Quick Details
-
Place of Origin:
-
Guangdong, China
-
Standard Version:
-
4G+2D Barcode scanner
-
Interface:
-
4*ISO7816 SAM Sockets; 2*RS232
-
Certification:
-
CE/FCC/RoHS
-
CPU:
-
32-bit ARM Cortex-A7 528GHz
-
Application:
-
Transportation/Bus/Parking
-
Cards Suppoting:
-
ISO14443 Type A & B
-
Built-in Peripherals:
-
LCD Display+Speaker+Buzzer+LED Status Indicators
-
Operation System:
-
Linux 4.9
-
Warranty:
-
1 year
-
DDR (RAM):
-
512 MB
Quick Details
-
Model Number:
-
P18-L2C
-
Country of Origin:
-
China
-
Brand Name:
-
HCCTG
-
Place of Origin:
-
Guangdong, China
-
Standard Version:
-
4G+2D Barcode scanner
-
Interface:
-
4*ISO7816 SAM Sockets; 2*RS232
-
Certification:
-
CE/FCC/RoHS
-
CPU:
-
32-bit ARM Cortex-A7 528GHz
-
Application:
-
Transportation/Bus/Parking
-
Cards Suppoting:
-
ISO14443 Type A & B
-
Built-in Peripherals:
-
LCD Display+Speaker+Buzzer+LED Status Indicators
-
Operation System:
-
Linux 4.9
-
Warranty:
-
1 year
-
DDR (RAM):
-
512 MB
Product Description
Product Paramenters
|
Connectivity
|
|
|
|
RS232
|
3 lines R*D, T*D and GND without flow control
|
|
|
RS485
|
3 lines A, B and GND
|
|
|
Ethernet
|
Built-in 10/100-base-T with RJ45 connector
|
|
|
USB
|
USB 2.0 Host Full Speed
|
|
|
GSM/GPRS/EDGE
|
900 MHz/1800 MHz
|
|
|
Dual Band UMTS/HSDPA/HSPA+
|
B1/B8
|
|
|
Dual Band TD-SCDMA
|
B34/B39
|
|
|
Four-Band FDD-LTE
|
B1/B3/B7/B8
|
|
|
Four-Band TDD-LTE
|
B38/B39/B40/B41
|
|
|
WiFi
|
IEEE 802.11 b/g/n
|
|
|
GPS
|
Supported
|
|
|
Barcode Scanner
|
|
|
|
1D Barcode Scanning
|
Supported
|
|
|
2D Barcode Scanning
|
Supported
|
|
|
QR Code Scanning
|
Supported
|
|
|
Contactless Smart Card Interface
|
|
|
|
Standard
|
ISO-14443 A & B part 1-4, ISO-18092
|
|
|
Smart Card Read /Write Speed
|
Up to 424 kbps
|
|
|
Operating Distance
|
Up to 50 mm
|
|
|
Operating Frequency
|
13.56 MHz
|
|
|
SAM Card Interface
|
|
|
|
Number of Slots
|
4 ID -000 slots
|
|
|
Card connect slot
|
Contact
|
|
|
Standard
|
ISO/IEC 7816 Class A, B (5V, 3V)
|
|
|
Protocol
|
T=0, T=1
|
|
|
Smart Card Read /Write Speed
|
9,600-115,200 bps
|
|
|
Firmware Upgradeable through
|
RS232
|
|
|
Built-in Peripherals
|
|
|
|
LCD Display
|
160×80 dot-matrix LCD display with backlight, 4.3 inch
|
|
|
Speaker
|
Supported
|
|
|
Buzzer
|
Supported
|
|
|
LED Status Indicators
|
4LEDs for indicating status (from left most: blue, yellow, green, red)
|
|
|
Other Features
|
Real Time Clock
|
|
|
|
Temperature: -20℃～60℃
|
|
|
|
Humidity: 5℅～93℅(Non-condensing)
|
|
|
|
Temperature:－30℃～80℃
|
|
|
|
Humidity: 5℅～95℅(non-condensing)
|
|
|
Physical Specifications
|
|
|
|
Dimensions
|
227mm×140mm×99mm
|
|
|
Case Color
|
Black
|
|
|
Weight
|
880g
|
|
|
Certifications/Compliance
|
ISO-7816, ISO-14443, CE, FCC, RoHS
|
|
