Quick Details
-
Core Components:
-
laser source
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
XT LASER
-
Weight (KG):
-
240 KG
-
Applicable Industries:
-
shipping, auto parts, rubber mould, high-end machi
-
Product name:
-
Laser Rust Cleaning Removal Machine
-
Voltage:
-
Single 220v 50/60hz AC
-
Clean Width:
-
10-100mm
-
Pulse Frequency:
-
10-50KHZ
-
Cable length:
-
5m
-
cleaning speed:
-
1000-8000mm/s
-
Cooling Way:
-
water cooling
-
Cleaning Type:
-
Manual
-
head weight:
-
2.5kg
-
cleaning efficiency (m2/h):
-
5/9/20
Quick Details
-
Power:
-
100w/200w/300w/500w/1000w
-
Laser Type:
-
Fiber Laser
-
Laser Source Brand:
-
RAYCUS
-
Core Components:
-
laser source
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
XT LASER
-
Weight (KG):
-
240 KG
-
Applicable Industries:
-
shipping, auto parts, rubber mould, high-end machi
-
Product name:
-
Laser Rust Cleaning Removal Machine
-
Voltage:
-
Single 220v 50/60hz AC
-
Clean Width:
-
10-100mm
-
Pulse Frequency:
-
10-50KHZ
-
Cable length:
-
5m
-
cleaning speed:
-
1000-8000mm/s
-
Cooling Way:
-
water cooling
-
Cleaning Type:
-
Manual
-
head weight:
-
2.5kg
-
cleaning efficiency (m2/h):
-
5/9/20
Product Description
Main features
XT Laser laser cleaning machine is easy to install, control, and implement automation. With Simple operation, switching power supply, open the device, then it can be achieved cleaning without chemical reagent, medium and water washing, it has many advantages of the focus adjustment manually, joint surface cleaning, higher cleaning surface cleanliness, it also can remove the surface of resin, grease, stains, dirt, rust, coating, coating, paint on objectives
Technical Parameter
|
Operate voltage
|
|
Single phase 220v/50-60Hz
|
|
||
|
Power consumption
|
|
2500w(including water chiller)
|
|
||
|
Conditions
|
|
Flat ground,vibration free, no impact
|
|
||
|
Operation ambient air temperature range
|
|
0-40℃
|
|
||
|
Operation ambient air humidity range
|
|
≤80%
|
|
||
|
Average laser power
|
|
200w
|
|
||
|
Power regulation range (%)
|
|
10-100
|
|
||
|
Repeat frequency (KHz)
|
|
10-50
|
|
||
|
Cleaning efficiency(m2/h)
|
|
9
|
|
||
|
Focal length(mm)
|
|
100(standard)/254(optional)
|
|
||
|
Cooling way
|
|
Water cooling
|
|
||
|
Machine size(mm)
|
|
1070*1000*620
|
|
||
|
Weight
|
|
270kg
|
|
||
|
Cable length
|
|
5m(the Max 10m is customized)
|
|
||
|
Weight of hand-held gun
|
|
2.5kgs
|
|
||
|
Scan width(mm)
|
|
10-110mm
|
|
||
|
Motion type
|
|
Hanheld
|
|
||
Samples Photos
Laser cleaning is widely used in various industries, such as shipping, auto parts, rubber mould, high-end machine tool, tire mould, rail, environmental protection
Product packaging
After-sales service
Warranty time
XT LASER has two years warranty on the products purchased by customers and lifetime maintenance. During the warranty period, when the equipment is out of order and the mechanical parts are damaged (except for human factors and majeure factors),XT LASER is responsible for free repairs free of charge, and the required replacement parts are provided free of charge by XT LASER (except for consumable parts). After the warranty period, only the actual cost of repair will be charged for the repair.
After-sales service response time
