Quick Details
-
MOQ:
-
5pcs
-
Function:
-
Control angle
-
Product name:
-
GXservo Brushless Servo
-
Color:
-
Red
-
Product size:
-
60x30x58mm
-
Brand Name:
-
GXservo
Quick Details
-
Place of Origin:
-
China
-
Model Number:
-
X120
-
Certification:
-
CE, Rohs
-
MOQ:
-
5pcs
-
Function:
-
Control angle
-
Product name:
-
GXservo Brushless Servo
-
Color:
-
Red
-
Product size:
-
60x30x58mm
-
Brand Name:
-
GXservo
Product Description
Puise Width: 500μs-2500μs =180°/270°/360°
Operating Speed: (6.0V)0.16sec60°
Operating Speed: (7.4V)0.14sec60°
Operating Speed: (8.4V)0.13sec60°
Stall Torque(6.0V): 110kg.cm
Stall Torque(7.4V): 120kg.cm
Stall Torque(8.4V): 135kg.cm
Operating Voltage: 6.0V-8.4V
Gear Type: Steel
Motor: Brushless motor
Dead band: 2μs
Ball Bearing: 3BB
Working Frequence: 1520μs/330hz
Shell Materal: CNC aviation aluminium alloy
spline tooth： 15T
Control System: Customizable(PWM,RS485 ,TTL,CAN)
Dimensions: 65*30*58mm
Weight: 210g
Operating Speed: (6.0V)0.16sec60°
Operating Speed: (7.4V)0.14sec60°
Operating Speed: (8.4V)0.13sec60°
Stall Torque(6.0V): 110kg.cm
Stall Torque(7.4V): 120kg.cm
Stall Torque(8.4V): 135kg.cm
Operating Voltage: 6.0V-8.4V
Gear Type: Steel
Motor: Brushless motor
Dead band: 2μs
Ball Bearing: 3BB
Working Frequence: 1520μs/330hz
Shell Materal: CNC aviation aluminium alloy
spline tooth： 15T
Control System: Customizable(PWM,RS485 ,TTL,CAN)
Dimensions: 65*30*58mm
Weight: 210g
Specification
|
Size
|
65*30*58mm
|
|
Use
|
Vehicles & Remote Control Toys
|
|
RC Parts & Accs
|
Servo
|
|
Color
|
Black
|
