Quick Details
-
Model Number:
-
10HW046A
-
Place of Origin:
-
Guangdong, China
-
Nominal Impedance:
-
8 Ω
-
Nominal Power handling:
-
200 W
-
Sensitivity (1W/1m):
-
95.4 dB
-
Winding Material:
-
Copper
-
Former Marerial:
-
ASV
-
Voice Coil Diameter:
-
65.5 mm/2.58"
-
Winding Depth:
-
14 mm
-
size:
-
10 inch
-
Quality:
-
high
-
Service:
-
good
Quick Details
-
Type:
-
Passive
-
Use:
-
Stage
-
Brand Name:
-
Hiwell audio
-
Model Number:
-
10HW046A
-
Place of Origin:
-
Guangdong, China
-
Nominal Impedance:
-
8 Ω
-
Nominal Power handling:
-
200 W
-
Sensitivity (1W/1m):
-
95.4 dB
-
Winding Material:
-
Copper
-
Former Marerial:
-
ASV
-
Voice Coil Diameter:
-
65.5 mm/2.58"
-
Winding Depth:
-
14 mm
-
size:
-
10 inch
-
Quality:
-
high
-
Service:
-
good
1. 10 inch woofer 400watts Peak power.
2. 200 watts woofer with high quality and good price
3. special wool cone
4. Used in line array speaker system
| Features | |
| Power handling capacity 200 W RMS | |
| Reference efficiency(1W @ 1m) 95.4 dB SPL | |
| Voice coil size 65.5mm/2.5 inch | |
| Usable frequency range 59.3-3200 Hz | |
| Environmental withstanding Outdoor | |
| Specifications | |
| Nominal Diameter | 263 mm |
| Nominal Impedance | 8 Ω |
| Minimum Impedance | 7.3 Ω |
| Power handling | |
| (50-500Hz) | |
| Nominall | 200 W |
| Continuous Program | 400 W |
| Sensitivity (1W/1m)3 | 95.4 dB |
| Frequency Range | 59.3-3200 Hz |
| Voice Coil Diameter | 65.5 mm |
| Winding Material | Copper |
| Former Marerial | ASV |
| Winding Depth | 14 mm |
| Magnetic Gap Depth | 8 mm |
| Flux density | 1.2 T |
| Thiele-Small parameters4 | |
| Fs | 59.3 Hz |
| Re | 5.6 Ω |
| Qes | 0.34 |
| Qms | 3.06 |
| Qts | 0.31 |
| Vas | 37.5 L |
| η0 | 2.18% |
| X max | 3 mm |
| X var | 4 mm |
| Mms | 39 gr |
| BL | 15.4 N/A |
| Le | 0.8 mH |
| Mounting and Shipping Information | |
| Blot Circle Diameter | 245 mm |
| Overall Diameter | 263 mm |
| Baffie Cutout Diameter | 230 mm |
| Depth | 120 mm |
| Flang and Gasket Tickness | 11 mm |
| Net Weight | 4.5 kg |
| Shipping Weight | 4.9 kg |
| Shipping BOX | 27.5×27.5×14 mm |
| Magnet Size | 156*80*20 mm |
