Quick Details
-
Structure:
-
Control
-
Warranty:
-
1 years
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
BNDZKYB
-
Model Number:
-
DZW-45
-
Port Size:
-
Customized according to customer requirements
-
Torque:
-
200~2500N.M
-
Link mode:
-
Direct connection type, base type
-
Switching mode:
-
Switching type, regulating type
-
Supply voltage:
-
380V
-
Control signal:
-
4-20 MA, passive switching, 485 COMM, Modbus COMM, 220V switching
-
Feedback signal:
-
Analog signal 4-20mA, open source switching quantity
-
Electrical interface:
-
2-M22*1.5/2-M27*1.5
-
Protection level:
-
IP65
-
Explosion-proof rating:
-
BT4
-
Control mode:
-
Local control, remote control, remote control
Quick Details
-
Type:
-
Gate Valves, Globe Valves
-
Application:
-
General
-
Power:
-
Electric
-
Structure:
-
Control
-
Warranty:
-
1 years
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
BNDZKYB
-
Model Number:
-
DZW-45
-
Port Size:
-
Customized according to customer requirements
-
Torque:
-
200~2500N.M
-
Link mode:
-
Direct connection type, base type
-
Switching mode:
-
Switching type, regulating type
-
Supply voltage:
-
380V
-
Control signal:
-
4-20 MA, passive switching, 485 COMM, Modbus COMM, 220V switching
-
Feedback signal:
-
Analog signal 4-20mA, open source switching quantity
-
Electrical interface:
-
2-M22*1.5/2-M27*1.5
-
Protection level:
-
IP65
-
Explosion-proof rating:
-
BT4
-
Control mode:
-
Local control, remote control, remote control
|
Product parameters
|
|
|
|
|
||||
|
Model
|
DZW-20 | DZW-30 | DZW-45 | DZW-60 | DZW-90 | DZW-120 | DZW-180 | DZW-250
|
|
|
|
||||
|
Output Torque
|
50Nm | 160Nm | 200Nm | 250Nm | 500Nm | 600Nm | 1000Nm
|
|
|
|
||||
|
Cycle Time
|
18r/min | 24r/min | 36r/min
|
|
|
|
||||
|
Rotation
|
360°
|
|
|
|
||||
|
Switch mode
|
Switching type, regulating type
|
|
|
|
||||
|
Rated Current
|
0.57A | 1.03A | 1.38A | 2.2A | 2.62A | 4A | 4.12A | 5.25A | 7.9A | 8.87A | 12.05A | 15.6A | 20.5A | 26.6A
|
|
|
|
||||
|
Motor Power
|
0.12KW | 0.25KW | 0.37KW | 0.55KW | 0.75KW | 1.1KW | 1.5KW | 2.2KW | 3KW | 4KW | 5.5KW | 7.5KW | 10KW | 15KW |
|
|
|
|
||||
|
Voltage Options
|
380VAC
|
|
|
|
||||
|
Input Signal
|
Passive switching quantity, 220V switching quantity, analog 4~20mA, 485 communication
|
|
|
|
||||
|
Output Signal
|
Analog signal 4-20 MA, open switch quantity
|
|
|
|
||||
|
Maximum stem diameter
|
28mm | 40mm | 48mm | 60mm | 70mm | 80mm |
|
|
|
|
||||
|
Control mode
|
Local control, remote control, remote control
|
|
|
|
||||
|
Explosion-proof grade
|
ExdⅡBT4Gb
|
|
|
|
||||
|
Protection grade
|
IP65
|
|
|
|
||||
FAQ
Q1:What are your main products?
A: Our main products are electric actuators, butterfly valves and gate valves.
Q2:Are you a traderor a manufacturer? Do you have a factory?
A: We are actuator manufacturer, we have experienced team to do custom products, we haveour own factory and production line.
Q3:If you select the actuator
A: We need you to provide the torque (torque), if you don'tknow, the valve diameter, and the valve interface drawing.
Q4:How do you guarantee quality?
A: We have our own quality control. Every product is controlled and tested before it leaves the factory and we offer A 12-month guarantee.
Q5:When can I receive theprice?
A: We will make an offer within 12 hours after receiving your inquiry. If it's an emergency, you can call us.
Q6:How do Iorder our valves and actuators?
A: Please send your inquiry to us via Email, Whatsapp, wechat, etc. We need to know the followinginformation before formal quotation.
1) Actuator: Actuator parameters, with what valve to use, use environment, temperature,special requirements.
2) valves: Valve flow medium, flow medium temperature, valve parameters.
Q7:How can I get a sample to check
your quality? A: Contact our sales specialists to arrange sample delivery. Please send us the details of the sample before placingorder.
your quality? A: Contact our sales specialists to arrange sample delivery. Please send us the details of the sample before placingorder.
Q8:If we place a formal order, what about the delivery date?
A: We have regular inventory of conventional products, and thesmooth delivery period is 3-7 days. If you need to customize production, communicate with sales experts to determine the specificdelivery time.
