Quick Details
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Online support
-
Brand Name:
-
Sinotruk HOWO
-
Model:
-
ZZ1047D3414C145
-
Place of Origin:
-
China
-
Dimensions (L x W x H) (mm):
-
5995*2150*2450mm
-
Box Dimensions (L x W x H) (mm):
-
4500*2050*2150mm
-
Temperature Range:
-
-18℃
-
Product name:
-
Refrigerator truck
-
Drive Type:
-
Howo 4x2 light
-
Engine Brand:
-
YN38PE-1, 116hp, Euro III
-
Tire Specification:
-
8.25R16 Steel tire
-
Gear Box:
-
6 speed forward with 2 reverse, manual
-
Suspension:
-
Steel spring suspension
-
Box dimension(mm):
-
4500*2050*2150mm
-
Box material:
-
fiberglass, middle is 80mm polyurethane foam
-
Refrigerator unit brand:
-
China Huan Ya
-
Temperature:
-
-18℃
Quick Details
-
Condition:
-
New
-
Emission Standard:
-
Euro 3
-
Gross Vehicle Weight:
-
5-10T
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Online support
-
Brand Name:
-
Sinotruk HOWO
-
Model:
-
ZZ1047D3414C145
-
Place of Origin:
-
China
-
Dimensions (L x W x H) (mm):
-
5995*2150*2450mm
-
Box Dimensions (L x W x H) (mm):
-
4500*2050*2150mm
-
Temperature Range:
-
-18℃
-
Product name:
-
Refrigerator truck
-
Drive Type:
-
Howo 4x2 light
-
Engine Brand:
-
YN38PE-1, 116hp, Euro III
-
Tire Specification:
-
8.25R16 Steel tire
-
Gear Box:
-
6 speed forward with 2 reverse, manual
-
Suspension:
-
Steel spring suspension
-
Box dimension(mm):
-
4500*2050*2150mm
-
Box material:
-
fiberglass, middle is 80mm polyurethane foam
-
Refrigerator unit brand:
-
China Huan Ya
-
Temperature:
-
-18℃
Product Description
![](https://cdn.bestsuppliers.com/seo_products_img/cdtrucks/c47a345835c5352cb5e69db6d9916311.png!/rotate/180)
Specification
MANUFACTURE DATE
制造时间 |
|
2022
|
|
||
OVERALL DEMENSION
整车尺寸 |
MM
毫米 |
5995×2020×3100
|
|
||
CURB WEIGHT
整备重量 |
KG
千克 |
3500
|
|
||
LOADING CAPACITY
载 重 |
KG
千克 |
4000
|
|
||
MAX GRADABILITY WHEN FULL LOADING
最大负载时最大爬坡度 |
DEG
度 |
32°
|
|
||
MAX SPEED
最大时速 |
KM/H
千米/时 |
90
|
|
||
FRONT/REAR HANGING
前悬/后悬 |
MM
毫米 |
1032/1663
|
|
||
CLOSE/DEPARTURE ANGLE
接近角/离去角 |
DEG
度 |
19/10
|
|
||
LEAF SPRING
钢板弹簧片数 |
PCS
片 |
11/9+7
|
|
||
DRIVE WHEEL
驱动轮 |
|
4*2
|
|
||
CHASSIS MODEL
底盘型号 |
|
EQ1060TJ20D3(DongFeng)
|
|
||
MANUFACTURER
制造商 |
|
DongFeng Motors Co.,Ltd.
东风铃汽车(集团)有限公司 |
|
||
MANUFACTURE DATE
制造时间 |
|
2022
|
|
||
POWER STEERING 方向助力
|
|
Equipped
|
|
||
WHEELBASE
轴距 |
|
3300
|
|
||
REAR AXLE 后桥
|
|
3T
|
|
||
TYRE SPECIFICATION
轮胎规格 |
|
7.00R16
|
|
||
NO OF TYRES
轮胎数 |
PCS
条 |
6+1 spare tyre
|
|
||
ENGINE MODEL
发动机型号 |
CY4100Q
|
|
|
||
MANUFACTER
厂商 |
DongFeng Chaoyang Power Co., Ltd
东风朝阳朝柴动力有限公司 |
|
|
||
ENGINE HORSEPOWER
发动机功率 |
PS
马力 |
82
|
|
||
DISPLACEMENT
排量 |
ML
毫升 |
3707
|
|
||
EMISSION STANDARD
排放标准 |
Euro III
|
|
|
||
ENGINE DETAILS MORE
发动机特性 |
|
|
|
||
|
|
|
|
||
|
|
|
|
||
NO OF GEARS
档位数 |
5 forward gears and 1 reverse
|
|
|
||
RATIO
速比 |
4.875
|
|
|
||
BRAND
品牌 |
CLW
|
|
|
||
BODY DIMENSION
货箱尺寸 |
MM 毫米
|
4200×2080×3020
|
|
||
THICKNESS 厚度
|
MM 毫米
|
Polyurethene foam :80mm Fiberglass :1.4mm Plywood:18mm
|
|
||
TEMPERATURE 温度
|
℃ 摄氏度
|
-18
|
|
||
UNIT 冷藏机组
|
|
Thermo king-RV380
|
|
||
SIDE DOOR 侧门
|
|
according to your order
|
|
||
MATIRAL OF DOORFRAME 门框材质
|
|
Stainless steel
|
|
||
MATERAIL
材质 |
|
In the middle of Polyurethene foam,Exterior and inner side: fiberglass
|
|
||
MODEL 款式
|
DONGFENG-Single Cabin
|
|
|
||
STEERING 转向
|
Left hand drive
|
|
|
||
TYPE 类型
|
Flat proof
|
|
|
||
COLOR 颜色
|
According to you
|
|
|
||
SEATS 座位
|
3
|
|
|
||
A/C 空调
|
Equipped
|
|
|
||
OTHERS 其他
|
With FM RADIO,CD,Spare tire stents and so on
|
|
|
More details
![](https://cdn.bestsuppliers.com/seo_products_img/cdtrucks/f7599d229d3d36f1996cbcca16c413ce.jpg!/rotate/180)
![](https://cdn.bestsuppliers.com/seo_products_img/cdtrucks/a5b6d323057f3d23ad0e3f8297c1be0a.jpg!/rotate/180)
![](https://cdn.bestsuppliers.com/seo_products_img/cdtrucks/16fbfe2358aa3c47a4b1ff79dead4ff3.jpg!/rotate/180)
The integrated structure design of the whole vehicle has a novel and elegant appearance. Convenient for urban road travel and
meet the needs of refrigerated insulation in the long and short distance transportation.
meet the needs of refrigerated insulation in the long and short distance transportation.
Refrigeration and thermal insulation box has the advantages of good air tightness, good
thermal insulation, high strength, light weight, corrosion resistance, good thermal insulation performance and long life. Among
them, the air-tight performance of the refrigerated and insulated box is in accordance with national standards, and the total heat
transfer coefficient reaches the level I standard.
thermal insulation, high strength, light weight, corrosion resistance, good thermal insulation performance and long life. Among
them, the air-tight performance of the refrigerated and insulated box is in accordance with national standards, and the total heat
transfer coefficient reaches the level I standard.
There is a ceiling light device inside the car body for use at night; red and white
indicator lights are installed on the front and rear of the top of the car body; side indicator lights are installed on the lower
part of the car body; reflectors are installed on the rear of the vehicle to ensure Vehicle driving safety.
indicator lights are installed on the front and rear of the top of the car body; side indicator lights are installed on the lower
part of the car body; reflectors are installed on the rear of the vehicle to ensure Vehicle driving safety.
