Quick Details
-
Horsepower:
-
251 - 350hp
-
Cargo Tank Type:
-
Van
-
Gross Vehicle Weight:
-
15001-20000 kg
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Video technical support, Return and Replacement, Online support, Free spare parts
-
Brand Name:
-
Japan Brand
-
Place of Origin:
-
HUB
-
Engine Brand:
-
Japan Brand
-
Size:
-
11750*2550*3960mm
-
Cargo Tank Dimension:
-
9350*2450*2550mm
-
Drive type:
-
6*4
-
Loading capacity:
-
20Ton
-
Wheelbase:
-
5700+1370mm
-
Transmission:
-
9 Forwards
-
Product name:
-
Heavy Duty Cargo Truck
-
Brand:
-
Japan Brand
-
Engine:
-
6 Cylinders
-
Horse power:
-
300hp
-
Product Name:
-
XDR 15 tons Heavy Duty Dry Cargo Carrying Steel Hand Van Body Truck
Quick Details
-
Condition:
-
New
-
Emission Standard:
-
Euro 6
-
Market Segement:
-
Construction materials transportation
-
Horsepower:
-
251 - 350hp
-
Cargo Tank Type:
-
Van
-
Gross Vehicle Weight:
-
15001-20000 kg
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Video technical support, Return and Replacement, Online support, Free spare parts
-
Brand Name:
-
Japan Brand
-
Place of Origin:
-
HUB
-
Engine Brand:
-
Japan Brand
-
Size:
-
11750*2550*3960mm
-
Cargo Tank Dimension:
-
9350*2450*2550mm
-
Drive type:
-
6*4
-
Loading capacity:
-
20Ton
-
Wheelbase:
-
5700+1370mm
-
Transmission:
-
9 Forwards
-
Product name:
-
Heavy Duty Cargo Truck
-
Brand:
-
Japan Brand
-
Engine:
-
6 Cylinders
-
Horse power:
-
300hp
-
Product Name:
-
XDR 15 tons Heavy Duty Dry Cargo Carrying Steel Hand Van Body Truck
Product Description
Specification
|
Basic Information
|
|
|
|
|||
|
Truck Dimension
|
11750*2550*3960
|
Box Dimension
|
9350*2450*2550
|
|||
|
Truck Model
|
YZRQL5250XXYWTFZJ
|
Truck type
|
Vans
|
|||
|
Drive Type
|
6X4
|
Wheelbase(mm)
|
5700+1370
|
|||
|
Box length Level (M
|
9.4
|
Engine
|
6HK1-TCG60
|
|||
|
Transmission
|
9-speed gearbox
|
Truck length(mm)
|
11750
|
|||
|
Truck width (mm)
|
2550
|
Truck height(mm)
|
3960
|
|||
|
Front tread (on wheel )(mm)
|
1960
|
Rear tread (on wheel )(mm)
|
1855/1855
|
|||
|
Curb weight (kg)
|
10830
|
Rated loading weight(kg)
|
13975
|
|||
|
Gross weight
|
25000
|
Max. Speed(km/h)
|
105
|
|||
|
Origin
|
China
|
Tonnage class
|
Heavy duty
|
|||
|
Approach angle (º)
|
15
|
Departure angle (º)
|
9
|
|||
|
Front/rear suspension (mm)
|
1335/3415
|
|
|
|||
|
Engine Parameters
|
|
|
|
|||
|
Engine model
|
6HK1-TCG60
|
Engine brand
|
Isuzu
|
|||
|
Engine class
|
/
|
Cylinder number
|
6
|
|||
|
Fuel type
|
Diesel
|
Cylinder arrangement
|
inline
|
|||
|
Displacement (L)
|
7.79
|
Emission standard
|
Euro 6
|
|||
|
Max. output power(kw)
|
221
|
Max.Horsepower(hp)
|
300
|
|||
|
Max. Torque(N.m)
|
980
|
Max. torque speed(RPM)
|
/
|
|||
|
Rated Rotated Speed(RPM)
|
/
|
|
|
|||
|
Cargo box parameters
|
|
|
|
|||
|
Cargo box form
|
van
|
Length (mm)
|
9350
|
|||
|
Width (mm)
|
2450
|
Height (mm)
|
2550
|
|||
|
Cab parameters
|
|
|
|
|||
|
occupancy
|
3person
|
Seat rows
|
Single
|
|||
|
Transmission parameters
|
|
|
|
|||
|
Transmission Model
|
9-speed gearbox
|
Shift mode
|
Manual
|
|||
|
forward gear
|
9
|
reverse gear
|
2
|
|||
|
Chassis parameters
|
|
|
|
|||
|
Allowable front axle load(kg)
|
7000
|
Allowable rear axle load(kg)
|
20000
|
|||
|
Number of spring plates
|
9/10
|
Fuel tanker
|
200L
|
|||
|
Tires
|
|
|
|
|||
|
Tire Specification
|
295/80R22.5
|
Number of tires
|
10
|
|||
|
Controls
|
|
|
|
|||
|
ABS anti-lock
|
√
|
|
|
|||
|
Internal Configuration
|
|
|
|
|||
|
multifunction steering wheel
|
√
|
Forms of air-conditioning regulation
|
Manual
|
|||
|
power window
|
√
|
Electronic central locking
|
√
|
|||
|
Multimedia Configuration
|
|
|
|
|||
|
radio
|
√
|
|
|
|||
|
Brake
|
|
|
|
|||
|
Vehicle Brake Type
|
pneumatic brake
|
parking brake
|
Hand brake
|
|||
