Quick Details
-
Brand Name:
-
Kosma
-
After-sales Service Provided:
-
No overseas service provided
-
Material:
-
PP membrane
-
Type:
-
Capsule filter cartridge
-
Certificate:
-
ISO9001
-
Application:
-
printer ink filtration
-
Filter media:
-
PP/PES/PVDF/PTFE/Nylon Membranes for Options
-
Pore size:
-
0.1;0.45;0.65;1;5
-
Connection:
-
1/2" thread connector
Quick Details
-
Weight (KG):
-
1
-
Core Components:
-
filter
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Kosma
-
After-sales Service Provided:
-
No overseas service provided
-
Material:
-
PP membrane
-
Type:
-
Capsule filter cartridge
-
Certificate:
-
ISO9001
-
Application:
-
printer ink filtration
-
Filter media:
-
PP/PES/PVDF/PTFE/Nylon Membranes for Options
-
Pore size:
-
0.1;0.45;0.65;1;5
-
Connection:
-
1/2" thread connector
Products Description
PARAMETER INFORMATION
|
Materials Of Construction
|
Filter Media
|
|
|
|
|
PP/PES/PVDF/PTFE/Nylon Membranes for Options
|
|
|
|
|||||||
|
|
Support Layers
|
|
|
|
|
Polypropylene
|
|
|
|
|||||||
|
|
Inner Core
|
|
|
|
|
Polypropylene
|
|
|
|
|||||||
|
|
Outer Cage, End Cap
|
|
|
|
|
Polypropylene
|
|
|
|
|||||||
|
Cartridge Dimensions
|
Outer Diameter
|
|
|
|
|
65mm(2.5'')
|
|
|
|
|||||||
|
|
Length
|
|
|
|
|
2.5", 5"
|
|
|
|
|||||||
|
|
Connectors
|
|
|
|
|
1/4"MNPT; 1/2"MNPT; 9/16" hose barb; 1.5” Tri Clamp; 1/4"compression joint
|
|
|
|
|||||||
|
|
Filtration Area(m2)
|
|
|
|
|
0.14 m2 to 0.28 m2
|
|
|
|
|||||||
|
Operating Conditions
|
Normal Operating
Temperature |
|
|
|
|
Up to 60℃ (140 ℉ )
|
|
|
|
|||||||
|
|
Max.operating Temperature.
|
|
|
|
|
80℃ (176 ℉ ) at △ P1.0 bar (14.5psi)
|
|
|
|
|||||||
|
|
Normal Flow Direction
|
|
|
|
|
4.2 bar (60.9 psi) at 25℃ (77 ℉ )
|
|
|
|
|||||||
|
|
Reverse Flow direction
|
|
|
|
|
2.1 bar (30.5psi) at 25℃ (77 ℉ ).
|
|
|
|
|||||||
|
|
Sterilization
|
|
|
|
|
Autoclave sterilization 30 minutes,
Gamma-irradiation |
|
|
|
|||||||
