Quick Details
-
Place of Origin:
-
Zhejiang, China
Quick Details
-
Displacement:
-
250cc
-
Brand Name:
-
BossATV
-
Model Number:
-
BS250-7
-
Place of Origin:
-
Zhejiang, China
|
Engine Type |
Single cylinder, liquid-cooled, 4-stroke |
|
Engine Displacement |
250cc |
|
Bore & Stroke |
67x65mm |
|
Compression Ratio |
10:1 |
|
Carburetor |
Carburetor |
|
Max. Power Output |
11.5kW/(7000r/min) |
|
Max. Torque |
18.5N.m/(5500r/min) |
|
Ignition |
CDI |
|
Starter |
Electric start |
|
Drive Train |
|
|
Clutch |
Manual with hand clutch lever. (Semi-automatic without hand clutch lever is available. It is air cooling and the same price.) |
|
Gearbox |
5-speed(four forward gears and one reverse gear, plus neutral gear) |
|
Final Drive |
Shaft drive with rear axle differential mechanism |
|
Dimensions and Weight |
|
|
Length x Width x Height |
1,840 x 1,240 x 1,170mm, height is the handgrip height. |
|
Wheelbase |
1,230mm |
|
Front Tread |
910mm |
|
Rear Tread |
910mm |
|
Seat Height |
890mm |
|
Foot Step to Seat |
480mm |
|
Fuel Capacity |
8L |
|
Dry Weight |
200kg |
|
Wheels, Suspension and Brakes |
|
|
Wheels Front |
12 inch alloy rim |
|
Wheels Rear |
12 inch alloy rim |
|
Tyres Front |
AT25x8-12 |
|
Tyres Rear |
AT25x10-12 |
|
Suspension Front |
Independent single-wishbone |
|
Suspension Rear |
Swing arm with single shock |
|
Brakes Front |
Double hydraulic disc brakes |
|
Brakes Rear |
Double hydraulic disc brakes |
|
Packing |
|
|
Carton Size |
196 x 109 x 83cm, 4 wheels packed separately. |
|
G.W./N.W. |
225/200kg |
|
Container Load |
12pcs/24pcs/30pcs |
