Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
China
-
Brand Name:
-
SZXY
-
Power:
-
/
-
Name:
-
Conveyor belt
-
Colour:
-
Black
-
Voltage:
-
12V/24V
-
Feature:
-
Vending machine
-
Materials:
-
Plastic
Quick Details
-
Type:
-
Conveyor belt
-
Dimension:
-
50*7*5(cm)
-
After-sales Service Provided:
-
Free spare parts, Online support
-
Warranty:
-
1 Year
-
Place of Origin:
-
China
-
Brand Name:
-
SZXY
-
Power:
-
/
-
Name:
-
Conveyor belt
-
Colour:
-
Black
-
Voltage:
-
12V/24V
-
Feature:
-
Vending machine
-
Materials:
-
Plastic
Product Description
1
.
Scope of application
Applicable to the market, the current spring-loaded vending machine has the interchangeability with the spring, which means that
the original cargo lane, electric control and terminal block do not need to be changed and have the function of interchangeability.
Suitable for vending machine, fast food, cold chain, vegetable, wine and other fragile products.
2. Technical parameters: (table)
1. Single piece minimum 30g (g), thickness 30mm (mm), high 80mm (mm), track total cargo up to 10kg (kg). The maximum bearing
capacity of double track is 20kg.
2. Single item travel 300mm (mm)
3 . 24V motor current 180mA (mA) load 12V motor current 250mA (mA) load
4. Speed: 55mm per second
5. Temperature: -10 ℃ ~ 80 ℃
3. Shipping principle
When the cargo falls the spring forces the switch power off and the track stops running (that is, the drop track stops running)
4. Product specifications
Length: 420-1000mm, adjustable (original spring size)
Thickness (stents carrying cargo): 33 mm
Applicable to the market, the current spring-loaded vending machine has the interchangeability with the spring, which means that
the original cargo lane, electric control and terminal block do not need to be changed and have the function of interchangeability.
Suitable for vending machine, fast food, cold chain, vegetable, wine and other fragile products.
2. Technical parameters: (table)
1. Single piece minimum 30g (g), thickness 30mm (mm), high 80mm (mm), track total cargo up to 10kg (kg). The maximum bearing
capacity of double track is 20kg.
2. Single item travel 300mm (mm)
3 . 24V motor current 180mA (mA) load 12V motor current 250mA (mA) load
4. Speed: 55mm per second
5. Temperature: -10 ℃ ~ 80 ℃
3. Shipping principle
When the cargo falls the spring forces the switch power off and the track stops running (that is, the drop track stops running)
4. Product specifications
Length: 420-1000mm, adjustable (original spring size)
Thickness (stents carrying cargo): 33 mm
| Length | 420-1000mm, adjustable (original spring size) |
