Quick Details
-
Use:
-
Curtain, Bags,Purses & Totes, Outdoor, Outdoor-Umbrella, Outdoor-Tent, Outdoor-Awning, Outdoor-Agriculture, Outdoor-Metallurgy, Outdoor-Industry
-
Yarn Count:
-
1000D*1000D
-
Weight:
-
18oz/ 610gsm
-
Density:
-
20*20
-
Model Number:
-
UKCT1122/610
-
Product Name:
-
PVC Truck Cover Tarpaulins 1000D PVC Coated Fabric Tarpaulin
-
Color:
-
Refer to RAL & PANTONE color chart
-
Printing:
-
Printable, customized
-
Package:
-
hard tube/kraft paper/bale/carton box/customized
-
Temperature resistance:
-
-30°C ~ +70°C
-
Size:
-
Customizable Size
-
Surface:
-
Glossy, Matt or as customized
-
Life Span:
-
Laminated:3-5years, semi-Coated:5-8 years, Knife coated: 10-15 years
-
Usage:
-
Multi-purpose Cover,Cover Outdoor Items,Inflatable Products
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
UNITARP
Quick Details
-
Material:
-
pvc+polyester
-
Pattern:
-
Coated
-
Feature:
-
Water Resistant, Flame Retardant, Waterproof, Tear-Resistant, Anti-UV
-
Use:
-
Curtain, Bags,Purses & Totes, Outdoor, Outdoor-Umbrella, Outdoor-Tent, Outdoor-Awning, Outdoor-Agriculture, Outdoor-Metallurgy, Outdoor-Industry
-
Yarn Count:
-
1000D*1000D
-
Weight:
-
18oz/ 610gsm
-
Density:
-
20*20
-
Model Number:
-
UKCT1122/610
-
Product Name:
-
PVC Truck Cover Tarpaulins 1000D PVC Coated Fabric Tarpaulin
-
Color:
-
Refer to RAL & PANTONE color chart
-
Printing:
-
Printable, customized
-
Package:
-
hard tube/kraft paper/bale/carton box/customized
-
Temperature resistance:
-
-30°C ~ +70°C
-
Size:
-
Customizable Size
-
Surface:
-
Glossy, Matt or as customized
-
Life Span:
-
Laminated:3-5years, semi-Coated:5-8 years, Knife coated: 10-15 years
-
Usage:
-
Multi-purpose Cover,Cover Outdoor Items,Inflatable Products
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
UNITARP
Products Description
|
Basic Information:
|
|
|
|
Item
|
Unitarp Custom Waterproof Fireproof Plastic Pvc Tarps Tarpaulin Fabric
|
|
|
Base fabric
|
100% Polyester
|
|
|
Surface Treatment
|
Acrylic / PVDF
|
|
|
Weight
|
300gsm ~ 1500gsm
|
|
|
Max Width
|
5m
|
|
|
Printing
|
Printable, customized
|
|
|
Colour
|
Refer to RAL & PANTONE color chart
|
|
|
Features
|
Waterproof, Fire Retardant, Anti UV, Heavy Metal Free, Anti Mildew, Flexible, Heavy Duty, Tensile, Self Clean etc are available.
|
|
|
Application
|
1. Truck/Trailer/Pallet cover, Top roof and side curtain.
2. Outdoor event tent(blockout),Awnings. 3. Rain and sunshine shelter, playground. 4. Outdoor tent, carriage tent and house building. 5. Membrane Construction Structure,
