Quick Details
-
Brand Name:
-
SINOMADA
-
Model Number:
-
SD8N
-
Dimension(Long * Breadth * High):
-
7930*3940*3549mm
Quick Details
-
Machine Weight:
-
37300 KG
-
Dozing Capacity:
-
11.24cbm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SINOMADA
-
Model Number:
-
SD8N
-
Dimension(Long * Breadth * High):
-
7930*3940*3549mm
Contact Me
Ellie Hu
Phone / Whatsapp: +86-17373130042
Facebook: Wenjuan Hu
Instagram: Sakura-Wangwang
Pls feel free to contact me if you need more information. Looking forward to your news!
Product Description
Technical Characteristics:
* The appearance of the vehicle is based on optimization design.
* High engine power reserve, strong torque output, low fuel consumption, reliable controls.
* Hydraulically powered, automatic speed change, shift the gears without stop the vehicle.
* 3 elements, single stage and single phase torque convertor features high efficiency and capacity.
* The updated hexahedral cab features outstanding visibility and good tightness.
* Using the triangle spline and the gear of crowned teeth and tip relief in the final drive to average the loads on the trans-mission components for more stability, prolong the lifetime.
* New blade is more durable and capacious.
* Alarming & monitoring system is reliable.
* Reliable manual- operated spool valve and external mounted valve for easy maintenance.
Parameters
| SPECIFICATION | |||||
| Operation weight,(including ripper) (Kg) | 37300 | ||||
| Ground pressure(KPa) | 94 | ||||
| Track gauge(mm) | 2083 | ||||
| Gradient | 30°/25° | ||||
| Min. ground clearance (mm) | 556 | ||||
| Dozing capacity (m³) | 11.24 | ||||
| Blade width (mm) | 3940 | ||||
| Max. digging depth (mm) | 582 | ||||
| Overall dimensions (mm) (including ripper) | 7930×3940×3549 | ||||
| Engine | |||||
| Type | NTA855-C360S10 | ||||
| Rated revolution (rpm) | 2100 | ||||
| Rated power (KW) | 257 | ||||
| Torque storage coefficient | 20% | ||||
| Undercarriage system | |||||
| Type | The track is triangle shape. The sprocket is elevated elastic suspended. | ||||
| Number of track rollers (each side) | 8 | ||||
| Pitch (mm) | 216 | ||||
| Width of shoe (mm) | 560 | ||||
| Gear | 1st | 2nd | 3rd | ||
| Forward (Km/h) | 0-3.5 | 0-6.2 | 0-10.8 | ||
| Backward (Km/h) | 0-4.7 | 0-8.1 | 0-13.9 | ||
| Implement hydraulic system | |||||
| Max. system pressure (MPa) | 20 | ||||
| Control type | Pilot control | ||||
| System output(L/min) | 220 | ||||
| Driving system | |||||
| Torque converter | Torque converter is power separating hydraulic-mechanic type | ||||
| Transmission | Planetary, power shift transmission, with three speeds forward and three Speeds reverse, speeds and Direction can be quickly shift | ||||
| Steering clutch |
The steering clutch is hydraulic
pressed, non-constant engaged clutch. |
||||
| Steering braking clutch | The braking clutch is pressed by spring, separated hydraulic, constant meshed type. | ||||
| Final drive | The final drive is two-stage planetary reduction gear mechanism, splash lubrication. | ||||
