Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SUNPOR
-
Dimension(L*W*H):
-
525X450X545
-
Weight:
-
55
-
Rated power/speed:
-
9KW/3600RPM
-
Product name:
-
Diesel Engine
-
Engine Model:
-
195F
-
Engine type:
-
Air-cooled 4-stroke
-
Application:
-
Suitable
-
Keyword:
-
Diesel Engine Diesel
-
Rated Power:
-
9KW
-
Cooling System:
-
Air Cooled
-
Brand:
-
SUNPOR
-
Fuel:
-
Diesel
Quick Details
-
Displacement:
-
520cc
-
Emission Standard:
-
EURO 5
-
Power:
-
12HP, 15HP
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SUNPOR
-
Dimension(L*W*H):
-
525X450X545
-
Weight:
-
55
-
Rated power/speed:
-
9KW/3600RPM
-
Product name:
-
Diesel Engine
-
Engine Model:
-
195F
-
Engine type:
-
Air-cooled 4-stroke
-
Application:
-
Suitable
-
Keyword:
-
Diesel Engine Diesel
-
Rated Power:
-
9KW
-
Cooling System:
-
Air Cooled
-
Brand:
-
SUNPOR
-
Fuel:
-
Diesel
13Hp 195F Single Cylinder Air Cooled Diesel Engine
High Compatibility: Widely used in: diesel generator, mini tractor, transportation machinery, water pump, irrigation machinery, engineering machinery and other power devices.
Feature: Superior quality at competitive price, strong power and long working life.
Highlights: Durable alloy nylon water tank, qualified manufacturer accessories (cylinder head, piston, etc.), upgrade design muffler, tight sealing piston ring, shock absorption optimization for longer life.
Warranty: 12 months or 1000 hours warranty.
|
Model |
|
SP190F |
SP192F |
SP195F |
SP1100F |
SP1103F |
|||
|
Type |
|
Single cylinder,vertical,four-stroke,direct injection,air-cooled |
|||||||
|
Bore*Stroke |
mm |
90*75 |
92*75 |
95*75 |
100*85 |
103*85 |
|||
|
Displace m ent |
ml/cc |
477 |
498 |
532 |
670 |
735 |
|||
|
Compression Ratio |
|
19:1 |
19:1 |
19:1 |
19:1 |
19:1 |
|||
|
Power |
Hp/rpm |
9.1/3000 10/3600 |
10.3/3000 11.2/3600 |
11.3/3000 11.8/3600 |
13.5/3000 |
16/3000 |
|||
|
Rated Speed |
rpm |
3000/3600 |
3000 |
||||||
|
Lowest rotation speed at zero load |
r/min |
≤ 1300 |
|||||||
|
Lubricating system |
|
Pressure splashed |
|||||||
|
Starting system |
|
Recoil start/electric start |
|||||||
|
Fuel Type |
|
0# ( summer) -10#(winter) -35#(chillness) diesel |
|||||||
|
Fuel tank capacity |
L |
5.5 |
5.5 |
5.5 |
5.5 |
5.5 |
|||
|
Fuel consumption/related rotation speed(g/kw.h/r/min) |
|
275.1/3000 281.5/3600 |
2 75 /3000 280 /3600 |
270/3000 |
270/3000 |
||||
|
Lube oil type |
|
CD grade or SAE 10W-30 15W-40 |
|||||||
|
Lube oil capacity |
L |
1.65 |
1.65 |
1.65 |
2.2 |
2.2 |
|||
|
Overall dimension(LXWXH) |
mm |
500*450*545 |
500*460*560 |
560*528*650 |
|||||
|
Dry weight |
kg |
45 |
46 |
50 |
58 |
65 |
|||
