Quick Details
-
Range of Spindle Speed(r.p.m):
-
10 - 1400 r.p.m
-
Width of bed (mm):
-
400
-
Max. Turned Length (mm):
-
1000 mm
-
Spindle Motor Power(kW):
-
7.5
-
Year:
-
2021
-
Place of Origin:
-
China
-
Brand Name:
-
HAISEN
-
Model Number:
-
CK6150
-
Voltage:
-
380
-
Dimension(L*W*H):
-
3200*1140*1750mm
-
Weight (KG):
-
2577 KG
-
Max .Swing over carriage:
-
370mm
-
Chuck diameter:
-
250mm
-
Max .length of work:
-
750-6000mm
-
Max workpiece weight:
-
300Kg
-
section of turning tool:
-
25*25mm
-
CNC or Not:
-
Not
-
tailstock spindle diameter:
-
75 mm
-
Max. tailstock spindle travel:
-
150 mm
-
After-sales Service Provided:
-
Online support
Quick Details
-
Max. Length of Workpiece (mm):
-
1000
-
Machining Capacity:
-
Medium Duty
-
Spindle Bore(mm):
-
52
-
Range of Spindle Speed(r.p.m):
-
10 - 1400 r.p.m
-
Width of bed (mm):
-
400
-
Max. Turned Length (mm):
-
1000 mm
-
Spindle Motor Power(kW):
-
7.5
-
Year:
-
2021
-
Place of Origin:
-
China
-
Brand Name:
-
HAISEN
-
Model Number:
-
CK6150
-
Voltage:
-
380
-
Dimension(L*W*H):
-
3200*1140*1750mm
-
Weight (KG):
-
2577 KG
-
Max .Swing over carriage:
-
370mm
-
Chuck diameter:
-
250mm
-
Max .length of work:
-
750-6000mm
-
Max workpiece weight:
-
300Kg
-
section of turning tool:
-
25*25mm
-
CNC or Not:
-
Not
-
tailstock spindle diameter:
-
75 mm
-
Max. tailstock spindle travel:
-
150 mm
-
After-sales Service Provided:
-
Online support
|
Main Parameters
|
Unit
|
CK6150
|
CK6161
|
CK6166
|
||
|
Max swing diameter over bed
|
mm
|
500
|
610
|
660
|
||
|
Max swing diameter over tool post
|
mm
|
300
|
370
|
400
|
||
|
Max. workpiece length between centers
|
mm
|
750 /1000 /1500 /2000
|
|
|
||
|
Bed width
|
mm
|
400
|
400
|
400
|
||
|
Max workpiece weight
|
kg
|
300
|
300
|
300
|
||
|
Main motor power
|
KW
|
7.5
|
7.5
|
7.5
|
||
|
Chuck diameter
|
mm
|
250
|
250
|
250
|
||
|
Tool post type
|
/
|
Three jaw chuck
|
Three jaw chuck
|
Three jaw chuck
|
||
