Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LANBOO
-
Model Number:
-
LB22E
-
Product name:
-
LB22E
-
Mounting hole diameter:
-
22mm
-
Head shape:
-
Flat Head
-
LED color:
-
Red.Yellow.Green.White.Blue.Orange
-
Button color:
-
Stainless steel/Aluminum oxide
-
Mechanical Life:
-
100000 Times
-
Electrical Life:
-
1000000times
-
LED Voltage:
-
3V/6V/12V/24V/36V/110V/220V/250V
-
Contact Resistance:
-
≤50 ohm
-
Insulation Resistance:
-
≥1000M ohm
-
Certification:
-
CCC CE ROHS ISO9001
Quick Details
-
Protection Level:
-
IP67/Ik10
-
Max. Current:
-
16A
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LANBOO
-
Model Number:
-
LB22E
-
Product name:
-
LB22E
-
Mounting hole diameter:
-
22mm
-
Head shape:
-
Flat Head
-
LED color:
-
Red.Yellow.Green.White.Blue.Orange
-
Button color:
-
Stainless steel/Aluminum oxide
-
Mechanical Life:
-
100000 Times
-
Electrical Life:
-
1000000times
-
LED Voltage:
-
3V/6V/12V/24V/36V/110V/220V/250V
-
Contact Resistance:
-
≤50 ohm
-
Insulation Resistance:
-
≥1000M ohm
-
Certification:
-
CCC CE ROHS ISO9001
| Mounting Aperture | 22mm |
| Serial Number | LB22E |
| Head shape | Flat head |
| Switch combination | Self-locking Self-recovering |
| Action form | 1NO Independent Pin |
| Waterproof level | IP67, anti-collision IK10 (refer to GB/T 20138) |
| Heating current | Ith: 16A, 250VAC |
| Working environment | -40°C~+80°C (non-vacuum state, without freezing) |
| Insulation resistance | ≥1000MΩ |
| Contact resistance | ≤50mΩ |
| LED voltage | 9-24V, 220V / Customized: 3-8V |
| Rated curren | Resistive load: AC-15: 110V:5A/220V |
| Inductive load | AC-15: 110V / 220V: 2.5A, DC-13: 110V: 2.5A |
| Glowing shape | Ring/Ring+Power Symbol / Customized: Custom Pattern Symbol |
| Glow color | Red, Green, Blue / Customized: Yellow, White |
