Quick Details
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
-
Name:
-
Light Stone Tombstone Engraving Carving Machine For Sale
-
Processing stroke:
-
1300*2500mm
-
Feed height:
-
200mm CNC router machine
-
Spindle speed:
-
6000-24000r/min
-
Number of spindles:
-
1pcs cnc acrylic laser engraving machine price
-
Shank diameter:
-
ER20,3,4 ,6,12
-
Fixed way:
-
Manual platen
-
Oil filling system:
-
Manual oiling Light Duty Stone CNC Engraving machine
-
Transfer method:
-
High precision rack and pinion drive
Quick Details
-
Engraving Area:
-
1300*2500mm
-
Laser Type:
-
Diode
-
Engraving Speed:
-
12m/min
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
-
Name:
-
Light Stone Tombstone Engraving Carving Machine For Sale
-
Processing stroke:
-
1300*2500mm
-
Feed height:
-
200mm CNC router machine
-
Spindle speed:
-
6000-24000r/min
-
Number of spindles:
-
1pcs cnc acrylic laser engraving machine price
-
Shank diameter:
-
ER20,3,4 ,6,12
-
Fixed way:
-
Manual platen
-
Oil filling system:
-
Manual oiling Light Duty Stone CNC Engraving machine
-
Transfer method:
-
High precision rack and pinion drive
1325 Factory Supply High Precision CNC Numerical Control Light Stone Tombstone Engraving Carving Machine For Sale
Product Description&Features of Light Stone Engraving Machine:
1.The 1325 light stone engraving machine uses a high-power waterproof spindle.
2. Equipped with flushing system and water tank, it can effectively reduce the breakage of the cutter during the engraving process and prevent dust pollution.
3. Realized the mechanization and automatic production of stone carving products, greatly improving the efficiency.
4. Applicable materials: stone carving of granite, marble, bluestone, sandstone, glass, etc., metal engraving such as copper, aluminum and iron. For example: tea trays, metal carving crafts, stone lettering, relief, cutting, etc.
5. Advertising, woodworking, light stone, copper, aluminum and other metals can be engraved. It has a wide range of applications and can achieve low investment and high return.
|
Technical Parameters of Light Stone Engraving Machine |
|
|
Model |
1325 Light stone engraving machine |
|
Processing stroke |
1300*2500mm |
|
Feed height |
200mm |
|
Bed design |
The heavy six-legged bed is sturdy and does not deform, and the leg of the bed is 200*200mm.Stable landing |
|
Gantry design |
The whole system comes standard with 250*150mm square large gantry, widened and thickened to effectively reduce resonance |
|
Countertop |
Aluminum profile countertop with 8mm PVC protection |
|
Track type |
Square rail 20 track, fine and smooth |
|
Slider type |
20 slider |
|
Rack type |
High-precision 1.25-die rack with high precision and high wear resistance |
|
transfer method |
High precision rack and pinion drive |
|
Cabinet type |
Optional (built-in cabinet or stand-alone cabinet) |
|
Oil filling system |
Manual oiling |
|
motor |
Chuangwei 860 stepping |
|
Spindle type |
220V/380V.3.7KW Water-cooled spindle with strong cutting force, low noise and durability |
|
Spindle speed |
6000-24000r/min |
|
Spindle power |
220V/380V.3.7KW |
|
Number of spindles |
1 pcs |
|
Other power |
600w |
|
Frequency converter |
TAILAN |
|
Electrical components |
ZHENGTAI |
|
operating system |
Weihong control system, easy to learn, compatible with Wentai, carved, etc. |
|
Operating software |
Beijing Jingdiao, Wentai |
|
Maximum operating speed |
12m/min |
|
Engraving instruction |
G code [nc],mmg,PIt,eng,dxf |
|
Operating Voltage |
220V/380V |
|
Shank diameter |
ER20,Φ3,Φ4 ,Φ6,Φ12 |
|
Fixed way |
Manual platen |
|
Vacuum pump |
No |
|
vacuum cleaner |
Optional |
More details:
Finished product:
WHY DO YOU CHOOSE US?
BECAUSE
1.Better Material:
We choose better materials in the market to produce, improve the quality from the source, for your escort along the way.
2.Fine Workmanship:
We have standardized production process, strict supervision mechanism and constantly updated product technology.
3.Quality Guarantee:
Before leaving the factory, our products are strictly tested and the quality of each product is guaranteed.
4.Rest Assured After-sales:
We are a large manufacturer, there are specialized after sales and maintenance personnel, can reduce the customer's concern, welcome the customer to visit the factory to discuss.
