It is equipped with Yuchai, Cummins and other heavy-duty special oil extraction machines to achieve the best combustion state in the whole range of engine operation, making the product more reliable, stronger power, and better fuel economy.
- Product Details
- {{item.text}}
Quick Details
-
Voltage:
-
380V, 360V
-
Dimension(L*W*H):
-
1650*600*1200
-
Weight:
-
340KG, 3200kg
-
working pressure:
-
1.0-1.7mpa
-
Motor power:
-
7.5kw-160kw/ 10hp-200hp
-
Air capacity:
-
580 cfm
-
name:
-
Air compressor
-
Capacity:
-
360-680CFM
-
weight:
-
2750-3400 kg
-
Cooling method:
-
Air/water
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Kaishan
-
Model Number:
-
LGCY-6/7X, LGCY- 11/18T, LGCY- 19/21-21/18, LGCY-26/25, LGCY-39/25
-
Voltage:
-
380V, 360V
-
Dimension(L*W*H):
-
1650*600*1200
-
Weight:
-
340KG, 3200kg
-
working pressure:
-
1.0-1.7mpa
-
Motor power:
-
7.5kw-160kw/ 10hp-200hp
-
Air capacity:
-
580 cfm
-
name:
-
Air compressor
-
Capacity:
-
360-680CFM
-
weight:
-
2750-3400 kg
-
Cooling method:
-
Air/water
Product Description
LG series portable screw air compressor is extensively used in mining, water conservancy, traffic, shipbuilding, civil construction, energy, and military industries. In Europe and the United States and other developed countries, portable air compressor for power refers to screw air compressor for 100%.
Screw Air Compressor Mainly Has the Following Advantages:
1. High reliability: The compressor has a few parts and no quick-wear part, thus it runs reliably, has long service life and its overhaul interval is 40,000~80,000 hours.
2. Easy operation and maintenance: It is highly automatic, so that operators can manage unattended operation without long-time professional training.
3. Good dynamic balance: Without unbalance inertia force, it can run at a high speed smoothly to realize non-foundation operation, and it is particularly suitable for portable compressor with small volume, light weight and small floor space.
4. Good adaptability: It is featured by forced air transmission, its volume flow is hardly influenced by discharge pressure, and it can maintain high efficiency within a wide speed range.
Screw Air Compressor Mainly Has the Following Advantages:
1. High reliability: The compressor has a few parts and no quick-wear part, thus it runs reliably, has long service life and its overhaul interval is 40,000~80,000 hours.
2. Easy operation and maintenance: It is highly automatic, so that operators can manage unattended operation without long-time professional training.
3. Good dynamic balance: Without unbalance inertia force, it can run at a high speed smoothly to realize non-foundation operation, and it is particularly suitable for portable compressor with small volume, light weight and small floor space.
4. Good adaptability: It is featured by forced air transmission, its volume flow is hardly influenced by discharge pressure, and it can maintain high efficiency within a wide speed range.
Patented rotor profile.
Highest efficiency.
Heavy-duty design.
SKY bearing.
Direct drive.
Energy-saving principle.
Innovative design.
Air Volume Automatic Control System
According to the use of the pressure air volume adjustment device, the air compressor suction volume and the diesel engine speed are automatically and steplessly adjusted. Makes the air supply and consumption completely match, so as to achieve the best effect with the lowest fuel consumption.
Fully enclosed chassis and silent cover design, low operating noise.
Multiple Air Filtration System
Effectively prevent the impact of harsh dust environment on the engine. The precision filter layer of the main air filter filters out the remaining dust to ensure that the machine is not worn. The safety filter element allows the machine to perform air filter maintenance without stopping the machine to ensure the safe operation of the machine.
