Quick Details
-
EINECS No.:
-
231-072-3
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
jinhua
-
Model Number:
-
318AB
-
Type:
-
liquid
-
Color:
-
Clear
-
Certificate:
-
ROHS,REACH, PAHS, ASTM, EN-71
-
Mixing Ratio:
-
A:B=3:1
-
Shelf life:
-
6 Months
-
Lead Time:
-
3days
Quick Details
-
CAS No.:
-
38891-59-7
-
Other Names:
-
epoxy resin ab glue
-
MF:
-
C15H16O2C2H7ONC3H5OCl
-
EINECS No.:
-
231-072-3
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
jinhua
-
Model Number:
-
318AB
-
Type:
-
liquid
-
Color:
-
Clear
-
Certificate:
-
ROHS,REACH, PAHS, ASTM, EN-71
-
Mixing Ratio:
-
A:B=3:1
-
Shelf life:
-
6 Months
-
Lead Time:
-
3days
1.JINHUA clear and transparent epoxy resin AB glue made from basic pure resin and do well in adhesive.
2.Good at UV and yellow resistance,self leveling,without bubble,high brightness.
3.Can be cured at nomal temperature or by heating.
4.Clear,low viscosity,nature defoaming, super transprency and good performance after mixed.
5.Can get any color you want by add pigments.
6.Easy to clean and repair.
7.No ripple,bright in surface,odourless,eco-friendly,nontoxic,waterproof and so on.
Certificated
Application
312AB-8 can be widely used for high quality LED channel letter, photo frame, drops of glue, signs, cards, crafts, lamp potting and mold filling, etc..
Product Display
Properties before Hardening
|
Part |
312A-8 |
312B-8 |
|
Color |
Transparent |
Transparent |
|
Specific gravity |
1.15 |
0.96 |
|
Viscosity (25℃) |
2000-4000CPS |
100 MAXCPS |
|
Mixing ratio |
A: B = 100:33(weight ratio) |
|
|
Hardening conditions |
25 ℃×8H to 10H or 55℃×1.5H (2 g) |
|
|
Usable time |
25℃×40min (100g) |
|
Operation
1.Weigh A and B glue according to the given weight ratio into the prepared cleaned container, fully mixed the mixture again the container wall by clockwise, place it along for 3 to 5 minutes, and then it can be used.
2.Take the glue according to the usable time and dosage of mixture to avoid wasting. When the temperature is below 15 ℃, please heat A glue to 30 ℃ first and then mix it to the B glue (A glue will be thicken in low temperature ); The glue must be sealed lid after use to avoid rejection caused by moisture absorption.
3.When the relative humidity is higher than 85%, the surface of the cured mixture will absorb moisture in the air, and form a layer of white mist in the surface, so when the relative humidity is higher than 85%, is not suitable for room temperature curing, suggest to use the heat curing.
Properties after Hardening
|
Hardness, shore D |
<85 |
|
Withstand voltage, KV/mm |
22 |
|
Flexural strength, Kg/mm2 |
28 |
|
Volume resistivity, Ohm3 |
1x10 15 |
|
Surface resistance, Ohmm2 |
5X10 15 |
|
Thermal conductivity, W/M.K |
1.36 |
|
Induced electric loss, 1KHZ |
0.42 |
|
Withstand high temperature, ℃ |
80 |
|
Moisture absorption, % |
<0.15 |
|
Compressive strength, Kg/ mm2 |
8.4 |
Caution
1,The operating environment should be ventilative and should keep away from fire. Closely sealed after use.
2, Avoid eye contact, in case of contact, wash with plenty of water and get medical attention immediately.
3, If contact skin, wrap with clean cloth or paper, and wash it with water and soap.
4, Keep away from children.
5, Please take a trial before application to avoid usage mistake.
Storage And Shelf Life
1, Store at the temperature of 25°C or cool and dry place. Avoid from sunlight, high temperature or high humidity environment.
2, Use up as soon as possible when opened. It is strictly forbidden to expose to the air for a long time after it is opened to avoid affecting the quality of the products. The shelf life is six months in the room temperature of 25°C.
5kgs per bottle; 20kgs per carton
20kgs per barrel
200kgs per barrel
Delivery Detai: Shipped in 3 days after payment
