spray bottle liquid filling machine,aerosol filling machine gas machine filling spray oxygen aerosol can filler

spray bottle liquid filling machine,aerosol filling machine gas machine filling spray oxygen aerosol can filler

FOB Reference Price: Get Latest Price

≥1 Sets

US $6000

≥2 Sets

US $5500

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: Higee

Dimension(L*W*H):: 1200 * 8000 * 1500 mm

Weight (KG):: 500

Name:: spray filling machine

Model:: HG-20

Production capacity:: 1800-4000 cph

Liquid filling volume:: 30-750 ml

Inflaction filling volume:: 30-750 ml

Bottle type:: Aerosol cans , spray cans

Bottle diameter:: 35-65 mm

Bottle height:: 50-320 mm

Machinery Capacity:: 3000BPH

Quick Details

Production Capacity:: customized

Voltage:: 380v 50 hz 3 phase

Place of Origin:: Shanghai, China

Brand Name:: Higee

Dimension(L*W*H):: 1200 * 8000 * 1500 mm

Weight (KG):: 500

Name:: spray filling machine

Model:: HG-20

Production capacity:: 1800-4000 cph

Liquid filling volume:: 30-750 ml

Inflaction filling volume:: 30-750 ml

Bottle type:: Aerosol cans , spray cans

Bottle diameter:: 35-65 mm

Bottle height:: 50-320 mm

Machinery Capacity:: 3000BPH

SGS certification spray bottle liquid filling machine

This machine consist of cans arranging machine, rotary liquid filling machine, valve inserting machine, rotary sealing and gas filling , automatic weight checker, water bath, nozzle presser, cap presser, ink jet printer, packing table, etc. Propellants could be LPG, DME, CO2, N2, compressed air, etc, This machine is widely applied in personal care and body care also spray paint, air freshener, insecticide, body spray, cosmetics, food aerosols.

Woring process :

Can arranging machine - Liquid filling machine-Valve inserting machine-sealing and gas filling machine-big cap pressing machine- Actuator pressing machine-water bath tester -weight check machine-date printing machine-packing table-swinging machine

Liquid filling machine This machine has 2-4 filling liquid fillers. It is automatic and with high-efficiency,It will not fill materials without empty cans.And the filling accuracy is over 99% .
	Valve inserting and Sealing machine This machine can make the valves match into the mouths of cans automatic one by one.It consist of a valve arranging machine,an inclined conveyor belt and a valve feeder,it can saves labor and improve production efficiency.this machine can insert the valve with tubes and also the valve without tubes.
Gas filling machine This machine is operated by pneumatic, it consists of filling heads,booster pump,gas storage tank . It is automatic and the gas filling heads will not fill gas if there is no cans.
	Automatic actuator pressing machine Automatic actuator pressing machine is consists of a vibration hopper and an indexing table, it can automatically arrange and convey caps, and then cap pressing machine press caps onto aerosol cans automatically .

Technical parameter

Name	Aerosol filling machine
Liquid Filling volume	50-750 ml
Production capacity	1800-3600 bph (it ’ s according to your finished production filling volume)
Liquid filling accuracy	≤ ±1%
Inflation volume	50-750 ml
Inflation volume accuracy	≤ ±1%
Capping size accuracy	≤ ± 2 %
Application cans diameter	35-65 mm
Can height	90-315 mm
Working pressure	0.6- 1 mpa
Workling pressure (m3/min)	3~5
