rtv2 liquid silicone rubber silicone sealant for solar panel neutral silicone sealant HM-538 UL certificated
HM -538C Neutral Sealant
Room temperature Methanol cured one-component silicon adhesive, passed UL, SGS certificate. With excellent resistance to climatic aging and yellowness; high strength, have good adhesion for aluminum, glass, etc. No corrosion to PC.
Applications
Bonding, sealing, and encapsulating photovoltaic module components.
Main parameters
|
Item |
Result |
Test Standard |
|
Color |
Black, white or grey paste |
visual inspection |
|
Tack-free time (min) |
10 ~ 20 |
GB/T13477 |
|
Hardness(HSA) |
45 ~ 55 |
GB/T531 |
|
Specific gravity ( g/cm 3 ) |
1.35 |
GB/T13477 |
|
Tensile strength(MPa) |
≥2.1 |
GB/T528 |
|
Metal corrosion test |
qualified |
SH/T0331-1992 |
|
Working temperature °C |
-50 ~ 180 |
/ |
|
Flame retardant rating |
UL94HB |
/ |
How to use
Substrates preparation
A. All surface must be clean and dry, degrease and wash off any contaminates that could impair adhesion.
B.Certain plastic may require specific surface treatment to obtain optimum adhesion. Such as the polypropylene, which should need chemical corrosion or plasma treatments?
How to apply
A. Apply a bead of neutral sealant to one of the prepared surface, and then quickly cover with the other substrate to be bonded.
B. On exposure to moisture, the freshly applied material will “skin over” in about 10 to 15 minutes at room temperature and 50% relative humidity. The surface is easily tooled with a spatula.
Cured time
After skin formation, cure continues inward from the surface. In 24 hours (at room temperature and 50% relative humidity),will cure to a depth of about 2.5mm.Very deep sections, especially when access to atmosphere moisture is restricted, will take longer time to cure completely. Cure time will also extend when at lower humidity levels.
Usable life and storage
When stored at or below 27 °C in the original unopened conta iner has a usable life of 6 months from the day of manufacture.
Plastic barrel:5 gallon (about 18L)
1. What are the normal package ?
100 ml /300 ml /2600 ml /18.9 L
for one part silicone sealant
1 kg /tin
for heat sink compound
20 kg / barrel
for two parts potting compound
2. Normal application temperature ?
Normally it's
-50C - +180C
,depends on specific item .
3. Does your silicone sealant corrode metal and plastic ?
No, it doesn't .
All of our silicone sealant are neutral .
4. What kind of silicone sealant are you selling ?
We are selling
neutral silicone sealant for LED ,automobile ,Solar PV ,consumer electronics ,craft ,etc
5. Are your silicone sealant Eco-friendly ?
All of our silicone sealants are Eco-friendly ,they have gone through RoHS, REACH tests every year .Some have UL certificates .
6. What is the Shelf life of your silicone sealant
When stay unopened, shelf life is six months from the date of manufacture, keep in cool and dry place (-20 ℃ ~27 ℃ ).
