Quick Details
-
Model Number:
-
DS1825+KCD1-8-101EN+DJ622-J4.8A
-
Max. Current:
-
20A
-
Mechanical Life:
-
10000cycles
-
Product type:
-
ON OFF Round Rocker Switch
-
Rating:
-
20A 12VDC; 10A 24VDC
-
LED Color:
-
Red dot illuminated LED
-
Function:
-
3 pin SPST ON OFF
-
Connector Type:
-
Crimp
-
Round Shell:
-
nylon PA66
-
Terminals:
-
brass, silver plated
-
Note:
-
Only DC voltage is available
-
Package:
-
round LED rocker switch *1 + Shell *1 + 3 wires
-
Application:
-
widely used in 12V-24V Car, Automotive, Truck, and other equipments
-
Certification:
-
CE
Quick Details
-
Max. Voltage:
-
24VDC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Daiertek
-
Model Number:
-
DS1825+KCD1-8-101EN+DJ622-J4.8A
-
Max. Current:
-
20A
-
Mechanical Life:
-
10000cycles
-
Product type:
-
ON OFF Round Rocker Switch
-
Rating:
-
20A 12VDC; 10A 24VDC
-
LED Color:
-
Red dot illuminated LED
-
Function:
-
3 pin SPST ON OFF
-
Connector Type:
-
Crimp
-
Round Shell:
-
nylon PA66
-
Terminals:
-
brass, silver plated
-
Note:
-
Only DC voltage is available
-
Package:
-
round LED rocker switch *1 + Shell *1 + 3 wires
-
Application:
-
widely used in 12V-24V Car, Automotive, Truck, and other equipments
-
Certification:
-
CE
PRODUCT DESCRIPTION
|
lItem
|
12V Lighted 3 Pin SPST ON OFF Round Rocker Switch Shell With Red LED Rocker Toggle Switch For Automotive Car Truck Boat
|
|
Switch Function
|
3 Pin SPST ON OFF
|
|
Switch Type
|
Dot Lighted RED led
|
|
Rating
|
20A 12VDC; 10A 24VDC
|
|
LED
|
12V Blue
|
|
Package
|
1 x round LED rocker switch
1 x Shell
3 x wires
|
PRODUCT DETAILS
ON OFF ROUND ROCKER SWITCH WITH WIRES
* Features: A dot LED light is designed to be embedded in the round rocker switch, which is available in blue color. The LED light will be on when the switch is on.
* Material: The round 12 Volt rocker switch shell is made of nylon 66. The terminal is made of brass, silver plated.
* Function: The round rocker switch has 3 pins, and SPST (single pole single throw) design with a set of jumpers, easy to turn ON/ OFF. The rating is 20A 12VDC.
* Installation: The mounting hole size of the round rocker switch shell is 29mm (about 1.14 inches), if you remove the shell, the mounting hole size will be 20mm (about 0.79 inch).
* Application: The round 12V rocker switch is widely applied to automotive, race cars, RVs, marine, heavy duty trucks, off road vehicles, ATVs, and nearly everything that uses a 12V power source.
* Material: The round 12 Volt rocker switch shell is made of nylon 66. The terminal is made of brass, silver plated.
* Function: The round rocker switch has 3 pins, and SPST (single pole single throw) design with a set of jumpers, easy to turn ON/ OFF. The rating is 20A 12VDC.
* Installation: The mounting hole size of the round rocker switch shell is 29mm (about 1.14 inches), if you remove the shell, the mounting hole size will be 20mm (about 0.79 inch).
* Application: The round 12V rocker switch is widely applied to automotive, race cars, RVs, marine, heavy duty trucks, off road vehicles, ATVs, and nearly everything that uses a 12V power source.
Function
The toggle switch with 12 Volt Red LED illuminated. The LED will be lighted to indicate the operating status of the device when the switch ON.
Design
The Shell converts the Snap-in installation of the switch into a nut installation and conforms to the standard panel installation
size.
size.
Application
Widely used in a variety of applications including Automotive, Race Car, RV, Marine, Truck, ATV, Off-Road Vehicles and etc.
