Quick Details
-
Voltage:
-
220v/380v
-
Weight (KG):
-
800
-
Power (kW):
-
3
Quick Details
-
Wheel Size(mm):
-
150
-
Place of Origin:
-
China
-
Brand Name:
-
hoyongtrd
-
Voltage:
-
220v/380v
-
Weight (KG):
-
800
-
Power (kW):
-
3
FG500 Flywheel Grinding Machine
Product Description：
Use and performance of the vehicle repair industry is grinding to repair the vehicle flywheel special machine tools, has a simple structure and reliable performance characteristics such as grinding may be less than the diameter of the fly wheel 500mm, The rigid machine tool performance, the work of high precision, fast speed, processing efficient, simple and convenient maintenance is and ideal tool for special flywheel grinding. The type of grinding machine Tool grinder.
|
Model
|
FG500
|
|
Max. machine diameter of workpiece
|
φ500 mm
|
|
Rotating worktable diameter
|
φ450 mm
|
|
Space from worktable surfac to the end surfac of grinding wheel
|
0-200 mm
|
|
Grinding wheel diameter
|
φ150 mm
|
|
Speed of worktable
|
17/34 r/min
|
|
Speed of grinding wheel
|
2800 r/min
|
|
Motor power of grinding head
|
3 Kw
|
|
Motor power of worktable
|
0.4 Kw
|
|
Motor power of cooling pump
|
0.12 Kw
|
|
Overall dimensions(LxWxH)
|
1200x800x1750 mm
|
|
Packing dimensions(LxWxH)
|
1530x1030x2000 mm
|
|
N.W./G.W.
|
600/800 Kg
|
