Quick Details
-
Model Number:
-
TLFS20-500
-
Power:
-
0.59kw-1.69kw
-
Material:
-
plywood package/nude package
-
Weight (KG):
-
8000 kg
-
Model:
-
TLFS-10--TLFS-500
-
Capacity:
-
10-500kgs/batch
-
Color:
-
Customized Color
-
Application:
-
Farms/animal pet hospitals/livestock farms
-
Fuel:
-
Diesel oil/LPG/natural gas
-
Voltage:
-
380v/220v
-
Certification:
-
CE, ISO
-
Service life:
-
10-20 Years
-
Advantage:
-
Harmless,smokeless
-
Raw material:
-
Inside High Temperature Refractory Brick,outside carbon steel
Quick Details
-
Production Capacity:
-
500L/H
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
TIANLANG
-
Model Number:
-
TLFS20-500
-
Power:
-
0.59kw-1.69kw
-
Material:
-
plywood package/nude package
-
Weight (KG):
-
8000 kg
-
Model:
-
TLFS-10--TLFS-500
-
Capacity:
-
10-500kgs/batch
-
Color:
-
Customized Color
-
Application:
-
Farms/animal pet hospitals/livestock farms
-
Fuel:
-
Diesel oil/LPG/natural gas
-
Voltage:
-
380v/220v
-
Certification:
-
CE, ISO
-
Service life:
-
10-20 Years
-
Advantage:
-
Harmless,smokeless
-
Raw material:
-
Inside High Temperature Refractory Brick,outside carbon steel
Hospital incinerator poultry incinerator pet cremation incinerators harmless cremators machine
Product Description
1,
Adopts the most advanced incineration method:
one-stage pyrolysis gasification + surround wind con-firing + secondary incineration + burn-out
2, Incinerators
reduce
the solid mass of the original waste by
80-85%
and the volume reduced by
95-96%.
3,The
highest temperature
of incinerator running
can reach 1100-1300℃
,which can
achieve the effect of sterilization and disinfection
.
4, There will be
no smoke,no smell,no pollution after be burning.
Product Application
Pet Animal Waste cremation:dead animal body and pets carcass.
S
uch as dog,cat,chicken,duck,fish,birds,cattle,etc.
Farm incinerators,
such as cattle farms,pig farms,sheep farms,stables,kennels,abattoirs,testing laboratories, catteries, pet crematoriums and poultry farms, other waste disposals. Thus we manufacturer animal incinerator for animal carcass incinerator ,sheep farms incinerator,cattle farms incinerator,cattle farms incinerator,
poultry farms incinerator,pig farms incinerator,stables incinerator,abattoirs incinerator,animal cremation incinerators
.
The product advantage
1.
It's easier to operate than other manufactures' incinerators.
Provide installation manual, operation video, online technical guidance.
You can use it once the incinerator installation is completed.
2.Low running&maintenance cost.
Power consumption is less than 2 KWH.
3.
There is
no smoke,no smell,no pollution
after waste burning.
4.The highest temperature can reach 1100-1300 degrees Celsius,which
can achieve the effect of sterilization and disinfection.
5. Long service time:
15-20 years
service life
6.Be portable and cover a small area.
Technical Data
|
Name
|
TLFS-30
|
TLFS-50
|
TLFS-100
|
TLFS-150
|
TLFS-300
|
TLFS-500
|
|
Capacity
|
30kg/batch
|
50kg/batch
|
100kg/batch
|
150kg/batch
|
300kg/batch
|
500kg/batch
|
|
Size(L*W*H)mm
|
1300*800*1650
|
1800*1150*3000
|
1800*1300*3300
|
2000*1400*3500
|
2200*1550*3800
|
3000*2000*4800
|
|
Waste inlet(mm)
|
480*600
|
620*800
|
680*900
|
760*960
|
900*1100
|
1080*1280
|
|
Chimney (mm)
|
Outer diameterφ280
|
Outer diameterφ280
|
Outer diameterφ300
|
Outer diameterφ300
|
Outer diameterφ400
|
Outer diameterφ400
|
|
Air blower
|
0.37kw
|
0.37kw
|
0.37kw
|
0.5kw
|
0.5kw
|
1.1kw
|
|
FIrst burner
|
0.11kw
|
0.11kw
|
0.11kw
|
0.11kw
|
0.22kw
|
0.22kw
|
|
Second burner
|
0.11kw
|
0.11kw
|
0.11kw
|
0.22kw
|
0.37kw
|
0.37kw
|
|
Voltage
|
380V/220V
|
380V/220V
|
380V/220V
|
380V/220V
|
380V/220V
|
380V/220V
|
|
Weight (kgs)
|
2500
|
5500
|
8000
|
10000
|
12000
|
20000
|
30 kg/batch capacity incinerator
Our Service
Pre-sale service
If there any needs or not know how to choose the incinerator, please contact me with your questions. I will provide your the professional recommend and detailed information about
suitable model of incinerator
During the production process, the quality inspection department strictly controls the product quality of the incinerator.
After the incinerator is completed, it will be tested before transportation
to further ensure the product quality of each incinerator.
After-sales service
1.Provide the English(or other language )
Print version with electronic version
Installation Manual
s.
2.Our equipment warranty period is 1 year.
3.If there is any malfunction of the equipment during the warranty period. our company promise to propose a solution within 24 hours.
4. Incinerator
Accessories can enjoy a lifetime 20% discount.
