1) Nude Solar Panel Electrical Performance:
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
LL-YT400W
-
Maximum Output Power:
-
420W
-
Place of Origin:
-
Guangdong, China
-
Character:
-
Ultra thin and light
-
OEM/ODM:
-
Acceptale
-
Weight:
-
9.8KG
-
Folded Size:
-
59*93*5CM/23.23*36.61*1.97inch
-
Unfolded Size:
-
233.8*93CM/92.05*36.61inch
-
Net Weight:
-
9.86KG/11.66Ibs
-
Certification:
-
UL CE ROHS FCC PSE
-
Patent:
-
With EU and USA patent
-
Efficiency:
-
23%
Quick Details
-
Type:
-
Electric, Power Supply Adapter, CAR CHARGER, Fast Charger
-
Port:
-
DC
-
Brand Name:
-
LLsolar
-
Model Number:
-
LL-YT400W
-
Maximum Output Power:
-
420W
-
Place of Origin:
-
Guangdong, China
-
Character:
-
Ultra thin and light
-
OEM/ODM:
-
Acceptale
-
Weight:
-
9.8KG
-
Folded Size:
-
59*93*5CM/23.23*36.61*1.97inch
-
Unfolded Size:
-
233.8*93CM/92.05*36.61inch
-
Net Weight:
-
9.86KG/11.66Ibs
-
Certification:
-
UL CE ROHS FCC PSE
-
Patent:
-
With EU and USA patent
-
Efficiency:
-
23%
Parameter:
|
Output Power（@STC ）
|
420.0W ±5%
|
|
Open Voltage（@STC）
|
48.9V ±5%
|
|
Standard Voltage（@STC）
|
40.3V ±5%
|
|
Standard Current（@STC）
|
10.4A ±5%
|
|
Short Circuit（@STC）
|
11.666A ±5%
|
Details shown
1)The Matte ETFE with IP68 waterproof level;
2)The weight is much lighter than many others';
3)The conjunction box is built in the handle with cover to anti-dust and water;
4)waterproof bag can protect accessories well;
3)The conjunction box is built in the handle with cover to anti-dust and water;
4)waterproof bag can protect accessories well;
5)Multiple voltage and port can be widely used for devices;
6)Adjustable kickstand to make the 90 degree between the surface of the solar panel and sunlight;
7)PC handle ,not ABS material and make the handle with long lifespan and anti-aging problem;
8)LLsolar used compound fiber material make the solar panel up to PV professional grade;
9)Copper eyelet left for carabiner to hang.
Conversion Cable Instruction:
1)MC4
2)XT60
3)DC5521
4)DC35135
5)DC6530
6)Anderson
Advantage:
1)11 years' R&D and Manufacture experience;
2)LLsolar with stable supply chain to confirm high quality material used and short leading time;
3)LLsolar solar panel with much longer lifespan;
4)LLsolar solar panel with full power output;
5)LLsolar has our own mould and can help customers mould;
6)LLsolar has full certification,like UL,CE,ROHS,FCC,PSE etc
7)LLsolar has our own EU and USA patent and we can authorize our customer to sell very legally and safely;
8)LLsolar has much shorter leading time,5 days for samples,15-20 days for 500 to 1000PCS;
9)LLsolar solar panel was safe,don't worry the damage of the solar cells to fire at all;
10)LLsolar can offer longer warranty and professional guidance for customers.
3)LLsolar solar panel with much longer lifespan;
4)LLsolar solar panel with full power output;
5)LLsolar has our own mould and can help customers mould;
6)LLsolar has full certification,like UL,CE,ROHS,FCC,PSE etc
7)LLsolar has our own EU and USA patent and we can authorize our customer to sell very legally and safely;
8)LLsolar has much shorter leading time,5 days for samples,15-20 days for 500 to 1000PCS;
9)LLsolar solar panel was safe,don't worry the damage of the solar cells to fire at all;
10)LLsolar can offer longer warranty and professional guidance for customers.
|
Package Information:
|
|
|
|
|||
|
2PCS/CTN
|
Unit Product
|
Unit Product with inner box
|
Unit Carton
|
|||
|
Weight
|
9.86KG/21.69Ibs
|
10.66KG/23.45Ibs
|
11.66KG/25.65Ibs
|
|||
|
Size
|
59.0*93.0*5.0CM/23.23*36.61*1.97Inch
|
98.0*64.2*8.7CM/38.58*25.28*3.43inch
|
99.5*65.7*18.9CM/39.17*25.87*7.44inch
|
|||
FAQ
Q1:Areyou a manufacturing in solar panel industry?
