Quick Details
-
Model Number:
-
Platinum Crystal smart home L-Q
-
Product Name:
-
66way Electrical Distribution box
-
Type:
-
Weak or strong current box
-
Application:
-
Loading breaker & control module for smart home/building
-
Material:
-
Tempered glass panel, aluminium alloy frame/hinge/din rail/rack
-
Certificate:
-
CE, ISO9001, CCC
-
Installation type:
-
wall-mounted(flush mounted)
-
closed type:
-
Magnetic adsorption
-
External dimension:
-
720*480*140mm
-
Installation dimension:
-
690X450X120mm
-
Panel dimension:
-
720X480X20mm
-
Color:
-
White, black, transparent, gold, silver
Quick Details
-
Voltage:
-
High and low voltage
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
matech
-
Model Number:
-
Platinum Crystal smart home L-Q
-
Product Name:
-
66way Electrical Distribution box
-
Type:
-
Weak or strong current box
-
Application:
-
Loading breaker & control module for smart home/building
-
Material:
-
Tempered glass panel, aluminium alloy frame/hinge/din rail/rack
-
Certificate:
-
CE, ISO9001, CCC
-
Installation type:
-
wall-mounted(flush mounted)
-
closed type:
-
Magnetic adsorption
-
External dimension:
-
720*480*140mm
-
Installation dimension:
-
690X450X120mm
-
Panel dimension:
-
720X480X20mm
-
Color:
-
White, black, transparent, gold, silver
Material details: L-Q , 66P(3row)
66 way indoor electrical distribution box with tempered glass panel:
※ Tempered glass panel with white screen printing
※ Logo: laser printing
※ Golden Aluminium alloy panel frame
※ Golden Aluminum alloy hinge
※ 1.2mm cold-rolled steel sheet bottom box
※ Alumilium alloy din rail for circuit breaker or module, black, x3, (22P/rail, total 3rows/66P)
※Cover for din rail: black steel with powder coating,x3
※ Zero line termial blocks:10 joint, x1
※ Gro unding terminal blocks:10 joint, x1
Di
mensions:(HxWxD) L-Q
※ External dimension(mm): 720 x480x140
※ Panel dimension (mm): 720x480
x20
※ Installation dimension(mm): 690
x450x120
※ Vertical rail length: 630mm
※Per Din rail length: 396mm(22P)
|
Description /Model
|
External dimension (mm)
|
Panel dimension (mm)
|
Installation dimension(mm)
|
|
14 way, 1 row /Platinum crystal C-Q/R
|
332X246X114
|
332X246X14
|
300X210X100
|
|
20 way, 1 row /Platinum crystal SM-D-Q/R /Platinum metal SM-Q/R
|
470X310X14
|
470X310X14
|
440X270X100
|
|
26 way, 2 rows /Platinum crystal SM-E-Q/R
|
470x310x114
|
470x310x14
|
450x275x100
|
|
32 way, 2 rows /Platinum crystal M-C-S-Q/R
|
480X380X117
|
480X380X17
|
450X350X100
|
|
42 way, 2 rows /Platinum crystal smart home S-C
|
520X450X137
|
520X450X17
|
495X420X120
|
|
63 way, 3 rows /Platinum crystal smart home L-C
|
790X450X137
|
790X450X17
|
765X420X120
|
|
44 way, 2 rows /Platinum crystal smart home S-Q
|
560X480X140
|
560X480X20
|
530X450X120
|
|
66 way, 3 rows /Platinum crystal smart home L-Q
|
720X480X140
|
720X480X20
|
690X450X120
|
|
110 way, 5 rows /Platinum crystal smart home XL-Q
|
1040X480X140
|
1040X480X20
|
1010X450X120
|
The effect with circiut breaker and smart home control modules: modules can suitable for KNX, ABB, HDL etc. see below pictures:
Jiangsu MATECH Intelligent Technology Co., Ltd.,established in 2013 with ten million RMB registered fund, is a company specialized in high-end intelligent distribution box research and development.
The founder Wenbin Cao have been engaged in building wiring project for long time since 2001. He found that the traditional distribution boxes could not satisfy the users any longer with the rise of Smart Home. The users have better taste in the appearance, space structure and manufacture concept.
Perfect appearance and exquisite manufacture are our basic pursuit. What's more, we are absorbed in more convenient installation and debugging, which could reduce lots of fussy operation for integrators.
MATECH means material technology change.
We redefine the concept of intelligent distribution box. We believe that wonderful things have occurred.
Packing
small panel and panel prame packed into a non-woven bag, larger one packed into a pearl wool case .
all parts in one export brown carton box.
pallet available for large quality and customer requirement.
Delivery
Generally it is 5-10 days if the goods are in stock. or it is 20-35 days if the goods are not in stock, it is according to quantity.
Q: Where is your comapny located?
A: Our company is located in
liyang city
Jiangsu province, it is near to Shanghai, Nanjing & Hangzhou.
Q: Are you trading company or manufacturer ?
A: We are manufacturer, aslo can do trading with foreign clients.
Q: How long is your delivery time?
A: Generally it is 2-5 days if the goods are in stock. or it is 20-35 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we can provide the sample, the cost of product and freight is based on customers.
Q: What is your terms of payment ?
A: Payment<=5000USD, 100% in advance. Payment>5000USD, 30% T/T in advance ,balance before shippment.
Q: Is OEM & ODM available?
A: Yes.
Q: How long is your warranty?
A: 2 years.
