Replacebale led strip inside , easy for your post-maintaince
With 1.2mm aluminum heat sink, superior in heat disspitation
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Other Country
-
Model Number:
-
NBPC-2
-
Brand Name:
-
OGJG
-
Input Voltage(V):
-
100-277
-
Working Lifetime(Hour):
-
50000
-
Product Name:
-
over bed head lamp
-
Power factor:
-
up 10W down 20W /up 20w down 20W
-
LED Type:
-
SMD-2835
-
Color Temperature(CCT):
-
3000k 4000k 5000k 6500k
-
CRI:
-
>83Ra
-
Length:
-
2ft 4ft 5ft 8ft
-
Material:
-
Alumimum + PC
-
Function:
-
Dimming/4-step switch
-
Application:
-
hospital/ dormitory/bedroom
-
Lamp Body Material:
-
Aluminum+PC
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
105
-
IP Rating:
-
IP40
-
CRI (Ra>):
-
83
-
Place of Origin:
-
Other Country
-
Model Number:
-
NBPC-2
-
Brand Name:
-
OGJG
-
Input Voltage(V):
-
100-277
-
Working Lifetime(Hour):
-
50000
-
Product Name:
-
over bed head lamp
-
Power factor:
-
up 10W down 20W /up 20w down 20W
-
LED Type:
-
SMD-2835
-
Color Temperature(CCT):
-
3000k 4000k 5000k 6500k
-
CRI:
-
>83Ra
-
Length:
-
2ft 4ft 5ft 8ft
-
Material:
-
Alumimum + PC
-
Function:
-
Dimming/4-step switch
-
Application:
-
hospital/ dormitory/bedroom
-
Lamp Body Material:
-
Aluminum+PC
Specification
|
Setting Information
|
|
|
|
Model
|
NBPC2
|
|
|
Input Voltage
|
100~270VAC
|
|
|
Housing
|
aluminum
|
|
|
IP
|
40
|
|
|
LED
|
Epistar
|
|
|
CCT
|
3000k/ 4000k/ 5000k/ 6500k
|
|
|
CRI
|
>83
|
|
|
Warranty
|
5 years
|
|
Product Description
With press type terminal block, led strips are replaceable Epistar SMD 2835 led chips, over 105 lm/W
We have been specializing in lighting manufacturing for over 11 years in China.
Experienced in R&D, production and exporting of full range of Led lights.
We promise 50000H 3 years warranty for our LED tube.
Any defective products within warranty will get maintenance or replacement unconditionally.
|
Model
|
Wattage
|
Size
|
Dimension(mm)L*W*H
|
Lumens
|
|
OG-LED210-NBPC(2)
|
20W
|
2'
|
580X133X60
|
2100lm/2600lm
|
|
OG-LED220-NBPC-2(2)
|
40W
|
2'
|
580X133X60
|
4800lm
|
|
OG-LED220-NBPC(2)
|
40W
|
4'
|
1190X133X60
|
4200lm/5200lm
|
|
OG-LED230-NBPC-4(2)
|
60W
|
4'
|
1190X133X60
|
7200lm
|
|
OG-LED225-NBPC(2)
|
50W
|
5'
|
1470X133X60
|
5250lm/6500lm
|
|
OG-LED230-NBPC(2)
|
60W
|
5'
|
1470X133X60
|
6300lm/7800lm
|
|
OG-LED245-NBPC(2)
|
90W
|
5'
|
1470X133X60
|
11250lm
|
|
OG-LED250-NBPC(2)
|
100W
|
5'
|
1470X133X60
|
12500lm
|
|
OG-LED240-NBPC(2)
|
80W
|
8'
|
2370X133X60
|
8400lm/10400lm
|
|
OG-LED260-NBPC(2)
|
120W
|
8'
|
2370X133X60
|
14400lm
|
