Quick Details
-
Ink Type:
-
UV Ink
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Winscolor
-
Voltage:
-
110/220V
-
Dimensions(L*W*H):
-
5370*3780*1460mm
-
Weight:
-
3000 KG
-
Marketing Type:
-
Hot Product 2022
-
Product name:
-
inkjet printers
-
Printing Size:
-
3300*2100mm
-
Lamp:
-
LED UV Lamp
-
Print head:
-
Ricoh Gen5
-
Print speed:
-
2~16 sqm/h
-
Printhead arrangement:
-
CMYK LC LM W V Optional
-
Printing Material:
-
Flat roller Materials
-
Software:
-
Photoprint optional
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
Quick Details
-
Print Dimension:
-
3300*2100mm
-
Condition:
-
New
-
Color & Page:
-
Multicolor
-
Ink Type:
-
UV Ink
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Winscolor
-
Voltage:
-
110/220V
-
Dimensions(L*W*H):
-
5370*3780*1460mm
-
Weight:
-
3000 KG
-
Marketing Type:
-
Hot Product 2022
-
Product name:
-
inkjet printers
-
Printing Size:
-
3300*2100mm
-
Lamp:
-
LED UV Lamp
-
Print head:
-
Ricoh Gen5
-
Print speed:
-
2~16 sqm/h
-
Printhead arrangement:
-
CMYK LC LM W V Optional
-
Printing Material:
-
Flat roller Materials
-
Software:
-
Photoprint optional
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
Product Description
1. UV LED Lamp 2. Anti-static, Anti-crash 3. TAIWAN HIWIN guide rail
4. Switch and power switch area 5 . Top Heavy Rubber Roller 6. Universal Wheel
4. Switch and power switch area 5 . Top Heavy Rubber Roller 6. Universal Wheel
7.
Industrial Print head
Specification
|
Product Model
|
YC3321R
|
|
|
|
|||
|
Printhead Type
|
RICOH GEN5/GEN6/KM1024I/SPT1024GS
|
|
|
|
|||
|
Printhead Number
|
2-8 heads
|
|
|
|
|||
|
Ink Characteristics
|
UV Curing Ink (VOC Free)
|
|
|
|
|||
|
Ink reservoirs
|
Refillable on the fly while printing 2500ml per color
|
|
|
|
|||
|
LED UV Lamp
|
more than 30000-hours life
|
|
|
|
|||
|
Printhead arrangement
|
CMYK LC LM W V Optional
|
|
|
|
|||
|
Printhead Cleaning System
|
Automatic Cleaning System
|
|
|
|
|||
|
Guide Rail
|
Taiwan HIWIN
|
|
|
|
|||
|
Working Table
|
Vacuum Sucking
|
|
|
|
|||
|
Printing Size
|
3300*2100mm
|
|
|
|
|||
|
Roller Material Width
|
3300mm
|
|
|
|
|||
|
Roller Material Diameter
|
200mm
|
|
|
|
|||
|
Print Interface
|
USB2.0
|
|
|
|
|||
|
Media Thickness
|
0-100mm
|
|
|
|
|||
|
Print Resolution& Speed
|
720X600dpi
|
4PASS
|
13-55sqm/h
|
|
|||
|
|
720X900dpi
|
6PASS
|
10-22sqm/h
|
|
|||
|
|
720X1200dpi
|
8PASS
|
8-18sqm/h
|
|
|||
|
Life of printed image
|
3 years(outdoor),10years(indoor)
|
|
|
|
|||
|
File Format
|
TIFF,JPEG,Postscript,EPS,PDF etc.
|
|
|
|
|||
|
RIP Software
|
Photoprint Ntek
|
|
|
|
|||
|
Power Supply
|
220V 50/60Hz(10%)
|
|
|
|
|||
|
Power
|
8500W
|
|
|
|
|||
|
Operation Environment
|
Temperature 20 to 30 ℃,Humidity 40% to 60%
|
|
|
|
|||
|
Machine Dimension
|
5.37*3.78*1.46m
|
|
|
|
|||
|
Packing Dimension
|
5.55*2.25*1.67m 4.3*0.85*1.22m
|
|
|
|
|||
|
Weight
|
3000kg
|
|
|
|
|||
|
Warranty
|
12 months exclude the consumables
|
|
|
|
|||
