- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
promaxion
-
Capture Format:
-
Compression format:H0264
-
Model Number:
-
M-HW200
-
IN/OUT:
-
signal input/output
-
DC/5V:
-
USB type-C power input
Quick Details
-
Power Supply:
-
5V DC/AC
-
Input Interface:
-
HDMI in
-
Output Interface:
-
HDMI out
-
Brand Name:
-
promaxion
-
Capture Format:
-
Compression format:H0264
-
Model Number:
-
M-HW200
-
IN/OUT:
-
signal input/output
-
DC/5V:
-
USB type-C power input
Products Description
|
Description
|
|
Parameter
|
|
|
Video
|
Standards
|
HD 1.3; HDCP 1.2
|
|
|
|
Compression format
|
H.264
|
|
|
|
Maximum pixel clock
|
165MHz
|
|
|
|
Maximum data rate
|
6.75Gbps
|
|
|
|
Resolution
|
1920X1080P@60Hz
|
|
|
|
Connector
|
HD-A
|
|
|
|
Impedance
|
100Ω
|
|
|
|
Transmission delay
|
0.08 seconds
|
|
|
|
Recommended max HD cable Input/Output distance
|
＜5m, when 1920*1080P@60Hz
|
|
|
WIFI
|
RF power
|
21dbm
|
|
|
|
Wireless standard
|
802.11a、802.11n、802.11ac
|
|
|
|
Signal direction
|
unidirectional
|
|
|
|
Frequency
|
5150~5250MHz、5475~5850MHz
|
|
|
|
Transmission distance
|
200m in open environment
|
|
|
|
Modulation mode
|
OFDM
|
|
|
|
Bandwidth
|
20MHz
|
|
|
Other
|
Power supply
|
The power adapter: DC 5V/1A
|
|
|
|
Power dissipation
|
MAX 3W
|
|
|
|
Temperature
|
Operating: -5℃ ~ +70℃
|
|
|
|
Humidity
|
Operating: 5% ~ 90%
|
|
|
|
Dimension
|
116*68*20mm
|
|
