Quick Details
-
Battery Size:
-
LFP 36V 100AH
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
33KG
-
Cycle life:
-
3000+times
-
Battery cell:
-
prismatic
-
Max Continuous discharge current:
-
100A
-
Color:
-
Black and Customized
-
Peak discharge current:
-
200A
-
Cut off voltage:
-
30v
-
Protection:
-
with BMS
-
Warranty:
-
3 Years, 3years
-
ODM OEM:
-
Available
-
Dimension:
-
520*267*218mm
-
Certification:
-
CE MSDS FCC ROHS
Quick Details
-
Application:
-
BOATS, Golf Carts, Electric Bicycles/Scooters, electric vehicles, Solar Energy Storage Systems, Uninterruptible Power Supplies, lead acid replacement
-
Brand Name:
-
CYCLENPO
-
Model Number:
-
CY LFP-36-100
-
Battery Size:
-
LFP 36V 100AH
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
33KG
-
Cycle life:
-
3000+times
-
Battery cell:
-
prismatic
-
Max Continuous discharge current:
-
100A
-
Color:
-
Black and Customized
-
Peak discharge current:
-
200A
-
Cut off voltage:
-
30v
-
Protection:
-
with BMS
-
Warranty:
-
3 Years, 3years
-
ODM OEM:
-
Available
-
Dimension:
-
520*267*218mm
-
Certification:
-
CE MSDS FCC ROHS
Product Description
Cyclen provides one-stop services and fully-integrated battery solution to meet your specific needs. The products we display don't represent the limitation of us.
In addition to the battery shape and temperature conditions, we can customize specifications and BMS: voltage, capacity , charge current, discharge current and etc.If you are interested in our products, please don't hesitate to contact us at any time.
In addition to the battery shape and temperature conditions, we can customize specifications and BMS: voltage, capacity , charge current, discharge current and etc.If you are interested in our products, please don't hesitate to contact us at any time.
|
Normal parameters
|
|
|
|
|||
|
NO
|
Item
|
General Parameter
|
Remark
|
|||
|
1
|
Model
|
IFR 3.2V 100AH
|
Single
|
|||
|
2
|
Casing material for single cell
|
Nickel plated steel
|
|
|||
|
3
|
Standard capacity(0.2C5A)
|
100Ah
|
|
|||
|
4
|
Rated voltage
|
38.4V
|
38.4V(Work voltage:38.4V)
|
|||
|
5
|
Max.Charge voltage
|
43.2V
|
3.65V(Single Ave. charge Voltage)
|
|||
|
6
|
Cut-off voltage
|
30V
|
2.50V(Single Ave. Discharge Voltage)
|
|||
|
8
|
Standard charge current
|
30A
|
0.3C
|
|||
|
9
|
charging Time
|
About 3.5h
|
|
|||
|
10
|
Max Continuous discharge current
|
100A
|
1C
|
|||
|
11
|
Peak discharge current
|
200A
|
2C (10s) seconds
|
|||
|
12
|
Battery dimension
|
520 * 267 * 218 mm
|
|
|||
|
13
|
(Approx.)Total weight(Approx.)
|
About 35.36kg
|
|
|||
|
14
|
(Max, at 1000Hz.)Impedance(Max, at 1000Hz.)
|
≤ 20mΩ
|
|
|||
|
15
|
(CC/CV)
Charge method (CC/CV) |
Standard
|
0℃~45℃
|
|||
|
|
|
discharge
|
-20℃~65℃
|
|||
|
|
|
storage
|
-20℃~45℃
|
|||
Main Features
1. Lighter in weight, heavier on power
2. Use a grade prismatic cells. More than 3000 cycle times.Up to 7-8 years lifespan.
3. Max discharge continuous current 100A, peak 200A.
4. Maintenance free.
Built in BMS overall protection
1.Over charged protection
2.Over discharged protection
3.Thermal protection
4.Over load protection
5.Over current protection
Application
Widely used in RV, camping car, golfcart, sightseeing car, marine, yacht, solar backup, and other deep cycle applications etc.
1. Lighter in weight, heavier on power
2. Use a grade prismatic cells. More than 3000 cycle times.Up to 7-8 years lifespan.
3. Max discharge continuous current 100A, peak 200A.
4. Maintenance free.
5. Can connect in parallel and series.
6. IP65 waterproof ratings.Suitable for marine use.
6. IP65 waterproof ratings.Suitable for marine use.
7.
Safer performance. Our batteries have passed different safety tests.
Built in BMS overall protection
1.Over charged protection
2.Over discharged protection
3.Thermal protection
4.Over load protection
5.Over current protection
Application
Widely used in RV, camping car, golfcart, sightseeing car, marine, yacht, solar backup, and other deep cycle applications etc.
