Quick Details
-
Row Distance(mm):
-
1800 - 2000 mm
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
no
-
Dimension(L*W*H):
-
700*800*1200mm
-
Weight:
-
275
-
Warranty:
-
1 Year, 1 year
-
After-sales Service Provided:
-
Overseas service center available
-
Product name:
-
paddy wheat reaper grain reaping machine agro harvesting machine
-
Function:
-
Grain Reaper
-
Productivity:
-
≥600m2/h
-
Cutting width (mm):
-
2000mm
-
Power:
-
3.8kw
-
Engine:
-
Gasoline Engine
-
Loss Rate:
-
≤3.5%
-
Broken Rate:
-
≤0.1%
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
Philippines, Indonesia, Bangladesh, Nigeria
Quick Details
-
Number of Rows:
-
1
-
Working Width(mm):
-
200 mm
-
Tractor Power(HP):
-
60 - 75 HP
-
Row Distance(mm):
-
1800 - 2000 mm
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
no
-
Dimension(L*W*H):
-
700*800*1200mm
-
Weight:
-
275
-
Warranty:
-
1 Year, 1 year
-
After-sales Service Provided:
-
Overseas service center available
-
Product name:
-
paddy wheat reaper grain reaping machine agro harvesting machine
-
Function:
-
Grain Reaper
-
Productivity:
-
≥600m2/h
-
Cutting width (mm):
-
2000mm
-
Power:
-
3.8kw
-
Engine:
-
Gasoline Engine
-
Loss Rate:
-
≤3.5%
-
Broken Rate:
-
≤0.1%
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
Philippines, Indonesia, Bangladesh, Nigeria
Fram rice paddy wheat reaper grain reaping machine agro harvesting machine
threshing . Cylinder, and harvester head, thus much more convenient to carry to paddy field where there is no road nearby.
Wide range of application, this item can be both used for dry land and water paddy field. Those big or large harvester cannot work
in water paddy field, as it will get stuck in water paddy field because of its heavy weight, but this 4LZ-0.3 mini harvester has no
such problem, thus it is very suitable for those southeast countries where there are so many water paddy fields
Specification
|
Product name |
grain reaping machine |
||
|
Model |
|||
|
Working Types |
Harvesting rice, operated by one person |
||
|
Weight(kgs) |
275 |
Cutting width(mm) |
1200 |
|
Overall Dimension |
2800×1400×1350(L×W×H)(mm) |
||
|
Packed dimension |
1320*960*1210mm, 1 370*1220*1250mm |
||
|
Engine |
173F(3.8KW) gasoline Engine |
||
|
Harvesting |
Harvester working in Paddy field with paddy working wheel |
||
|
Harvesting Rate |
≤3.5% |
||
|
Broken Rate |
Rate of rice with straw |
≤5% |
|
|
Fuel Consumption |
≤0.8L/H |
Feeding Volume |
0.3kg/s |
Structure
Main five components for this 4LZ-0.3 mini harvester are: harvester head, threshing part,operating part, power system,and walking system.
1. Harvester head consists of head frame, cutting knife, transmission part, convey etc.
2. Threshing part consists of threshing bin, screen, rice output bin, rice barrel, threshing assembly etc.
3. Operating part consists of clutch handle of transmission system, gear level, the gasoline engine throttle lever, regulating handle for head up and down etc.
4. Power system consists of fuel tank, silencer, air filter, starter, PTO shaft etc.
5. Walking system consists of belt transmission clutch, steering clutch for left and right, gear box, walking wheels etc
