Die Cast Aluminum Celling Light Led Round Lamp Parts Die Casting Housing
Die Cast Aluminum Celling Light Led Round Lamp Parts Die Casting Housing
Die Cast Aluminum Celling Light Led Round Lamp Parts Die Casting Housing
Die Cast Aluminum Celling Light Led Round Lamp Parts Die Casting Housing
Die Cast Aluminum Celling Light Led Round Lamp Parts Die Casting Housing
Die Cast Aluminum Celling Light Led Round Lamp Parts Die Casting Housing
Die Cast Aluminum Celling Light Led Round Lamp Parts Die Casting Housing
Die Cast Aluminum Celling Light Led Round Lamp Parts Die Casting Housing

Die Cast Aluminum Celling Light Led Round Lamp Parts Die Casting Housing

FOB Reference Price: Get Latest Price
≥100 Pieces
US $1.38
≥1000 Pieces
US $1.26
≥5000 Pieces
US $1.16
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Brand Name:
Rang Dong
Model Number:
TR80ND2/20W.H / TR100ND2/30W.H / TR135ND1/60W.H
CRI (Ra>):
80/90/Sunlike
Lamp Luminous Efficiency(lm/w):
85/90/95/100
Lamp Luminous Flux(lm):
1700-6000
Color Rendering Index(Ra):
80/90/Sunlike
Lifespan (hours):
30,000
Power (W):
20/30/60
Power Factor:
0.5/0.7/0.9
Luminous Flux (lm):
1700/1800/ 1900/2000/2550/2700/ 2850/3000/5100/5400/ 5700/6000
Luminous Efficacy (lm/W):
85/90/95/100
CCT (K):
3000/4000/5000/ 5700/6500
CRI:
80/90/Sunlike
Lifespan (hrs):
30000
Voltage (V):
100-277/120/220-240
Certificates:
CE, KC, RoHS
Dimension (mm):
80x100x135

Quick Details

Color Temperature(CCT):
3000/4000/5000/5700/6500
Input Voltage(V):
100-277/120/220-240
Place of Origin:
Hanoi, Vietnam
Brand Name:
Rang Dong
Model Number:
TR80ND2/20W.H / TR100ND2/30W.H / TR135ND1/60W.H
CRI (Ra>):
80/90/Sunlike
Lamp Luminous Efficiency(lm/w):
85/90/95/100
Lamp Luminous Flux(lm):
1700-6000
Color Rendering Index(Ra):
80/90/Sunlike
Lifespan (hours):
30,000
Power (W):
20/30/60
Power Factor:
0.5/0.7/0.9
Luminous Flux (lm):
1700/1800/ 1900/2000/2550/2700/ 2850/3000/5100/5400/ 5700/6000
Luminous Efficacy (lm/W):
85/90/95/100
CCT (K):
3000/4000/5000/ 5700/6500
CRI:
80/90/Sunlike
Lifespan (hrs):
30000
Voltage (V):
100-277/120/220-240
Certificates:
CE, KC, RoHS
Dimension (mm):
80x100x135
Product Features
- Full series from 20W to 60W
- High-quality LEDs provided by Samsung/ Seoul Semiconductor/ Nichia/ Lumiled with excellent performance
- High luminous efficacy up to 100 lm/W
- Die-cast aluminum housing with perfect heat dissipation
- PC cover with high lighting transmittance and desired lighting distribution
- CE, KC, UL certified
- Long lifespan: 30,000 hours, saving the maintenance cost

Applications
- Home, hall, store, warehouse, factory and etc.
Products Details
Product Specifications
Model
Dimension
LxWxH (mm)
Power
(W)
Voltage (V)
Power factor
Luminous flux
(lm)
Luminous efficacy
(lm/W)
CCT (K)
Lifespan
(hrs)
TR80ND2/20W.H
80x146
20
120/ 220-240/
100-277V
0.5/0.7/0.9
1700/1800/
1900/2000
85/90/95/100
3000/4000/5000/
5700/6500
30,000
TR100ND2/30W.H
100x175
30
120/ 220-240/
100-277V
0.5/0.7/0.9
2550/2700/
2850/3000
85/90/95/100
3000/4000/5000/
5700/6500
30,000
TR135ND1/60W.H
135x236
60
120/ 220-240/
100-277V
0.5/0.7/0.9
5100/5400/
5700/6000
85/90/95/100
3000/4000/5000/
5700/6500
30,000
Capacity: 13.5 million pieces per year
Customizable: Power (20/30/60W), Voltage (120/220-240/100-277), PF (0.5/0.7/0.9), lm/W (up to 100), CCT (3000/4000/5000/5700/6500K), CRI (80/90/Sunlike), lifespan, etc.
Luminous Intensity Distribution
Packing and Transportation
Type of lamps
Quantity in master box (pcs)
Estimated quantity/20'DC (pcs)
Estimated quantity/40'HC (pcs)
TR80ND2/20W.H
12
28 188
64 728
TR100ND2/30W.H
12
14 832
34 056
TR135ND1/60W.H
12
6 288
14 448
Customizable according to customer’s request
Exported market: South Korea, EU, etc.