6. Healthcare Medical Treatment.
7. Sport, Inflatable Fabric, Package etc |
|
|
Package
|
Craft paper; Hard Tube Packing
|
|
|
PVC Tarpaulin Features:
|
|
|
|
Fireproof
|
B1,B2,M1,M2,NFPA701 Optional
|
|
|
Anti-uv
|
Optional
|
|
|
PVDF/Acrylic
|
Optional
|
|
|
Anti-mildew
|
Optional
|
|
|
Eco-Friendly
|
3P, 6P, Reach, heavy metal free Optional
|
|
|
Weather Resistant
|
-35℃ ~ +70℃
|
|
Basic knowledge:
1. PVC
- The qualities in direct coating process range from 300gsm to 1200 gsm
- Standard widths are 1.5m, 2m, 2.5m, 3.2m (can be customized, MAX width: 5.1 m)
2. Yarn:
- Differet thicknesses range from 300Dtex to 2200Dtex with the most common being 1000Dtex
- The tear and tensile strengths as well as most of the stability of the product is determined by the fabric
- Full panama weave or half panama weave
3. Test Method:
- Weight (DIN53352)
- Breaking Strength (DIN53354)
- Tear strength (DIN53363)
- Adhesion (DIN53357)
- Temp Resistance (DIN53372)
1. PVC
- The qualities in direct coating process range from 300gsm to 1200 gsm
- Standard widths are 1.5m, 2m, 2.5m, 3.2m (can be customized, MAX width: 5.1 m)
2. Yarn:
- Differet thicknesses range from 300Dtex to 2200Dtex with the most common being 1000Dtex
- The tear and tensile strengths as well as most of the stability of the product is determined by the fabric
- Full panama weave or half panama weave
3. Test Method:
- Weight (DIN53352)
- Breaking Strength (DIN53354)
- Tear strength (DIN53363)
- Adhesion (DIN53357)
- Temp Resistance (DIN53372)
Details Images
|
Type
|
Description
|
Base Fabric
|
Weight(g/sqm)
|
Width(m)
|
|
UKT1133/900
|
Knife coated Tarpaulin
|
1000*1000D, 30*30/sq.in
|
900
|
1.6/2.5/2.8/3/3.2
|
|
UKT1133/1050
|
Knife coated Tarpaulin
|
1000*1000D, 30*30/sq.in
|
1050
|
1.6/2.5/2.8/3/3.2
|
|
UKT133032/1100
|
Knife coated Tarpaulin
|
1300*1300D, 30*32/sq.in
|
1100
|
1.6/2.5/2.8/3/3.2
|
|
UKT153032/1200
|
Knife coated Tarpaulin
|
1500*1500D, 30*32/sq.in
|
1200
|
1.6/2.5/2.8/3/3.2
|
|
UCT1122/610
|
Coated Tarpaulin
|
1000*1000D, 20*20/sq.in
|
610 (18oz)
|
1.6/2.5/2.8/3/3.2/5
|
|
UCT1122/650
|
Coated Tarpaulin
|
1000*1000D, 20*20/sq.in
|
650 (19oz)
|
1.6/2.5/2.8/3/3.2/5
|
|
UCT1122/750
|
Coated Tarpaulin
|
1000*1000D, 20*20/sq.in
|
750 (22oz)
|
1.6/2.5/2.8/3/3.2
|
|
UCT2826/1050
|
Coated Tarpaulin
|
1000*1000D, 28*26/sq.in
|
1050
|
1.6/2.5/2.8/3/3.2
|
|
ULT551817/450
|
Laminated Tarpaulin
|
500*500D, 18*17/sq.in
|
450
|
1.6/2.5/2.8/3/3.2/5
|
|
ULT35/500
|
Laminated Tarpaulin
|
300*500D, 18*12/sq.in
|
500
|
1.6/2.5/2.8/3/3.2/5
|
|
ULT8484/550
|
Laminated Tarpaulin
|
840*840D, 9*9/sq.in
|
550
|
1.6/2.5/2.8/3/3.2/5
|
|
ULT1199/600
|
Laminated Tarpaulin
|
1000*1000D, 9*9/sq.in
|
600
|
1.6/2.5/2.8/3/3.2/5
|
|
ULT1618/680
|
Laminated Tarpaulin
|
1000*1000D, 18*16/sq.in
|
680
|
1.6/2.5/2.8/3/3.2/5
|
Product packaging
