- Product Details
- {{item.text}}
Quick Details
-
Max. Loading Capacity:
-
2600
-
Weight (KG):
-
1300 KG
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KinYo
-
Voltage:
-
Custom made
-
Dimension(L*W*H):
-
L3000*W1600*H2450mm
-
Power (kW):
-
22 kW
-
Applicable Industries:
-
food
-
Dosing way:
-
Optional
-
Load cell:
-
Optional
-
MOC:
-
All stainless steel 304
-
Control system:
-
Buttons or PLC optional
-
Blending speed:
-
Fixed or VFD optional
-
Power supply:
-
Voltage & Hz customized
-
Design options:
-
SS316, SS316L, dosing, spraying, PLC
-
After-sales Service Provided:
-
Online support
Quick Details
-
Barrel Volume (L):
-
2600
-
Max. Loading Volume (L):
-
2000 L
-
Range of Spindle Speed(r.p.m):
-
1 - 46 r.p.m
-
Max. Loading Capacity:
-
2600
-
Weight (KG):
-
1300 KG
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KinYo
-
Voltage:
-
Custom made
-
Dimension(L*W*H):
-
L3000*W1600*H2450mm
-
Power (kW):
-
22 kW
-
Applicable Industries:
-
food
-
Dosing way:
-
Optional
-
Load cell:
-
Optional
-
MOC:
-
All stainless steel 304
-
Control system:
-
Buttons or PLC optional
-
Blending speed:
-
Fixed or VFD optional
-
Power supply:
-
Voltage & Hz customized
-
Design options:
-
SS316, SS316L, dosing, spraying, PLC
-
After-sales Service Provided:
-
Online support
KinYo
was registered in January 2018 for exporting & importing business and also a owner of a factory named Changzhou Aofile Machinery Co.,Ltd. devoting ourselves in blending and filling machine for powdered materials.
The factory is located at No. 89, Nanqi, Nanzhai, Wujin District, Changzhou City, Jiangsu Province with a manufacturing area of 3000 sqm+.
We have succeeded in delivering over 500 sets of ribbon blender and auger filling all over the world. North America and Europe are our main market on account of our exquisite workmanship.
The factory is located at No. 89, Nanqi, Nanzhai, Wujin District, Changzhou City, Jiangsu Province with a manufacturing area of 3000 sqm+.
We have succeeded in delivering over 500 sets of ribbon blender and auger filling all over the world. North America and Europe are our main market on account of our exquisite workmanship.
|
Item
|
KYRB 100
|
KYRB 200
|
KYRB 300
|
KYRB 500
|
|
Max. volume(V1)
|
140L
|
280L
|
420L
|
710L
|
|
Working volume(V2)
|
100L
|
200L
|
300L
|
500L
|
|
Weight
|
180kg
|
250kg
|
350kg
|
500kg
|
|
Total Power
|
3kW
|
4kW
|
5.5kW
|
7.5kW
|
|
Speed
|
46rpm
|
46rpm
|
46rpm
|
46rpm
|
|
Size
(L*W*H)
|
1275*480*1670mm
|
1365*600*1766mm
|
1612*660*1828mm
|
1807*740*2000mm
|
|
Item
|
KYRB 1000
|
KYRB 1500
|
KYRB 2000
|
KYRB 3000
|
|
Max. volume(V1)
|
1420L
|
1800L
|
2600L
|
3800L
|
|
Working volume(V2)
|
1000L
|
1500L
|
2000L
|
3000L
|
|
Weight
|
700kg
|
1000kg
|
1300kg
|
1600kg
|
|
Total Power
|
11kW
|
15kW
|
18.5kW
|
22kW
|
|
Speed
|
39rpm
|
28rpm
|
Custom made
|
Custom made
|
|
Size
(L*W*H)
|
2159*1030*2215mm
|
2519*1050*2635mm
|
3361*1040*2680mm
|
4067*1092*2728mm
|
Ribbons inside (single shaft)
Schneider
Electrical elements
Round for easier clean-up
Liquid hopper for spraying
Made in Korea water-oil filter
Limit switch for safety
Shaft
Cancaved outlet valve for less leftover
Hardened gearbox
Optional VFD for speed control
Dust-proof for bearing
Spare parts in delivery
Bearing before covered
Nozzle for spraying
Optional stair and platform
Relay control for mixing time
Bottom view of outlet
Worm reducer for 100L blender
Protection for pneumatic discharging
Liquid pump for spraying
Custom-made volume
10cbm
Custom-made volume
12cbm
Product packaging