|
Model
|
Working pressure
|
Capacity
|
Diesel power(KW)
|
Outlet
|
Weight
|
Dimension
|
|
|
(Mpa)
|
m3/min
|
|
|
(kg)
|
(mm)
|
|
LGCY-5/8
|
0.8
|
5
|
36.8
|
G3/4×1 G11/4×1
|
740
|
1660×1020×1610
|
|
LGCY-6/7
|
0.7
|
6.28
|
70
|
G3/4×1 G11/4×1
|
1500
|
2175×1760×1785
|
|
LGCY-9/7
|
0.7
|
9.34
|
88
|
G3/4×1 G11/4×1
|
1550
|
2175×1760×1785
|
|
LGCY-12/10(K)
|
1
|
12
|
118
|
G11/2×1 G3/4×1
|
1880
|
3500(3100)×1850×2100
|
|
LGCY-12/10
|
1
|
12
|
118
|
G11/2×1 G3/4×1
|
1880
|
3300(2200)×1880×2100
|
|
LGCY-10/13
|
1.3
|
10
|
118
|
G11/2×1 G3/4×1
|
1880
|
3300(2200)×1880×2100
|
|
LGCY-17/7
|
0.7
|
17
|
132
|
G2×1 G3/4×1
|
3350
|
3380×1640×2350
|
|
LGCY-15/10(Cummins)
|
1.3
|
15
|
132
|
G11/2×1 G3/4×1
|
2400
|
3000×1520×2200
|
|
LGCY-15/10(Yuchai)
|
1
|
15
|
140
|
G11/2×1 G3/4×1
|
2400
|
3000×1520×2200
|
|
LGCY-13/17
|
1.7
|
13
|
158
|
G2×1 G3/4×1
|
3400
|
3780×1980×2350
|
|
LGCY-18/17
|
1.7
|
18
|
194
|
G2×1 G3/4×1
|
3400
|
3980×1800×2450
|
|
LGCY-22/8
|
0.8
|
22
|
194
|
G2×1 G3/4×1
|
4000
|
3764×1800×2213
|
|
LGCY-22/14(Yuchai)
|
1.4
|
22
|
250
|
G2×1 G3/4×1
|
4500
|
4580×1950×2600
|
|
LGCY-22/14K(Cummins)
|
1.4
|
22
|
239
|
G2×1 G3/4×1
|
4500
|
4580×1950×2600
|
|
LGCY-22/18(Yuchai)
|
1.8
|
22
|
250
|
G2×1 G3/4×1
|
4500
|
4550×1950×2600
|
|
LGCY-22/18K(Cummins)
|
1.8
|
22
|
239
|
G2×1 G3/4×1
|
4500
|
4550×1950×2600
|
|
LGCY-27/10(Yuchai)
|
1
|
27
|
250
|
G2×1 G3/4×1
|
5000
|
4600×1950×2600
|
|
LGCY-27/10k(Cummins)
|
1
|
27
|
265
|
G2×1 G3/4×1
|
5000
|
4600×1950×2600
|
|
LGCY-32/10(Yuchai)
|
1
|
32
|
288
|
G2×1 G3/4×1
|
5000
|
4600×1950×2600
|
|
LGCY-32/10K(Cummins)
|
1
|
32
|
265
|
G2×1 G3/4×1
|
5000
|
4600×1950×2600
|
|
Model
|
Working pressure
|
Capacity
|
Diesel power
|
Outlet
|
Weight
|
Dimension
|
|
|
(Mpa)
|
m3/min
|
(KW)
|
|
(kg)
|
(mm)
|
|
LGCY-550/14T
|
1.4
|
15
|
132
|
G1/2×1 G3/4×1
|
2800
|
3600×1600×2220
|
|
LGCY-550/14AT
|
1.4
|
15
|
140
|
G1/2×1 G3/4×1
|
2800
|
3600×1600×2220
|
|
LGCY-650/18T
|
1.8
|
18
|
194
|
G2×1 G3/4×1
|
3700
|
3980×1800×2230
|
|
LGCY-650/18AT
|
1.8
|
18
|
191
|
G2×1 G3/4×1
|
3700
|
3980×1800×2230
|
|
LGCY-800/20(Yuchai)
|
2
|
23
|
250
|
G2×1 G3/4×1
|
4850
|
4600×1950×2850
|
|
LGCY-800/20(Cummins)
|
2
|
23
|
239
|
G2×1 G3/4×1
|
4850
|
4600×1950×2850
|
|
LGCY-26/25
|
2.5
|
26
|
404
|
G2×1 G3/4×1
|
6800
|
4700×2100×2500
|
|
LGCY-26/25A
|
2.5
|
26
|
404
|
G2×1 G3/4×1
|
6800
|
4700×2100×2500
|
|
LGCY-21/35
|
3.5
|
21
|
404
|
G2×1 G3/4×1
|
6800
|
4700×2100×2500
|
|
LGCY-21/35A
|
3.5
|
21
|
404
|
G2×1 G3/4×1
|
6800
|
4700×2100×2500
|
|
LGCY-33/25
|
2.5
|
33
|
404
|
G2×1 G3/4×1
|
6800
|
4700×2100×2500
|
|
LGCY-33/25A
|
2.5
|
33
|
404
|
G2×1 G3/4×1
|
6800
|
4700×2100×2500
|
|
LGCY-26/35
|
3.5
|
26
|
404
|
G2×1 G3/4×1
|
6800
|
4700×2100×2500
|
|
LGCY-26/35A
|
3.5
|
26
|
404
|
G2×1 G3/4×1
|
6800
|
4700×2100×2500
|
|
LGCY-39/25
|
2.5
|
39
|
511
|
G2×1 G3/4×1
|
7200
|
5000×2200×2900
|
|
LGCY-39/25A
|
2.5
|
39
|
478
|
G2×1 G3/4×1
|
7200
|
5000×2200×2900
|
|
LGCY-33/35
|
2.5
|
33
|
511
|
G2×1 G3/4×1
|
7200
|
5000×2200×2900
|
|
LGCY-33/35A
|
3.5
|
33
|
478
|
G2×1 G3/4×1
|
7200
|
5000×2200×2900
|
|
LGCY-19.5/19(Cummins)
|
1.9
|
19.5
|
194
|
G2×1 G3/4×1
|
3700
|
3980×1800×2650
|
|
LGCY-19.5/19A(Yuchai)
|
1.9
|
19.5
|
250
|
G2×1 G3/4×1
|
3700
|
3980×1800×2650
|
|
LGCY-22/20(Yuchai)
|
2
|
22
|
250
|
G2×1 G3/4×1
|
4850
|
4600×1950×2850
|
|
LGCY-22/20K(Cummins)
|
2
|
22
|
239
|
G2×1 G3/4×1
|
4500
|
4600×1950×2850
|
|
LGCY-27/20(Yuchai)
|
2
|
27
|
288
|
G2×1 G3/4×1
|
4850
|
4600×1950×2850
|
|
LGCY-26/20(Cummins)
|
2
|
26
|
265
|
G2×1 G3/4×1
|
4500
|
4600×1950×2850
|
|
LGCY-27/22
|
2.2
|
27
|
298
|
G2×1 G3/4×1
|
4500
|
4600×1950×2850
|
|
LGCQ-33/25-26/35
|
2.5(3.5)
|
33(26)
|
404
|
G2×2
|
6800
|
4395×2160×2550
|
|
LGCY-43/25-35/35
|
2.5(3.5)
|
43(35)
|
565
|
G2×2
|
7000
|
4750×2160×2300
|
