Quick Details
-
Brand Name:
-
First class brand
-
Model Number:
-
SD13
-
Dimension(Long * Breadth * High):
-
5140*3388*3032mm
-
Length X Width X Height:
-
5140X3388X3032mm
-
Gradeability(deg):
-
30°
-
Clearance(mm):
-
400
-
Maximum torque (N.m/r/min):
-
764/1300
-
After Warranty Service:
-
Video technical support
Quick Details
-
Machine Weight:
-
13200 KG
-
Dozing Capacity:
-
7.5m³, 4.3m³
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
First class brand
-
Model Number:
-
SD13
-
Dimension(Long * Breadth * High):
-
5140*3388*3032mm
-
Length X Width X Height:
-
5140X3388X3032mm
-
Gradeability(deg):
-
30°
-
Clearance(mm):
-
400
-
Maximum torque (N.m/r/min):
-
764/1300
-
After Warranty Service:
-
Video technical support
Products Description
Technical Features
The turbocharged engine features strong power, high efficiency and energy-saving, and high torque reserve efficiency.
The high reliability power shift transmission and the two-stage final drive with spur gear reducing structure features reliable and stable power transmission, high durability, and high operating effic
The high-efficiency radiator can help the normal running of machine under high temperature environment and ease the daily maintenances.
The valves and pumps are reasonably arranged to ease the repairs and maintenances. The multi-stage filtration system is adopted to effectively guarantee the oil cleanliness and reduce the malfunction rate of hydraulic system.
The full box-type main frame features high carrying capacity against impact load and bending moment and the high quality welds guarantee the life cycle of the main frame.
The electric system features stable and reliable working. All instruments are controlled by microcomputer, featuring vivid and distinct display and accurate and convenient readings.
The rigid traveling system effectively improves the stability of machine under complicated working conditions.
The comfortable and convenient operating console, light controls, and adjustable seat and armrests provide the operation personnel with comfortable operating experiences.
The working device features high stiffness and reliability and good fatigue resistance and can adapt to the demands of severe working conditions.
The standard straight tilting blade features strong cutting force to handle all kinds of severe working faces and the outstanding durability of blade is guaranteed by the application of high strength structure and high performance materials.
The turbocharged engine features strong power, high efficiency and energy-saving, and high torque reserve efficiency.
The high reliability power shift transmission and the two-stage final drive with spur gear reducing structure features reliable and stable power transmission, high durability, and high operating effic
The high-efficiency radiator can help the normal running of machine under high temperature environment and ease the daily maintenances.
The valves and pumps are reasonably arranged to ease the repairs and maintenances. The multi-stage filtration system is adopted to effectively guarantee the oil cleanliness and reduce the malfunction rate of hydraulic system.
The full box-type main frame features high carrying capacity against impact load and bending moment and the high quality welds guarantee the life cycle of the main frame.
The electric system features stable and reliable working. All instruments are controlled by microcomputer, featuring vivid and distinct display and accurate and convenient readings.
The rigid traveling system effectively improves the stability of machine under complicated working conditions.
The comfortable and convenient operating console, light controls, and adjustable seat and armrests provide the operation personnel with comfortable operating experiences.
The working device features high stiffness and reliability and good fatigue resistance and can adapt to the demands of severe working conditions.
The standard straight tilting blade features strong cutting force to handle all kinds of severe working faces and the outstanding durability of blade is guaranteed by the application of high strength structure and high performance materials.
Specification
|
ITEM
|
UNIT
|
SD13
|
|
L×W×H (Ripper not included)
|
mm
|
4492×3185×2950
|
|
Operating weight (Ripper not included)
|
t
|
13.7
|
|
Engine
|
-
|
Shangchai SC8D143G2B1
C ummins 6CTA8.3-C145 |
|
Rated power
|
kW/rpm
|
95.5/1900 108/1900
|
|
Gradeability
|
°
|
30
|
|
Blade type
|
-
|
Straight tilt blade Angle blade
|
|
Blade width
|
mm
|
Straight tilt blade 3185×1090 Angle blade 3475×915
|
|
Dozing capacity
|
m3
|
Straight tilt blade 3.7 Angle blade 3.4
|
|
Ma× drop below ground of blade
|
mm
|
590
|
|
Lift height of blade
|
mm
|
930
|
|
Ripper type
|
-
|
Three-shank ripper
|
|
Ripping depth of ripper
|
mm
|
467
|
|
Lifting height of ripper
|
mm
|
559
|
|
Number of carriers (each side)
|
-
|
2
|
|
Number of track rollers (each side)
|
-
|
6
|
|
Number of track shoes (each side)
|
-
|
38
|
|
Width of track shoe
|
mm
|
460
|
|
Track gauge
|
mm
|
1880
|
|
Ground length and ground pressure
|
mm/MPa
|
2365-0.063
|
|
Pitch
|
mm
|
190
|
|
Forward speed
|
km/h
|
0–3.2
|
|
|
|
0–5.9
|
|
|
|
0–9.8
|
|
Reverse speed
|
km/h
|
0–3.9
|
|
|
|
0–7.1
|
