Quick Details
-
Model Number:
-
HI-600B
-
Output Frequency:
-
60/50Hz
-
Size:
-
23*10*6CM
-
Weight:
-
2.5KGS
-
Certificate:
-
CE ROHS
-
Output Power:
-
500 - 1000W
-
Continuous power:
-
600W
-
Peak power:
-
1200W
-
Waveform:
-
Modified sine wave
-
Material:
-
Aluminum cover
-
Packing:
-
1pc/color box
-
Output voltage:
-
230V
-
Efficiency:
-
85%
-
Overloading protection:
-
Short circuit protection
-
Over heating protection:
-
Low and high input voltage protection
Quick Details
-
Output Current:
-
59A
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HONGHUI
-
Model Number:
-
HI-600B
-
Output Frequency:
-
60/50Hz
-
Size:
-
23*10*6CM
-
Weight:
-
2.5KGS
-
Certificate:
-
CE ROHS
-
Output Power:
-
500 - 1000W
-
Continuous power:
-
600W
-
Peak power:
-
1200W
-
Waveform:
-
Modified sine wave
-
Material:
-
Aluminum cover
-
Packing:
-
1pc/color box
-
Output voltage:
-
230V
-
Efficiency:
-
85%
-
Overloading protection:
-
Short circuit protection
-
Over heating protection:
-
Low and high input voltage protection
|
Rated power |
600w |
||
|
Output |
Surge power |
1200w |
|
|
Frequency |
60Hz ± 5 % or 50Hz ± 5 % |
||
|
AC regulation |
± 10 % |
||
|
AC voltage |
100/110/120VAC or 220/230/240VAC ( The specific data is based on the product label) |
||
|
W aveform |
Mo dified sine wave or pure sine wave ( The specific data is based on the product label) |
||
|
Input |
No load-current |
< 0,7 A |
|
|
< 0,8 A |
|||
|
DC voltage |
12V or 24V ( The specific data is based on the product label ) |
||
|
Voltage range |
10~15 VDC or 21~30 VDC or 42-61 VDC |
||
|
Eff iciency (Typ.) |
≥ 80 % |
||
|
Replacable-fuse |
12V |
35A x 2 |
|
|
24V |
35A x 1 |
||
|
Protection |
Bat.Low-Alarm |
10VDC±0,5V or 20,5VDC±1V or 44VDC±1V |
|
|
Bat.Low-Shutdown |
9,5VDC±0,5V or 19,5VDC±1V or 42VDC±1V |
||
|
Overload |
> 34 0W |
||
|
Shut off output voltage,re-power on to recover |
|||
|
Over voltage |
15~16~ or 30~32V or 60~65V |
||
|
Over temperature |
>60°C/>140°F |
||
|
Output short |
Auto,shut-off |
||
|
Other |
1. With accessories AC connector ,and a wire of 1.5m(only for PCS) |
||
|
2. With DC wire in the packing |
|||
We use different kind of cartons for different products from honeycomb carton.
We have professional document operator and forwarder,give you the best price and service.
Warranty 12 months
All emails will be replied within 24 hours
Our professional service before and after sale
The competitive price
Any questions from you are welcome and will be replied in 24 hours.
1.How many kinds of output waveform for inverters?
Two kinds.Pure sine wave and modified sine wave.
2.How about the payment?
We accept T/T L/C at sight
3.How about the delivery time?
Depend on your qty.Normally we need 35-40days.
