Quick Details
-
Graphic Format Supported:
-
AI, BMP, Dst, PLT
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZHONGKE
-
Model Number:
-
1325
-
Dimension(L*W*H):
-
2.1*3.2*1.8m
-
Laser power:
-
60/80/100/150/200W
-
Working humidity:
-
Free of condemened water
-
Cutting speed:
-
0-60mm/min
-
Working mode:
-
Stepper motor and driver
-
Cuting thickness:
-
0-20mm plexiglass(others defermined by materials)
-
Command::
-
G code*.000*.mmg*.plt
-
Table:
-
Knife table surface
-
Total power:
-
<1,000 W
-
Engrving speed:
-
1-6000min/mm
-
Type:
-
Water Cooling CO2 Laser Engraving Machines
Quick Details
-
Engraving Area:
-
600*900mm
-
Laser Type:
-
CO2
-
Engraving Speed:
-
1-6000mm/min
-
Graphic Format Supported:
-
AI, BMP, Dst, PLT
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZHONGKE
-
Model Number:
-
1325
-
Dimension(L*W*H):
-
2.1*3.2*1.8m
-
Laser power:
-
60/80/100/150/200W
-
Working humidity:
-
Free of condemened water
-
Cutting speed:
-
0-60mm/min
-
Working mode:
-
Stepper motor and driver
-
Cuting thickness:
-
0-20mm plexiglass(others defermined by materials)
-
Command::
-
G code*.000*.mmg*.plt
-
Table:
-
Knife table surface
-
Total power:
-
<1,000 W
-
Engrving speed:
-
1-6000min/mm
-
Type:
-
Water Cooling CO2 Laser Engraving Machines
Features:
1). The " front" and "back" of our laser machine can be open , suitable for super-length material process.
2). LCD control panel in English , convenience of operation control.
3). Import liner bearing with high engraving precision
4). offline control system which can not only work without computer , but also connect to U disk, USB communication
5). Imported metal mirrors , with good ability of reflection and focusing, long working life.
6). Red dot position system realizes the exact position without laser.
7). Auto Focus technology , realize "easy focus & high efficiency " in real, not only a word.
Specification:
|
Laser type |
Sealed CO 2 laser tube, water-cooling, wavelength 10.6um |
|
Laser power |
60/80/100/150/200W |
|
Cooling type |
Water-cooling (5-30°C tap water or purified water) |
|
Y axis guide rail |
Imported Taiwan HIWIN square guide rail |
|
Engraving Scanning Speed |
0 - 70000mm/min |
|
Cutting Speed |
0 - 40000mm/min |
|
Laser Output |
1-100% software setting |
|
Locating Precision |
±0.01mm, red light locating. |
|
Power supply |
AC220±10%,single phase,50Hz |
|
Cooling system |
Industrial water chiller |
|
Running environment |
Temperature:5-45°C; Humidity:5-95% (free of condensed water) |
|
Software |
LASERCUT5.3 (original version) |
|
Supported graphic Format |
BMP, DST, GIF, TGA, AI, PLT, DXF, LAS, etc. |
|
Dimensions |
3.2*2.05*1.12m |
Samples:
Applied area:
1.For laser processing in bamboo, crystal, horn, paper, glass, marble, cloth, leather, rubber, plastic and other non-metallic materials. Clothing, embroidery, cloth toys, furniture fabric, handbag, gloves, toys, leather industry, leather cutting and surface carving.
2.Arts and crafts, models, advertising, decoration, electrical appliances, plastics industry, acrylic plate, MDF decorative plate, such as non-metallic cutting.
Technical support:
- Warranty is 1 year
- 24 hour technical support by email or calling
- User-friendly english manual for machine using and maintaining
- We will send you manual and guide video in English,if you still don't know how to operate it, we can help you by phone or Whatsapp,Skype.
Payment terms:
- You can do 30% prepayment at first, then we will start to make machine. when the machine is ready , we will take pictures to you, after we got you payment.We will send the machine to you.
