Quick Details
-
Dimension(L*W*H):
-
According to Product Model
-
Weight:
-
750 KG, 750
-
Bandwidth:
-
500mm
-
Model:
-
RCYD(C)-5
-
Magnetic Field Strength:
-
≥60mT
-
Material Thickness:
-
<80mm
-
Hang high:
-
150mm
-
Drive Power:
-
1.5kw
-
Work system:
-
continuous
-
Adapt Belt speed:
-
≤4.5m/s
Quick Details
-
Production Capacity:
-
100%
-
Place of Origin:
-
Shandong, China
-
Voltage:
-
110/220V/380V
-
Dimension(L*W*H):
-
According to Product Model
-
Weight:
-
750 KG, 750
-
Bandwidth:
-
500mm
-
Model:
-
RCYD(C)-5
-
Magnetic Field Strength:
-
≥60mT
-
Material Thickness:
-
<80mm
-
Hang high:
-
150mm
-
Drive Power:
-
1.5kw
-
Work system:
-
continuous
-
Adapt Belt speed:
-
≤4.5m/s
Products Description
Suspension Type Iron Magnetic Drum Light Weight Over Belt Electromagnetic Separator Iron Remover
Iron remover is a kind of equipment that can generate strong magnetic attraction. It can remove ferromagnetic impurities mixed in materials, so as to ensure the safe and normal operation of crushers, grinders and other mechanical equipment in the conveying system. At the same time, it can effectively prevent the accident of cracking the conveying belt due to large and long iron parts zmwm02
Product Paramenters
Suspension Type Iron Magnetic Drum Light Weight Over Belt Electromagnetic Separator Iron Remover
According to its iron unloading mode, it can be divided into manual iron unloading, automatic iron unloading and program-controlled iron unloading. Due to different application occasions and magnetic circuit structure, various series of products have been formed.
|
Parameter
|
Bandwidth
|
Hang high
|
Thickness
|
Strength
|
Power
|
Belt
|
system
|
Kg
|
|
Project
|
mm
|
h=mm
|
≤mm
|
≥mT
|
≤KW
|
Speed
|
|
|
|
|
|
|
|
|
|
≤m/s
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RCYD(C)-5
|
500
|
150
|
80
|
60
|
1.5
|
4.5
|
continuous
|
750
|
|
RCYD(C)-6
|
600
|
175
|
120
|
60
|
1.5
|
|
|
920
|
|
RCYD(C)-6.5
|
650
|
200
|
150
|
70
|
2.2
|
|
|
1200
|
|
RCYD(C)-8
|
800
|
250
|
200
|
70
|
2.2
|
|
|
1400
|
|
RCYD(C)-10
|
1000
|
300
|
250
|
70
|
3
|
|
|
2120
|
|
RCYD(C)-12
|
1200
|
350
|
300
|
70
|
4
|
|
|
3350
|
|
RCYD(C)-14
|
1400
|
400
|
350
|
70
|
4
|
|
|
4450
|
|
RCYD(C)-16
|
1600
|
450
|
400
|
70
|
5.5
|
|
|
6200
|
|
RCYD(C)-18
|
1800
|
500
|
450
|
72
|
7.5
|
|
|
8100
|
|
RCYD(C)-20
|
2000
|
550
|
500
|
72
|
11
|
|
|
9700
|
Details Images
Suspension Type Iron Magnetic Drum Light Weight Over Belt Electromagnetic Separator Iron Remover
