Quick Details
-
Application:
-
Heating System
-
Color:
-
Red
-
Max input, Btu/hr (KW):
-
1,500,000(440) velocity
-
Min input, ratio regulated Btu/hr (KW):
-
150,000(44) velocity
-
Min input, fixed air Btu/hr (KW):
-
30,000(9) velocity
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Weight (T):
-
2 T
-
Power (kW):
-
300-1500kw
-
Application:
-
Heating System
-
Color:
-
Red
-
Max input, Btu/hr (KW):
-
1,500,000(440) velocity
-
Min input, ratio regulated Btu/hr (KW):
-
150,000(44) velocity
-
Min input, fixed air Btu/hr (KW):
-
30,000(9) velocity
| Model | Rated output power | Minimum thermal power KWh(kcal/h) | Maximum thermal power KWh(kcal/h) | Maximum consumption |
| DCM-10 | 116 | 60,000 | 150,000 | 5-12 kg/H |
| DCM-20 | 232 | 160,000 | 280,000 | 13-23 kg/H |
| DCM-30 | 336 | 220,000 | 380,000 | 18-31 kg/H |
| DCM-40 | 450 | 320,000 | 480,000 | 26-40 kg/H |
| DCM-50 | 560 | 420,000 | 580,000 | 35-48.5 kg/H |
| DCM-60 | 672 | 520,000 | 680,000 | 43-56.5 kg/H |
•
All information is based on laboratory testing in neutral (0 "w.c., 0 mbar) pressure chamber.
Difffferent chamber
• All information is based on standard combustor design. Changes in combustor will alter
performance and pressures.
• All inputs are calculated according to the high calorifific value of the fuel.
• Our company reserves the right to change the construction and/or confifiguration of our products
at any time without being obliged to adjust earlier supplies accordingly.
•
Plumbing of air and gas will affffect accuracy of orififice readings. All information is based on generally
acceptable air and gas piping practices.
