Quick Details
-
Brand Name:
-
hongba
-
Voltage:
-
380V/220V
-
Dimension(L*W*H):
-
1600*1240*1650mm
-
Weight (KG):
-
1850
-
Power (kW):
-
2.5
-
Working table travel:
-
400*500mm
-
Workbench load:
-
500 kg
-
Cut speed:
-
200 mm²/min
-
After-sales Service Provided:
-
Online support
-
After Warranty Service:
-
Online support
-
Certification:
-
CE
-
Precision:
-
0.004mm
-
Surface Roughness:
-
1um
Quick Details
-
Marketing Type:
-
New Product 2023
-
Place of Origin:
-
Jiangsu, China
-
Year:
-
2023
-
Brand Name:
-
hongba
-
Voltage:
-
380V/220V
-
Dimension(L*W*H):
-
1600*1240*1650mm
-
Weight (KG):
-
1850
-
Power (kW):
-
2.5
-
Working table travel:
-
400*500mm
-
Workbench load:
-
500 kg
-
Cut speed:
-
200 mm²/min
-
After-sales Service Provided:
-
Online support
-
After Warranty Service:
-
Online support
-
Certification:
-
CE
-
Precision:
-
0.004mm
-
Surface Roughness:
-
1um
Main Features
2.X Y drum all servo drive ，U V Z axis hybrid drive
3. High-speed the maximum working speed is over 200mm ²/min
6. Z-axis automatic homing function
PS: All the working area and specifications can be customized according to your requests.
|
Technical parameter/Model
|
unit
|
SF 30 series
|
SF 40 series
|
SF 50 series
|
SF 60 series
|
DK7780
|
||||
|
U V axis travel
|
mm
|
±30mm，LM guide
|
±30mm，LM guide
|
±30mm，LM guide
|
±30mm，LM guide
|
985*1350
|
||||
|
Worktable travel
|
mm
|
350*450
|
450*550
|
550*630
|
630*800
|
800*1000
|
||||
|
Max cutting thickness
|
mm
|
450
|
450
|
550
|
750
|
750
|
||||
|
Cutting angel
|
°
|
6° ( Customizable )
|
|
|
|
6°
|
||||
|
Max cutting speed(single)
|
m㎡/min
|
200
|
|
|
|
160
|
||||
|
Optimum roughness
|
um
|
<1um
|
|
|
|
<2.4 um(1.2um for multi cut)
|
||||
|
Dia of molybdenum wire
|
mm
|
0.1-0.2
|
|
|
|
|
||||
|
wire moving speed
|
m/s
|
1-12m/s
|
|
|
|
|
||||
|
Power supply
|
HZ V
|
50HZ 220V/380V Customizable
|
|
|
|
|
||||
|
Multiple cutting accuracy Cr12, H=40mm, 15mm octagonal
|
mm
|
<0.004 mm
|
|
|
|
|
||||
|
Motion axis motion resolution
|
mm
|
0.001mm
|
0.001mm
|
0.001mm
|
|
|
||||
|
Bidirectional positioning accuracy (five round trips, laser measurement)
|
mm
|
≤0.01mm
|
≤0.01mm
|
≤0.01mm
|
|
|
||||
|
Repetitive positioning accuracy (five round trips, laser measurement)
|
mm
|
≤0.005mm
|
≤0.005mm
|
≤0.005mm
|
|
|
||||
|
Reverse clearance (five round trips, laser measurement)
|
mm
|
≤0.005 mm
|
≤0.005 mm
|
≤0.005 mm
|
|
|
||||
|
MAX.workpiece weight
|
kg
|
600kg
|
800kg
|
1000kg
|
1200kg
|
1500
|
||||
|
Power consumption
|
Kw
|
3
|
|
|
|
<1.2
|
||||
|
Machine weight
|
kg
|
2100kg
|
2300kg
|
2800kg
|
3500kg
|
2800
|
||||
|
Machine demensions
|
mm
|
1960*1620*1915
|
2070*1800*1920
|
2390*2000*2130
|
2650*2310*2140
|
2250*1940*1850
|
||||
Q: Could I visit your factory ?
A:Of course,Yes! Warmly welcome all customer from all over the world to visit our factory.
Q: What about the price?
A: We promise the price we offer is lowest if same application, only to enlarge the market share.And given you cost price for consumable parts.
Q:Could you modified and production machine according to our designer ?What information will you need ?
A6:Of course yes.The worktable size and worktable travel, your special requirements.
Q: Do you provide training and maintenance?
A: Yes. In order to make your production more efficient, after signing contract, you can send someone to my company for professional operation training. we also can dispatch our engineer go to your country and assist you on installation and operation. But all accommodation charge and Round trip tickets should be stand by the buyer
Q:Whats your fast delivery time ?
A:If have stock after we received pre payment with 15days can arrange shipment.
Generally delivery time around 30 days not include national holiday.
Q: How to solve the quality problems after sales?
A: Take photos or video of the problems and send to us After we check and confirm the problems, within 24 hours days,we will reply satisfied solution for you.
Q:What is your terms of payment?
A:Usually,we accept T/T,irrevocable L/C at sight.
For regular orders,we prefer 30% in advance,70% before shipment.
Q: Are you a manufacturer or trade company?
A: We are the professional manufacturer of cnc machine tool, commited to this field for above 15 years.
