mm
|
|
|
8
|
Forming station
|
24 stations
|
|
|
9
|
Drive type
|
By chain(1.0 inch) link bearing model 6210
|
|
|
10
|
Power of main motor
|
7.5kw with Cycloidal reducer
|
|
|
11
|
Power of pump station
|
5.5kw
|
|
|
12
|
Forming speed
|
About 15m/min
|
|
|
13
|
Hydraulic cutting
|
Controlled by PLC
|
|
|
14
|
PLC
|
DELTA(TAIWAN)/Mitsubishi
|
|
|
15
|
Material of razor blades
|
Cr 12, quenching 58-62℃
|
|
|
16
|
Frequency converter
|
It has the advantage of slowing down before cutting, to ensure the
length accuracy(±1mm, far better than industrial standard ±3mm). |
|
