Quick Details
-
Power Source:
-
Electric
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TOPRO
-
Model Number:
-
KSD302
-
Product Name::
-
400V 250V 40A KSD302 Thermostat for Heavy Duty Applications
-
Dimensions:
-
L47XW33 XH28mm
-
Temperature range:
-
-30~140°C, increments of 5°C
-
Batch temperature tolerance:
-
±5°C
-
Switch Type:
-
Normally Closed/Open
-
Reset Type:
-
Auto Reset
-
Contact capacity:
-
100,000 times
-
Voltage&Current:
-
400V 250V 16A, 20A, 25A, 30A, 35A, 40A, 45A, 50A, 55A, 60A
-
Certifications:
-
Certifications for Asia, Europe and North America
-
Body material:
-
Bakelite
Quick Details
-
After-sales Service Provided:
-
Return and Replacement
-
Warranty:
-
1 Year
-
Application:
-
Household
-
Power Source:
-
Electric
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TOPRO
-
Model Number:
-
KSD302
-
Product Name::
-
400V 250V 40A KSD302 Thermostat for Heavy Duty Applications
-
Dimensions:
-
L47XW33 XH28mm
-
Temperature range:
-
-30~140°C, increments of 5°C
-
Batch temperature tolerance:
-
±5°C
-
Switch Type:
-
Normally Closed/Open
-
Reset Type:
-
Auto Reset
-
Contact capacity:
-
100,000 times
-
Voltage&Current:
-
400V 250V 16A, 20A, 25A, 30A, 35A, 40A, 45A, 50A, 55A, 60A
-
Certifications:
-
Certifications for Asia, Europe and North America
-
Body material:
-
Bakelite
KSD302 thermostat is a large capacity bimetallic thermostat with a metal cap and feet for screw fixing. It is widely used for household electrical appliances such as water dispenser, water heater, electrical thermos, disinfectant cabinet, microwave oven, coffee boiler, coffee pot, rice cooker, air conditioner, laminator.
Product Applications:
KSD301 is widely used for temperature control or overheat protection of various household electric appliances
Product Specifications:
* Electric Parameter: AC125V 5A/10A/16A, AC250V 5A/10A/16A
* Contact Life Cycles: Auto reset: More than 100,000 cycles; Manual reset: More than 10,000 cycles.
* Trip off Temperatures: 0 ~ 300 degrees centigrade (increments of 5 degrees centigrade).
* Temperature Tolerance: Standard +/-5 degrees centigrade, minimum +/-2 degrees centigrade
* Reset Temperature: 10 ~ 45 degrees centigrade below the trip off temperatures.
* Insulation Resistance: More than 100 mega Ohm
* Terminals: 250# (Width: 0.250 inch or 6.3mm, Thickness: 0.031 inch or 0.8mm), 187# (Width: 0.187 inch or 4.8mm, Thickness: 0.031 inch or 0.8mm), "I" type, "L" type and 145°C available.
* Product Size: Cap diameter 18.5mm. Contact us for dimension drawings of the specific thermostats you need.
Secure and neat packing: 50pcs a layer in a card board, sandwiched with card boards between layers to ensure maximum goods safety during shipment:
Carton Size:
L27 X W25 X H18cm for 1000PCS weighing 5.6KG, 0.013CBM/carton.
L27 X W25 X H34cm for 2000PCS weighing 11KG, 0.023CBM/carton.
The packing specifications are subject to change upon negotiation with the customer as per the actual order quantity.
Normally the products are shipped by door to door express delivery, freight for buyer's account.
