- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
1992mmX1050mm(820mm)X1210mm
-
Machine Weight:
-
1538 kg
-
Bucket capacity:
-
0.08CBM
-
Marketing Type:
-
New Product 2024
-
Product name:
-
STR 1000
-
Cutting-edge Design:
-
Closed Hydraulic System
-
Engine:
-
Kubota/Perkins
-
Rotating speed (rpm):
-
3600
-
Noise (Db):
-
≤95
-
Pressure (Mpa):
-
17
-
bucket Capacity:
-
0.08 m³
-
Max Lifting Force:
-
300 Kg
-
Customization:
-
Color/Logo/Fuselage Sticker
-
Provide support:
-
TUV and other third party door-to-door inspection service
Quick Details
-
Engine Brand:
-
Perkins
-
Power:
-
18.5 KW (25HP)
-
Brand Name:
-
STR
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
1992mmX1050mm(820mm)X1210mm
-
Machine Weight:
-
1538 kg
-
Bucket capacity:
-
0.08CBM
-
Marketing Type:
-
New Product 2024
-
Product name:
-
STR 1000
-
Cutting-edge Design:
-
Closed Hydraulic System
-
Engine:
-
Kubota/Perkins
-
Rotating speed (rpm):
-
3600
-
Noise (Db):
-
≤95
-
Pressure (Mpa):
-
17
-
bucket Capacity:
-
0.08 m³
-
Max Lifting Force:
-
300 Kg
-
Customization:
-
Color/Logo/Fuselage Sticker
-
Provide support:
-
TUV and other third party door-to-door inspection service
Hi My friend, welcome to SHANDONG STR INTELLIGENT EOUIPMENT CO., LTD,
Acompany specializing in manufacturing skid steer loaders in China,We have a variety of
models for you to choose from and support various customizations.Looking forward to
cooperating with you very much.
PRODUCT PARAMENTERS
|
No
|
Item
|
Metric
|
U.S.
|
|
1
|
Max working height (H3）
|
3028 mm
|
119.2 inch
|
|
2
|
Max pin height (H2)
|
2352 mm
|
92.6 inch
|
|
3
|
Max Dumping height (H1)
|
1730 mm
|
68.1 inch
|
|
4
|
Max Dumping distance(E)
|
900 mm
|
35.4 inch
|
|
5
|
Max Dumping Angle (a3)
|
95°
|
95°
|
|
6
|
Rollback of bucket on ground (a2)
|
25°
|
25°
|
|
7
|
Departure angle (a1)
|
28°
|
28°
|
|
8
|
Total height (H)
|
1405 mm
|
55.3 inch
|
|
9
|
Ground clearance (F)
|
185 mm
|
7.3 inch
|
|
10
|
Wheel base (L1)
|
1435 mm
|
56.5 inch
|
|
11
|
Overall length without bucket (L3)
|
2152 mm
|
84.7 inch
|
|
12
|
Total width (B2)
|
900 mm
|
35.4 inch
|
|
13
|
Bucket width (B1)
|
920 mm
|
36.2 inch
|
|
14
|
Total length with bucket (L)
|
2895 mm
|
114.1 inch
|
|
15
|
Turn radius forward turning (R)
|
1740 mm
|
68.5 inch
|
|
16
|
Rated Power (KW)
|
18.4KW(25HP)
|
|
|
17
|
Rotating speed (rpm)
|
2800
|
|
|
18
|
Noise (Db)
|
≤95
|
|
|
19
|
Pressure (Mpa)
|
2.4
|
|
|
20
|
Raise
|
4
|
|
|
21
|
Dump
|
1.3
|
|
|
22
|
Lower
|
3.2
|
|
|
16
|
Operating Load
|
454 Kg
|
1000 Lb
|
|
20
|
Bucket Capacity
|
0.08 m³
|
3 ft³
|
|
21
|
Max Lifting Force
|
300 Kg
|
661.39 Lb
|
|
22
|
Travel Speed
|
0-5.8 Km/h
|
3.73 mlie/h
|
|
23
|
Operating Weight
|
1538 Kg
|
3390 Lb
|
FAQ
Q: Are you original manufacturer?
A: Yes. We are manufacturer of construction machines and you can take a video tour of our factory anytime during working hours.
Q: How long is the machine warranty time?
A: One year.
Q: How should we do if the machine broken ?
A: You can take a video to us and our technicians will analyze the cause of the problem based on the video.
Q: How should we do if parts are broken ?
A: We advise customers to purchase some conventional accessories based on their country and
environment. If other parts broke ,we will send to you by sea or by air.
environment. If other parts broke ,we will send to you by sea or by air.
Q: What is the delivery time ?
A: Generally we need 5-7 days to produce the machine after prepayment ,if you are urgent , 3 days will be ok ,then send to port.
Q: What is the terms of payment?
A: :Normally, we accept 20% advance, 80% should be paid after finished the machine, L/C at sight.
