Quick Details
-
Voltage:
-
380/220V(50/60HZ)
-
Power:
-
8/10kw or gas
-
Weight:
-
330 KG
-
Dimension(L*W*H):
-
4100*950*1350mm
-
Application:
-
Food Processing Machine
-
Product name:
-
injera making machine
-
Name:
-
crepe making machine
-
Usage:
-
Food Industry Equipment
-
Function:
-
Multifunctional
-
Keywords:
-
Easy Operate High Productivity
-
Type:
-
Fully Automatic
-
Key words:
-
pancake skin board crepe make machine
-
Package:
-
Wooden Case
-
Other name:
-
spring roll sheet machine
Quick Details
-
Marketing Type:
-
New Product 2023
-
Place of Origin:
-
Henan,China
-
Brand Name:
-
Gelgoog
-
Voltage:
-
380/220V(50/60HZ)
-
Power:
-
8/10kw or gas
-
Weight:
-
330 KG
-
Dimension(L*W*H):
-
4100*950*1350mm
-
Application:
-
Food Processing Machine
-
Product name:
-
injera making machine
-
Name:
-
crepe making machine
-
Usage:
-
Food Industry Equipment
-
Function:
-
Multifunctional
-
Keywords:
-
Easy Operate High Productivity
-
Type:
-
Fully Automatic
-
Key words:
-
pancake skin board crepe make machine
-
Package:
-
Wooden Case
-
Other name:
-
spring roll sheet machine
Product Description
Spring roll wrapper machine
Spring roll skin machine is a kind of dough through the circular baking wheel heating and baking, into a fixed thickness of spring roll skin or other flake food equipment, automatic spring roll skin machine automatically complete the mixing, molding, output air cooling and other processes, can be combined with the filling machine, deep fryer, deep fryer, quick-freezing machine, packaging machine into a cooked food automatic production line.
Application
Spring roll sheet making machine
It is suitable for the production of pancake food such as spring roll skin, samosas skin, French pancake, and the forming of flour products, roast duck cake, egg dumpling skin and lotus leaf cake. Can be customized according to customer requirements have a variety of molds, widely used in food factories, restaurants, fast food restaurants and other food processing field production.
Related Product
Product parameter
|
Model
|
GG-3620
|
GG-5029
|
GG-8045
|
GG-12060
|
|
Voltage
|
380/220V（50/60HZ）
|
380/220V（50/60HZ）
|
380/220V（50/60HZ）
|
380/220V（50/60HZ）
|
|
Dia. of heating Cylinder
|
400mm
|
500mm
|
800mm
|
1200mm
|
|
Power
|
8/10kw or gas
|
18kw or gas
|
40kw or gas
|
59kw or gas
|
|
Host Power
|
0.4
|
0.4
|
0.4
|
0.75
|
|
Cutter Power
|
0.2
|
0.2
|
0.2
|
0.2
|
|
Belt power
|
-
|
0.36
|
0.36
|
0.55
|
|
Capacity
（Sheet Dia/Width 150mm） |
500-1000pcs/h
|
1000-1500pcs/h
|
3500pcs/h
|
9000pcs/h
|
|
Dimension
|
4100*950*1350mm
|
5200*950*1350mm
|
6200*1100*1600mm
|
6500*1300*2300mm
|
|
Rotating speed
|
1-2.5r/min
|
1-2.5r/min
|
1-3r/min
|
1-3r/min
|
|
Weight
|
330kg
|
520kg
|
1000kg
|
1750kg
|
|
Size of the Sheet ( Max.)
|
200mm
|
300mm
|
450mm
|
600mm
|
|
Thickness of the Sheet
|
0.3-2.0mm
|
0.3-2.0mm
|
0.3-2.0mm
|
0.3-2.0mm
|
Product Details
Product advantage
1. Energy saving: The machine adopts advanced temperature control system, so that the temperature reaches zero error, no heat waste, to achieve the purpose of energy saving and environmental protection, reduce energy costs.
2. Simple operation: The machine operating system is simple, fully automated production, cake pressing and heating are completed at the same time, after pressing the switch, the machine automatically starched the finished product, one person immediately operation, to the greatest extent to save labor costs.
3. Good shape: the size of the product is uniform, the surface is smooth, the pattern is neat, far more beautiful than hand-made.
4. Long life: The whole machine is made of high-quality stainless steel material, structural parts do not need refueling, no rust, no burrs on the cutting surface, durable, normal service life in 6-8 years.
5. Low noise: automatic noise treatment technology, the machine running noise control below 50 decibels, to ensure that the operator has a good working environment.
6. Can be customized: can be customized according to user needs of different sizes, different production of round/square spring roll skin, product size, machine can also be customized according to customer needs.
