Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Smart
-
Copper Thickness:
-
0.2-6.0 oz
-
Min. Hole Size:
-
0.1mm
-
Min. Line Width:
-
0.15mm
-
Min. Line Spacing:
-
0.075mm
-
Surface Finishing:
-
HASL, lead free
-
Board Size:
-
custom
-
Solder mask:
-
green, red, blue, yellow, black, white etc
Quick Details
-
Base Material:
-
FR4, TG
-
Board Thickness:
-
0.2-4.0mm
-
Model Number:
-
PCB Assembly
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Smart
-
Copper Thickness:
-
0.2-6.0 oz
-
Min. Hole Size:
-
0.1mm
-
Min. Line Width:
-
0.15mm
-
Min. Line Spacing:
-
0.075mm
-
Surface Finishing:
-
HASL, lead free
-
Board Size:
-
custom
-
Solder mask:
-
green, red, blue, yellow, black, white etc
Products Description
China PCB manufactures ,welcome to buy our printed circuit board
Please kindly send us your gerber file and bom list
for quotation ,and please also inform the order quantity
for quotation ,and please also inform the order quantity
|
PCB Capacities and Technical Specification
|
|
|
|
Order Quantity
|
1-500,000
|
|
|
Layer
|
1, 2, 4, 6, up to 24 layer
|
|
|
Material
|
FR-4, High Tg, Isola, Aluminum, Rogers, etc
|
|
|
PCB type
|
Rigid, flexible, rigid-flexible
|
|
|
Shape
|
Rectangular, round, slots, cutouts, complex, irregular
|
|
|
Max PCB dimensions
|
1200mm*600mm
|
|
|
Thickness
|
0.2~4.0mm, Flex 0.01~0.25''
|
|
|
Thickness tolerance
|
± 10%
|
|
|
Copper thickness
|
0.5-6 oz
|
|
|
Copper thickness tolerance
|
± 0.25oz
|
|
|
Surface finish
|
HASL, LF HASL, Imm Gold, Imm Silver, OSP etc
|
|
|
Solder mask
|
Green, red, white, yellow, blue, black, orange, purple
|
|
|
Silk screen
|
White, black
|
|
|
Silk screen min line width
|
0.006'' or 0.15mm
|
|
|
Min drill hole diameter
|
0.01'', 0.1mm or 10 mil
|
|
|
Min trace/gap
|
0.075mm or 3mil
|
|
|
PCB cutting
|
Shear, V-score, tab-routed
|
|
|
PCBA Capabilities
|
|
|
|
Turnkey PCBA
|
PCB+components sourcing+assembly+package
|
|
|
Assembly details
|
SMT and Thru-hole, ISO SMT and DIP lines
|
|
|
Lead Time
|
Prototype : 15 work days. Mass order : 20~25 work days
|
|
|
Testing on products
|
Testing jig/mold , X-ray Inspection, AOI Test, Functional test
|
|
|
Quantity
|
Min quantity : 1pcs. Prototype, small order, mass order, all OK
|
|
|
Files needed
|
PCB : Gerber files(CAM, PCB, PCBDOC)
Components : Bill of Materials(BOM list) Assembly : Pick-N-Place file |
|
|
PCB Panel Size
|
Min size : 0.25*0.25 inches(6*6mm)
Max size : 1200*600mm |
|
|
Components details
|
Passive Down to 0201 size
BGA and VFBGA Leadless Chip Carriers/CSP Double-sided SMT Assembly Fine Pitch to 0.8mils BGA Repair and Reball Part Removal and Replacement |
|
|
Component package
|
Cut Tape, Tube, Reels, Loose Parts
|
|
|
PCB+ assembly process
|
Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave
Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing |
|
