Quick Details
-
Warranty:
-
25years
-
Brand Name:
-
Exiom
-
Model Number:
-
EX550-600TC(B)-144(HC)(182)BF
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2172*1303*30mm
-
Number of Cells:
-
120 Cells
-
Junction Box:
-
IP68
-
Connector:
-
MC4
-
Frame:
-
Black Anodized Aluminium Alloy
-
Weight:
-
31 kg
-
Packaging:
-
31 Pcs/Pallet
-
Application:
-
Commercial
-
Port:
-
SHANGHAI/QINGDAO/NINGBO
-
OEM/ODM:
-
Highly Welcomed
-
Product Name:
-
Solar Panel Full Black
Quick Details
-
Cell size:
-
210mmx210mm
-
Type:
-
PERC, Half Cell, All Black
-
Panel Efficiency:
-
21.38%
-
Warranty:
-
25years
-
Brand Name:
-
Exiom
-
Model Number:
-
EX550-600TC(B)-144(HC)(182)BF
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2172*1303*30mm
-
Number of Cells:
-
120 Cells
-
Junction Box:
-
IP68
-
Connector:
-
MC4
-
Frame:
-
Black Anodized Aluminium Alloy
-
Weight:
-
31 kg
-
Packaging:
-
31 Pcs/Pallet
-
Application:
-
Commercial
-
Port:
-
SHANGHAI/QINGDAO/NINGBO
-
OEM/ODM:
-
Highly Welcomed
-
Product Name:
-
Solar Panel Full Black
Product Features
Technical Specifications
|
Electrical Characteristics
|
|
|
|
|
||||
|
Module Type
|
EX590M(B)
|
EX595M(B)
|
EX600M(B)
|
EX605M(B)
|
||||
|
Maximum Power- Pmax(W)
|
590
|
595
|
600
|
605
|
||||
|
Open Circuit Voltage - Voc(V)
|
41.10
|
41.30
|
41.50
|
41.70
|
||||
|
Short- Circuit Current - Isc(A)
|
18.42
|
18.47
|
18.52
|
18.57
|
||||
|
Voltage at Pmax -Vmp(V)
|
34.00
|
34.20
|
34.40
|
34.60
|
||||
|
Current at Pmax - Imp(A)
|
17.35
|
17.40
|
17.44
|
17.49
|
||||
|
Module Efficiency -ηm(%)
|
20.85
|
21.02
|
21.20
|
21.38
|
||||
|
Power Tolerance(W)
|
（0，+5W）
|
|
|
|
||||
|
Maximum System Voltage(V)
|
1500Vdc (IEC / UL)
|
|
|
|
||||
|
Maximum Series Fuse Rating (A)
|
30A
|
|
|
|
||||
|
Packing Configuration
|
|
|
|
External Dimensions
|
2172*1303*30mm
|
|
|
Container
|
40’HQ
|
|
|
Pieces per Pallet
|
31
|
|
|
Pallets per Container
|
18
|
|
|
Pieces per Container
|
558
|
|
About The Factory
Our strengths:
1. “Tier 1”brand that stands for guarantee, quality, and trust
2. 15+ year experience in the solar energy industry
3. Strategic cooperation with IBERDROLA and ADIWATT
4. 500MW+ solar panels MADE IN SPAIN
5. 24h response European local pre and after sales service
6. 48h delivery from European warehouse
Please feel free to contact us for more details.
