- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
HUAYEE
-
Fork Length:
-
1070MM
-
Fork Width:
-
150MM
-
Overall Dimensions:
-
4190*1480*2390mm
-
Weight (KG):
-
5000 kg
-
The Model:
-
HYP50
-
Power:
-
Diesel
-
Load center distance:
-
500mm
-
Driving mode:
-
Seat driving
-
Wheelbase:
-
2000mm
-
Minimum ground clearance:
-
175mm
-
No-load maximum lifting height:
-
3000mm
-
Free lifting height:
-
150mm
-
Minimum turning radius (outer side):
-
2900mm
-
Mast tilt angle (front/rear):
-
6°/12°
Quick Details
-
Min. Lifting Height:
-
2050mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HUAYEE
-
Fork Length:
-
1070MM
-
Fork Width:
-
150MM
-
Overall Dimensions:
-
4190*1480*2390mm
-
Weight (KG):
-
5000 kg
-
The Model:
-
HYP50
-
Power:
-
Diesel
-
Load center distance:
-
500mm
-
Driving mode:
-
Seat driving
-
Wheelbase:
-
2000mm
-
Minimum ground clearance:
-
175mm
-
No-load maximum lifting height:
-
3000mm
-
Free lifting height:
-
150mm
-
Minimum turning radius (outer side):
-
2900mm
-
Mast tilt angle (front/rear):
-
6°/12°
|
Model
|
HYP20
|
HYP25
|
HYP30
|
HYP35
|
HYP45
|
HYP50
|
|
Power
|
Diesel
|
Diesel
|
Diesel
|
Diesel
|
Diesel
|
Diesel
|
|
Rated lifting load（kg）
|
2000
|
2500
|
3000
|
3500
|
4500
|
5000
|
|
Load center distance (mm）
|
500
|
500
|
500
|
500
|
500
|
500
|
|
Length With fork (mm）
|
3590
|
3650
|
3750
|
3763
|
4190
|
4190
|
|
Length Without fork (mm）
|
2520
|
2580
|
2682
|
2693
|
3120
|
3120
|
|
Width (mm）
|
1170
|
1170
|
1225
|
1225
|
1480
|
1480
|
|
Height when the mast not raised(mm）
|
2100
|
2070
|
2130
|
2130
|
2390
|
2390
|
|
Overhead guard height(mm）
|
2110
|
2070
|
2090
|
2090
|
2240
|
2240
|
|
Minimum ground clearance (mm）
|
110
|
110
|
110
|
110
|
175
|
175
|
|
No-load maximum lifting height(mm）
|
3000
|
3000
|
3000
|
4000
|
3000
|
3000
|
|
Free lifting height
|
150
|
160
|
160
|
160
|
150
|
150
|
|
Minimum turning radius (outer side)(mm）
|
2300
|
2240
|
2400
|
2420
|
2900
|
2900
|
Here are some of the key advantages of diesel forklift trucks
1、
High Torque and Power
Diesel engines provide high torque at lower RPMs, which is beneficial for lifting heavy loads and maneuvering in tight spaces. This makes diesel forklifts suitable for demanding tasks.
2、Fuel Efficiency:
Diesel forklifts are known for their fuel efficiency compared to some other types of forklifts, especially when used for long hours or heavy-duty operations. They typically consume less fuel per unit of work done.
3、Longer Lifespan:
Diesel engines are robust and durable, often having a longer lifespan compared to other power sources. With proper maintenance, a diesel forklift can serve a company for many years.
4、Low Operating Costs:
Diesel fuel is generally less expensive than other fuels, such as propane or electricity, making diesel forklifts cost-effective to operate over time.
5、Versatility:
Diesel forklifts can be used both indoors and outdoors, making them versatile for various applications. Their strong performance allows them to handle a wide range of loads and terrains.
6、
Quick Refueling:
Refilling a diesel tank is usually faster than recharging batteries or swapping propane cylinders, reducing downtime for refueling.
7、
Cold Weather Performance:
Diesel engines typically perform well in cold weather conditions, which can be a crucial factor in industries that operate in extreme climates.
8、Resilience:
Diesel engines are less sensitive to adverse conditions like dust and dirt, making them suitable for rugged environments such as construction sites and outdoor warehouses.
9、Higher Capacity:
Diesel forklifts are available in larger capacities than some other forklift types, making them ideal for heavy lifting tasks.
About forklift:
A
forklift
is a powered truck used to lift heavy materials for a short distance. Buy an
order picker forklift
or select a new or
used forklift for sale
at alibaba.com to make your loading and unloading work easier.
Types of forklift trucks
Forklift truck has various features and uses in the current industrial and economic development. For side loader forklifts, the main types include stand up forklift , suitable for indoor work and the enclosed cab for outdoors. Lift trucks are types of trucks that can work in a narrower aisle because of their 35% turn radius. In addition, some trucks can operate in 8-foot-wide aisles.Forklifts from different companies like the Toyota forklift usually differ in features. A caterpillar forklift 10 ton has minimized noise and vibration levels, which helps operators to work efficiently and not get tired easily. A Hyster 10-ton forklift can handle more than one empty container, which helps port operations to save more time and cost. Forklifts can be diesel-powered or electric. Electric forklift perform effectively and help save money. A diesel forklift has an onboard diesel engine and canwithstand harsh conditions, making it ideal for outdoor use.
Uses of a forklift
Forklifts can load and unload various items, depending on their capacity. When looking for a forklift truck that can lift peopleand heavy objects from different places, a cherry-picker forklift is ideal. Cherry-picker forklifts can rise in the air to lift people working on high buildings and high ends. You can also use them to bring down loads that are out of reach. While planning to load or unload materials, a forklift crown comes in handy. A forklift crown loads and unloads products or materials from a docked vehicle and staggers them for further handling. Besides container stuffing and moving goods from or into storage areas, forkliftshelp transfer items from one site location to another. You can use a forklift to transfer items between two different areas in the production unit.
Types of forklift trucks
Forklift truck has various features and uses in the current industrial and economic development. For side loader forklifts, the main types include stand up forklift , suitable for indoor work and the enclosed cab for outdoors. Lift trucks are types of trucks that can work in a narrower aisle because of their 35% turn radius. In addition, some trucks can operate in 8-foot-wide aisles.Forklifts from different companies like the Toyota forklift usually differ in features. A caterpillar forklift 10 ton has minimized noise and vibration levels, which helps operators to work efficiently and not get tired easily. A Hyster 10-ton forklift can handle more than one empty container, which helps port operations to save more time and cost. Forklifts can be diesel-powered or electric. Electric forklift perform effectively and help save money. A diesel forklift has an onboard diesel engine and canwithstand harsh conditions, making it ideal for outdoor use.
Uses of a forklift
Forklifts can load and unload various items, depending on their capacity. When looking for a forklift truck that can lift peopleand heavy objects from different places, a cherry-picker forklift is ideal. Cherry-picker forklifts can rise in the air to lift people working on high buildings and high ends. You can also use them to bring down loads that are out of reach. While planning to load or unload materials, a forklift crown comes in handy. A forklift crown loads and unloads products or materials from a docked vehicle and staggers them for further handling. Besides container stuffing and moving goods from or into storage areas, forkliftshelp transfer items from one site location to another. You can use a forklift to transfer items between two different areas in the production unit.
