Quick Details
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
≥30T
-
Drive Wheel:
-
8X4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Free spare parts
-
Brand Name:
-
Other Brand
-
Place of Origin:
-
Jiangsu, China
-
Engine Brand:
-
Top Brand
-
Gear Box Brand:
-
Top Brand
-
Dimensions (L x W x H) (mm):
-
10500*5800*5500mm
-
Cargo Tank Dimension:
-
10500*5800*5500
-
Rated Payload:
-
110t
-
Empty Weight:
-
80000kg
-
Max. Speed:
-
55km/h
-
Max. Gradeability:
-
22%
-
Min. Turning Diameter:
-
22m
Quick Details
-
Condition:
-
New
-
Horsepower:
-
451 - 500hp
-
Emission Standard:
-
Euro 4
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
≥30T
-
Drive Wheel:
-
8X4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Free spare parts
-
Brand Name:
-
Other Brand
-
Place of Origin:
-
Jiangsu, China
-
Engine Brand:
-
Top Brand
-
Gear Box Brand:
-
Top Brand
-
Dimensions (L x W x H) (mm):
-
10500*5800*5500mm
-
Cargo Tank Dimension:
-
10500*5800*5500
-
Rated Payload:
-
110t
-
Empty Weight:
-
80000kg
-
Max. Speed:
-
55km/h
-
Max. Gradeability:
-
22%
-
Min. Turning Diameter:
-
22m
China Top Brand XDE110 Heavy Mining Dump Truck Price For Sale
Contact way
Sales Manager
Rees Wang
Newindu Construction Engineering (Shanghai) Co.,Ltd
Add: Suite 2801, Super Ocean Finance Center,2067 West Yan'an Road, Shanghai 200336, China
Mobile / Whatsapp/ Skype/Wechat: +86-17835409799
Web: www.newindu.com
Rees Wang
Newindu Construction Engineering (Shanghai) Co.,Ltd
Add: Suite 2801, Super Ocean Finance Center,2067 West Yan'an Road, Shanghai 200336, China
Mobile / Whatsapp/ Skype/Wechat: +86-17835409799
Web: www.newindu.com
Products Description
1. High
performance engine
Environment-friendly, electronically controlled, powerful diesel engine with less fuel consumption. High torque at low rpm for more traction power ensures strong vehicle climbing ability.
2. AC-DC-AC electric drive system
utilize AC-DC-AC electric drive system, safe and reliable，with fewer failure rate and maintenance costs. Constant-power and stepless speed regulation are achieved, with more traction power to maximize the productivity.
3. Structurally enhanced frame
* Welded box sectional steel structure.
* High strength alloy steel ensures the frame have high toughness to resist low-pressure impact, good fatigue properties and good weldability.
* Steel castings have been incorporated at key frame pivot points and key load bearing critical portions of the frame, includes the rear body pivot, pump pivot and cross beams, etc.
* The computer-aid design and finite element analysis ensure the frame have enough intensity.
Product Paramenters
|
Item
|
|
Unit
|
XDE110
|
|
|
Performance parameters
|
Rated Payload
|
t
|
110
|
|
|
|
Empty Weight
|
kg
|
80000
|
|
|
|
Gross Vehicle Weight
|
kg
|
190000
|
|
|
|
Drive Style
|
|
4x2
|
|
|
|
Max. Speed
|
km/h
|
55
|
|
|
|
Max. Gradeability
|
%
|
22
|
|
|
|
Min. Turning Diameter
|
m
|
22
|
|
|
|
Overall dimension
|
mm
|
10500*5800*5500
|
|
|
Engine
|
Model
|
|
Cummins KTA38
|
|
|
|
Rated Power/Speed
|
kW/rpm
|
895/2100
|
|
|
|
Max. Torque/Speed
|
Nm/rpm
|
4678/1300
|
|
|
Electric drive
|
Alternator
|
|
YJ116C
|
|
|
|
Traction Motor
|
|
YJ198A
|
|
|
|
Ratio
|
|
29.38:1
|
|
|
Tires
|
Standard Tire
|
|
30.00R51 Tubeless, all-steel radial tires
|
|
|
Electrical
|
|
V
|
24
|
|
