Quick Details
-
Warranty(Year):
-
2-Year
-
Input Voltage(V):
-
12V/24V
-
Lamp Luminous Flux(lm):
-
1000~2000lm
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 40
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
shanghai
-
Brand Name:
-
Edgelight
-
Model Number:
-
Edgelux panel(600*300mm)
-
Item Type:
-
LED Panel light
-
Warranty(Years):
-
2
-
Certification:
-
CCC, GOST, LVD, RoHS, UL
-
Installation Method:
-
ceiling or hangng
-
key words:
-
led acrylic panel
-
Shape:
-
Customized
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
50
-
Application:
-
Home Office
-
Lamp Body Material:
-
ABS
-
Warranty(Year):
-
2-Year
-
Input Voltage(V):
-
12V/24V
-
Lamp Luminous Flux(lm):
-
1000~2000lm
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 40
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
shanghai
-
Brand Name:
-
Edgelight
-
Model Number:
-
Edgelux panel(600*300mm)
-
Item Type:
-
LED Panel light
-
Warranty(Years):
-
2
-
Certification:
-
CCC, GOST, LVD, RoHS, UL
-
Installation Method:
-
ceiling or hangng
-
key words:
-
led acrylic panel
-
Shape:
-
Customized
Internal thickness only 3mm, external thickness 8mm, ultra-thin and light
Compact, reduces transport costs
High quality heat sink preserves the life span of your product
Fast activation function, no flickering.
Uses high quality PMMA material, 90% light output
| 12v/24V dc led light panel | |||||||||
| Material | acrylic LGP ,aluminum frame | Shape | Rectangle,square,customized shape | ||||||
| Power | 2W-120W | LGP Technology | Laser dotting,V-Cutting engraving | ||||||
| Light Source | SMD 3528/2835/5050/3535 LED strips | Thickness | 2/3/4/5/6/8/10/20mm | ||||||
| Voltage | 12V/24V | Visible Surface | single/double | ||||||
| Package | bubble bag , cartons , wood box for long distance transport | ||||||||
| Item | Frame size(mm) | Viewing size(mm) | LED strip description | ||||||
| Length | Width | Thickness | Length | Width | Voltage(V) | Power(W) | Lighting side | Q'ty/pcs | |
| A4 | 297 | 210 | 8 | 273 | 186 | 12&24 | 2.61 | 297 | 1 |
| A3 | 420 | 297 | 8 | 396 | 273 | 12&24 | 5.19 | 420 | 1 |
| A2 | 594 | 420 | 8 | 570 | 396 | 12&24 | 14.4 | 594 | 2 |
| A1 | 841 | 594 | 8 | 817 | 570 | 12&24 | 17.6 | 841 | 2 |
| The size can be customized | |||||||||
Our Services
Our Service :
1. We are factory: our factory address is: NO.55,Beimin Road, Songjiang District, Shanghai, China
1) You can visit our workshop, to know every details.
2) We have more than 15 years rich Experience to make light box
3) Our Laser engraving worker had more than 15 years Experience
4) We have Strong after sale service team best service for you.
2. Low MOQ : we have special MOQ, small quantity or sample are accepted.
3. Show Room We have a big showroom with our latest developed products.
4. Good Quality : We have high level quality control system same as car factory. With good quality, we can serve customer better in the market.
5. Fast & Cheap Delivery : We have high efficiency production system. The lead time for samples is only 2 – 3 working days, the lead time for quantity orders is 10 –
20 working days.
6. Low Prices : As our production quantity are large, we can get a lower prices from suppliers about raw material. So we can give you a good price under good quality.
7.OEM Service : Besides our standard design , customized service we also can offer , absolutely follow your advice
8 . Professional Service : We have professional Sales team which have rich experience about products and export for you service 24 hour online.
