Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
1005*825*2.8mm
-
Panel Efficiency:
-
>21%
-
Application:
-
Solar Power System
-
Product name:
-
Flexible Solar Panles
-
Keyword:
-
400 watt solar panel
-
Type:
-
Flexible ETFE
-
working voltage:
-
18.9V
-
Weight:
-
2.8kg
-
Color:
-
black
-
Operating temperature:
-
-20-80℃
-
Max flexed angel:
-
30 degree
-
Output cable:
-
MC4 cable(0.9m)
Quick Details
-
Cell size:
-
125mmx125mm
-
Brand Name:
-
JDI
-
Model Number:
-
Customized
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
1005*825*2.8mm
-
Panel Efficiency:
-
>21%
-
Application:
-
Solar Power System
-
Product name:
-
Flexible Solar Panles
-
Keyword:
-
400 watt solar panel
-
Type:
-
Flexible ETFE
-
working voltage:
-
18.9V
-
Weight:
-
2.8kg
-
Color:
-
black
-
Operating temperature:
-
-20-80℃
-
Max flexed angel:
-
30 degree
-
Output cable:
-
MC4 cable(0.9m)
Product Description
Flexible Solar Panels 600W 2X 300W Monocrystalline PET 18V-36V Home Solar Panels Solar Panel Kit for Car Boats, Caravans, RVs
Solar Panel can curve to a maximum 30-degree arc, which makes it ideal for storage in tight spaces or crowded areas. This solar panel packs 100W of power, but it only weighs a mere 2.6 pounds, making it easier to transport, hang, and install.
The solar panel is completely waterproof, can work for a long time in strong sunlight, and is very suitable for use in harsh
environments such as outdoors and the sea. The flexible solar panel has six holes reserved, which can effortlessly fix on the top of the nylon canvas.
environments such as outdoors and the sea. The flexible solar panel has six holes reserved, which can effortlessly fix on the top of the nylon canvas.
Specification
|
Power
|
50W-400W
|
|
|
|
open circuit voltage
|
23.2V
|
|
|
|
short circuit voltage
|
8A
|
|
|
|
working voltage
|
19.8V
|
|
|
|
working current
|
7.6A
|
|
|
|
max.system voltage
|
300V
|
|
|
|
cell efficiency
|
>21%
|
|
|
|
size
|
1005*825*2.8mm
|
|
|
|
weight
|
2.8kg
|
|
|
|
color
|
black
|
|
|
|
output
|
MC4 cable(0.9m)
|
|
|
|
cell type
|
monocrystalline
|
|
|
|
front material(option)
|
ETFE/PET
|
|
|
|
max flexed angel
|
30 degree
|
|
|
|
operating temperature
|
-20-80℃
|
|
|
|
Certificate
|
CE, ROHS, IEC
|
|
|
|
application
|
it is widly used for trailers, boats, cabins, tents, cars, trucks, trailers, yachts, trailers, roofs, or any other irregular
surface, also charge for power station or battery |
|
|
Higher solar conversion efficiency
it can be connected in series or in parallel
Easy to install:
Metal holes in the four corners of the product for fixing screws and mounting. Each solar panel has been tested several times.
As a professional solar panel manufacturer with more than ten years of production experience. Choose us, your interests will be the best protection.
As a professional solar panel manufacturer with more than ten years of production experience. Choose us, your interests will be the best protection.
【Good flexibility】
The minimum radius of the arc that a solar flexible panel can reach is 40cm(15.75 in).It is allowed to be installed on trailers, boats, cabins, tents, cars, trucks, trailers, yachts, trailers, roofs, or any other irregular surface.
Easy to use:
Semi-flexible panels can be mounted on irregular surfaces such as RV roofs, boats, tents, vaulted roofs, etc. Up to 30 degrees.
Flexible
Solar panel has 5 layers, all of which are made of flexible materials. It is flexible and can be installed on a curved surface and ship roof
Completely well waterproof
Solar panels made of advanced waterproof materials. It is more durable than traditional glass and aluminum model solar panels.
High temperature resistant, easy to clean
High temperature resistant, easy to clean
Tear resistant
The interface of Himino solar panel is engineered with high-temperature anti-corrosion PVC fabric,resulting in a high wear, tear resistant.
