Quick Details
-
Warranty(Year):
-
5-Year
-
Color Temperature(CCT):
-
5500K
-
Support Dimmer:
-
dimmable
-
Input Voltage(V):
-
AC200-240V
-
Lamp Luminous Flux(lm):
-
6300
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-40 - 50
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Rayborn
-
Model Number:
-
Rb-Pln40W-6060
-
Item No:
-
Rb-Pln40W-6060
-
LED Power:
-
40W LED ceiling Light anti glare
-
Input voltage:
-
AC200-240V
-
Body Size:
-
600*600mm LED panel Light
-
Luminous Flux:
-
6300lm
-
Power Efficiency:
-
>0.88
-
Power Factor:
-
>0.95
-
Avaliable Color:
-
3000K/4000K/5000K/6000K
-
Material:
-
Aluminium /SPCC/PMMA
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
150lm/w, 150lm/W
-
Application:
-
Hospital
-
Lamp Body Material:
-
Aluminum
-
Warranty(Year):
-
5-Year
-
Color Temperature(CCT):
-
5500K
-
Support Dimmer:
-
dimmable
-
Input Voltage(V):
-
AC200-240V
-
Lamp Luminous Flux(lm):
-
6300
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-40 - 50
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Rayborn
-
Model Number:
-
Rb-Pln40W-6060
-
Item No:
-
Rb-Pln40W-6060
-
LED Power:
-
40W LED ceiling Light anti glare
-
Input voltage:
-
AC200-240V
-
Body Size:
-
600*600mm LED panel Light
-
Luminous Flux:
-
6300lm
-
Power Efficiency:
-
>0.88
-
Power Factor:
-
>0.95
-
Avaliable Color:
-
3000K/4000K/5000K/6000K
-
Material:
-
Aluminium /SPCC/PMMA
Ultra Slim recessed Troffer lighting UGR<16 2x2 LED Ceiling Panel Light for hospital
LED Panel Lightings/Flat LED Panel Light
| Dimension: 600* 600mm | Power: 40W |
| Input Voltage: AC200-240V | LED Type: 2835 High Lumen |
| LED quantity: 189pcs | View angle: 85-70 ° |
| CCT:3000/4000/5000/6000K | CRI: ≥ 80Ra |
|
Luminous flux: 63 00 lm |
Glare rating: UGR<16 |
| Life time: >50,000 hrs | Working Environment : Indoor |
| Housing Material: Aluminum Alloy+PC | |
| Working Temperature: -20 ºC ~ +50 ºC | |
LED Panel light Main Features :
1. New design LED Panel light ,easy to replace ,model of 600x600mm/620x620mm/ 300x1200mm all are available ;
2. Anti-glare : UGR<16 ( Common LED Panel light generally is UGR>22 on the market ) ;
3. Adopt LED Source SMD2835/0.5W with Brand Epistar ,Edsion ;
4. The luminous efficacy can reach 150LM/W with high brightness ;
5. Driver Brand: Lifud ,Tridonic ;
6. More useful light: over 90% useful lumen in cone 90 (zonal lumen);
7. Dimming: Non-Dimming, DALI and 1-10V dimming ;
8. Non-flicker design ;
9. 5 Years Warranty ;
10. Installation: Recessed/Pendant mounted
11. Widely use for indoor office ,hotel ,meeting room ,commercial using etc .
LED Panel light Competitive Advantage :
1.50% energy saving same watts compare with CFL traditional lights.
2. No glare, no UV, no pollution. Friendly to environment, healthful for man
3. Low luminous decay. 3% luminous decay After 2000hrs
4. Wide range voltage 200-240VAC
5. No need in cooling. It is the good integrated heating dissipation and aesthetic design.
6. Dimmable can be option.
LED Panel light Lighting Distribution & test report :
Illumination assessment according UGR<16
Lighting effect comparsion of 150lm/W Module LED Panel light with Ordinary LED Panel light :
More than 24hours aging test of LED Panel light :
Before shipping, all the LEDlights will be over 24 hours aging tested, inspection department will test 100% products including light up test , power wattage test , high-Voltage test , waterproof test , ground connection test and so on, defective rate is controlled less than 0.1%.Quality is ensured, you can be assured.
LED Panel light Shipment and Packaging :
Our individual package maximize protecting LED Panel lights from transfer damage in transit.
1. Label on backside of each led panel lights and your required label is available.
2. 5 pieces led panel Light per carton.
3. If you need,we can also custom color packing and put your logo on it.
LED Panel light Applications :
1. Commercial and exhibition locations
2. Hotel, conference room
3. Factory, office, house
4. Airport, metro station
5. School, hospital and other public places
6. Place that require energy-efficiency and high color rendering index
CE/RoHS/SAA Certification:
We has a group of professional technical R & D team, who can provide the OEM / ODM services according to customers and LED lighting solutions,our factory has passed the authentications of ISO9001:2000,CE, FCC, ROSH ,TUV authentication.
•1. Payment: T/T, L/C at sight, Western Union ,Paypal available
•2. Samples can be available within 5-7 working days; Order: 10-20Days
•3. Shipping freight is quoted under your requests
•4. Shipping port:Shenzhen , China
•5. Discounts are offered based on order quantities
•1. Your inquiry related to our products or prices will be replied in 24hours.
•2. OEM & ODM are welcomed, OEM brand is available.
•3. Any defective products within warranty will get maintenance or replacement unconditionally.
•4. Protect your sales area
