Quick Details
-
Production Capacity:
-
200bags/min
-
Weight (KG):
-
800
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Dession
-
Dimension(L*W*H):
-
3770*670*1450mm
-
Sealing type:
-
Heat Sealer
-
Control system:
-
PLC
-
Packing material:
-
OPP/CPP/PE/PET
-
Bag type:
-
pillow bag/back sealing bag
-
Keyword:
-
Bag Pillow Packaging Machine
-
Main Function:
-
Automatic Form
-
Material:
-
SUS304
-
Advantage:
-
Reliable
-
Automaticity:
-
Touch Screen
-
Optional Devices:
-
Data Printer
Quick Details
-
Function:
-
FILLING, Wrapping, Labeling, Sealing
-
Packaging Type:
-
Bags, Film, Pouch
-
Packaging Material:
-
Plastic, Paper
-
Production Capacity:
-
200bags/min
-
Weight (KG):
-
800
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Dession
-
Dimension(L*W*H):
-
3770*670*1450mm
-
Sealing type:
-
Heat Sealer
-
Control system:
-
PLC
-
Packing material:
-
OPP/CPP/PE/PET
-
Bag type:
-
pillow bag/back sealing bag
-
Keyword:
-
Bag Pillow Packaging Machine
-
Main Function:
-
Automatic Form
-
Material:
-
SUS304
-
Advantage:
-
Reliable
-
Automaticity:
-
Touch Screen
-
Optional Devices:
-
Data Printer
Film Holder
Put the material into the stainless conveyor.
Stainless Steel
Conveying
The middle sealing device will sealing the film together.
Touch Control
Setting the parameters you want by touch sreccn.
Bag Former
The stainless steel bag maker device will make the bag shape.
Bag Sealing Device
The cutting device will cut the bag automaticlly.
Bag Cutter Device
Then you can get the nicely pcakages.
|
Upper-Reel Flow Wrapping Packing Machine
|
|
|
|
|
|
|
||||||
|
Model
|
DS-250B/D
|
DS-320B/D
|
DS-350B/D
|
DS-400B/D
|
DS-450D
|
DS-600D
|
||||||
|
Film Width
|
Max.250mm
|
Max.320mm
|
Max.350mm
|
Max.400mm
|
Max.450mm
|
Max.600mm
|
||||||
|
Bag Length
|
65~190 or 120~280mm
/ 90~220 or 150~330mm
|
80~300mm
|
80~350mm
|
130~320
/180~400mm
|
120~450mm
|
130~450mm
|
||||||
|
Bag Width
|
30~110mm
|
50~150mm
|
50~160mm
|
50~190mm
|
60~210mm
|
60~280mm
|
||||||
|
Product Height
|
Max.40/50mm
|
Max.45/80mm
|
150~2000ml
|
150~4000ml
|
Max.110mm
|
6000ml(max)
|
||||||
|
Roll Diameter
|
Max.320mm
|
|
|
|
|
|
||||||
|
Packaging Speed
|
40~230 bags/min
|
5~60 bags/min
|
10~50 bags/min
|
30~180 bags/min
|
10~40 bags/min
|
30~150 bags/min
|
||||||
|
Machine Power
|
220V,50/60Hz,2.4KW
|
220V,
50/60HZ,
2.2KW
|
220V,
50/60HZ,
3KW
|
220V,
50/60HZ,
3KW
|
220V,
50/60HZ,
3.6KW
|
220V,
50/60HZ,
3.6KW
|
||||||
|
Machine Size
(L*W*H)mm
|
3770*670
*
1450
|
3770*720
*1450
|
3770*720
*1450
|
4020*770
*1450
|
3990*900
*1468
|
3990*1000
*1468
|
||||||
|
Machine Weight
|
800kg
|
900kg
|
750kg
|
700kg
|
900kg
|
1050kg
|
||||||
|
Optional Device
|
Date Coder, Air-filling Device, Punching Device
|
|
|
|
|
|
||||||