A:We are the manufacturers for 11 years since 2013.
Q2:What are the advantages of your company?
A:1)We have stable supply chain and rich experience;
2)Strong R&D strength;
3)Controll product quality by many process of test;
4)Much Shorter Leading time than many others, less than 5 days for neutral products,15 to 20 days for bulk order.
Q3:Can you supply OEM &ODM service ?
A:Yes, only MOQ regards.
Q4:What’s kind of certificates and patent your products have acquired ?
A:1) Full of CE,ROHS,FCC,PSE,UL.
2)Utility model of China and Appearance Patent of Europe.
Q5:Can I test the sample?
A:Yes,we can supply one sample to test with charge,and refunded of product itself on mass order.
Q6:How can you deal with the anti-dumping on solar to USA?
A: DDP trade term to deliver to your appointed address within 25 days by sea,while 14 days by air,all of the ADD and CVD risk
endured by ourselvies.
Q7:How do you ensure quality?
A: 1)High quality of material;
2)Many test during many manufacture process with quality system enforced;
3)Last test result of 100% products confirmed and sent to customers before package;
4)Rich experience on package of infilling or compact pallet;
Q8:How long is the warranty? How to maintain the quality problem? How to deal with the quality problem?
A:1) We can supply 18 months warranty;
2)For minor problem,guidance to instruct to check and test.New items replacement solution if needed;
Q9:What can be noted when choose different watts of solar panels?
A: We will supply reasonable recommendation when devices demand given ,because of all of our sales have professional training and
rich experience;
Q10:What can be noted when using our solar panel?
A:1)Please unfolded the solar panel first to ensure the sunshine can be aimed at the face of solar panel that the solar cells can
be shown,besides,the solar panel can be taken as a power souce,without power storage function;
2)The solar panel need to be exposed fully under sunshine,not covered by window or put in the shade or inside of house.
Q2:What are the advantages of your company?
A:1)We have stable supply chain and rich experience;
2)Strong R&D strength;
3)Controll product quality by many process of test;
4)Much Shorter Leading time than many others, less than 5 days for neutral products,15 to 20 days for bulk order.
Q3:Can you supply OEM &ODM service ?
A:Yes, only MOQ regards.
Q4:What’s kind of certificates and patent your products have acquired ?
A:1) Full of CE,ROHS,FCC,PSE,UL.
2)Utility model of China and Appearance Patent of Europe.
Q5:Can I test the sample?
A:Yes,we can supply one sample to test with charge,and refunded of product itself on mass order.
Q6:How can you deal with the anti-dumping on solar to USA?
A: DDP trade term to deliver to your appointed address within 25 days by sea,while 14 days by air,all of the ADD and CVD risk
endured by ourselvies.
Q7:How do you ensure quality?
A: 1)High quality of material;
2)Many test during many manufacture process with quality system enforced;
3)Last test result of 100% products confirmed and sent to customers before package;
4)Rich experience on package of infilling or compact pallet;
Q8:How long is the warranty? How to maintain the quality problem? How to deal with the quality problem?
A:1) We can supply 18 months warranty;
2)For minor problem,guidance to instruct to check and test.New items replacement solution if needed;
Q9:What can be noted when choose different watts of solar panels?
A: We will supply reasonable recommendation when devices demand given ,because of all of our sales have professional training and
rich experience;
Q10:What can be noted when using our solar panel?
A:1)Please unfolded the solar panel first to ensure the sunshine can be aimed at the face of solar panel that the solar cells can
be shown,besides,the solar panel can be taken as a power souce,without power storage function;
2)The solar panel need to be exposed fully under sunshine,not covered by window or put in the shade or inside of house.
